Figure 17. Locating Active Heatsink Cable Connections - Intel S5000PSL - Server Board Motherboard User Manual

Server board motherboard

Hide thumbs Also See for S5000PSL - Server Board Motherboard:

Table of Contents

5. Active heatsink only: Connect the heatsink cable to the server board.

6. Reinstall and reconnect any parts you removed or disconnected to reach the

processor sockets. See the documentation that came with your chassis for

instructions on installing chassis components.

7. Replace the chassis cover and reconnect the AC power cord. See the documentation

that came with your chassis for instructions on installing the cover.

Intel

Server Board S5000PSL

Processor Heatsink

Callout

Connector

CPU_2
