Page 1 Fiery S300 31C-M Color Server CONFIGURATION GUIDE...
Page 2 ™ This manual is part of a set of Fiery S300 31C-M Color Server documentation that About the includes the following manuals for users and system administrators: Documentation • The Quick Start Guide summarizes the steps for conﬁguring the Fiery S300 31C-M Color Server and printing.
Page 3 Copyright © 2003 Electronics For Imaging, Inc. All rights reserved. This publication is protected by copyright, and all rights are reserved. No part of it may be reproduced or transmitted in any form or by any means for any purpose without express prior written consent from Electronics For Imaging, Inc., except as expressly permitted herein.
Page 4 FCC Information WARNING: FCC Regulations state that any unauthorized changes or modiﬁcations to this equipment not expressly approved by the manufacturer could void the user’s authority to operate this equipment. CE Marking (Declaration of Conformity) This product complies with the following EU directives: 89/336/EEC, 73/23/EEC, and 93/68/EEC directives. This declaration is valid for the area of the European Union.
Page 5 License EFI grants you a non-exclusive license to use the software (“Software”) and accompanying documentation (“Documentation”) included with the Product. The Software is licensed, not sold. You may use the Software solely for your own customary business or personal purposes. You may not rent, lease, sublicense or lend the Software.
Page 6 U.S. Government Restricted Rights: The Software and Documentation are provided with RESTRICTED RIGHTS. Use, duplication, or disclosure by the United States Government is subject to restrictions as set forth in subparagraph (c)(1)(ii) of the Rights in Technical Data and Computer Software clause at DFARS 252.227-7013 or subparagraphs (c)(1) and (2) of the Commercial Computer Software Restricted Rights at 48 CFR 52.227-19, as applicable.
Page 7: Table Of Contents
Contents About the Documentation Introduction About this manual Chapter 1: Connecting to the Network Fiery S300 on the network Stages of installation on the network Quick path to installation Connecting network cable to the Fiery S300 1-10 Back view of the Fiery S300 1-11 Ethernet connection 1-12...
Page 8 viii Contents Chapter 3: Preparing forFiery S300 Setup Levels of access and control Fiery S300 print connections Passwords Fiery WebTools Control level scenarios Fiery S300 system software About Setup Network server setup requirements Ensuring the copier connection Ensuring virus-free operation of the Fiery S300 on a network 3-10 About the Fiery S300 default password 3-10...
Page 9 ix Contents PostScript Setup options 4-40 Color Setup options 4-41 Administrative functions in the Setup menu 4-44 Job Log Setup 4-44 Exit Setup 4-45 Chapter 5: Setting up the Fiery S300 from a Windows Computer Accessing Setup Local Fiery Setup Remote Fiery Setup General Setup options Job Log Setup...
Page 10 x Contents Chapter 7: Administering the Fiery S300 Administrator functions Setting passwords Passwords from the Control Panel To change the Fiery S300 password Passwords Clearing the Fiery S300 Managing Fiery Address Books Printing a Conﬁguration page from the Control Panel Maintaining optimal Fiery S300 performance 7-10 Starting and shutting down the Fiery S300...
Page 11 xi About this manual This manual is intended for anyone who is responsible for integrating the Introduction Fiery S300 31C-M Color Server into a business environment that includes networked personal computers. After setting up the Fiery S300 31C-M Color Server and client workstations, individual users can print to the Fiery S300 31C-M Color Server as a high-performance color printer.
Page 12: Xii Introduction
xii Introduction About this manual This manual covers the following topics: • Basic conﬁguration of the Fiery S300 to support printing over AppleTalk, TCP/IP, and IPX (Novell) networks • Administering network printing • Conﬁguring Novell and Microsoft Windows NT 4.0/2000 servers and UNIX systems to provide Fiery S300 printing services •...
Page 13: Chapter 1: Connecting To The Network
1-1 Fiery S300 on the network This chapter summarizes the stages in setting up the Fiery S300, and includes Chapter 1: diagrams that refer you to other chapters or other manuals for completing your Connecting installation. Check those references to ﬁnd the information you need quickly. to the Network Fiery S300 on the network When the Fiery S300 is connected to a network, it behaves as a networked PostScript...
Page 14: Stages Of Installation On The Network
1-2 Connecting to the Network Stages of installation on the network Installation can be performed by a network or printing administrator. The stages of a successful installation are: • Physically connecting the Fiery S300 to a functioning network Prepare a network node for the Fiery S300—obtain cable, route it to the location where the Fiery S300 will be installed (near the copier), and attach the cable to the network interface of the Fiery S300.
Page 15 1-3 Stages of installation on the network Summary of Fiery S300 network installation ONNECTION Fiery S300 Prepare a network node. Connect the Fiery S300 to the copier and the network. If you use a computer running Command WorkStation software, connect it to the network.
Page 16: Quick Path To Installation
1-4 Connecting to the Network Quick path to installation The diagrams on the following pages show typical systems you can use to print and run Fiery software from remote workstations. Find the page with your preferred platform and network type, and then look up the setup procedures referenced in the “Key to setup”...
Page 17 1-5 Quick path to installation Mac OS environment with AppleTalk Key to setup: 1 Mac OS computer User Software Installation Guide 2 Fiery Setup Chapter 4 Fiery S300 connected to copier TCP/IP (http) for WebTools AppleTalk Mac OS computer Mac OS computer Mac OS computers can print directly.
Page 18 1-6 Connecting to the Network Windows computers in a Novell environment Key to setup: 1 NetWare server page 2-14 2 Fiery S300 Setup Chapter 4 Another supported 3 NetWare client User Software Installation Guide protocol 4 Windows computer with SPX page 2-9 Fiery S300 connected to copier NetWare server...
Page 19 1-7 Quick path to installation Windows NT 4.0/2000 Server environment Key to setup: 1 Windows NT 4.0/2000 Server page 2-3 2 Fiery S300 Setup Chapter 4 3 Windows NT 4.0/2000/XP Another supported client page 2-6 protocol Fiery S300 connected to copier Windows NT Workstation or Windows NT Server acting as print server...
Page 20 1-8 Connecting to the Network Windows computers using Windows printing Key to setup: 1 Windows computer User Software Installation Guide 2 Fiery S300 Setup Chapter 4 Another supported protocol Fiery S300 connected to copier TCP/IP (nbt) Windows computer Windows computer Windows computer For Windows printing Windows (SMB) printing enabled on the...
Page 21 1-9 Quick path to installation UNIX workstations and Windows computers on a TCP/IP network Key to setup: 1 UNIX server/host page 2-17 2 Fiery S300 Setup Chapter 4 Another supported 3 UNIX workstation page 2-17 protocol 4 TCP/IP client User Software Installation Guide, Chapter 4 5 Windows NT 4.0/2000/XP client...
Page 22: Connecting Network Cable To The Fiery S300
1-10 Connecting to the Network Connecting network cable to the Fiery S300 In this section, the front view and back panel of the Fiery S300 are illustrated, followed by information for connecting to the Ethernet board. Turn off the Fiery S300 before connecting it to any network device. If the Fiery S300 has just ﬁnished processing, wait ﬁve seconds after the system reaches the Idle state before using the power button on the front of the Fiery S300 to turn it off.
Page 23: Back View Of The Fiery S300
1-11 Connecting network cable to the Fiery S300 Back view of the Fiery S300 Dongle 10/100B (RJ-45) THERNET HE LOWER PORT IS UNAVAILABLE FOR USE Copier interface connector...
Page 24: Ethernet Connection
1-12 Connecting to the Network Ethernet connection For Ethernet connections, the Fiery S300 supports cabling, deﬁned as Category 5 for use with 100BaseT; or as Category 3, Category 4, or Category 5 for use with 10BaseT. The cable uses an 8-pin RJ-45 connector that plugs into the RJ-45 socket on the Fiery S300.
Page 25: Chapter 2: Setting Up Network Servers
2-1 Fiery S300 on a TCP/IP network with Windows NT 4.0/2000/XP This chapter describes environments that typically include one or more network Chapter 2: servers—Novell NetWare servers and Windows NT 4.0/2000 servers—that share Setting up printing to the Fiery S300. It describes setting up servers that use IPX/SPX or TCP/IP Network Servers protocols for communicating with the Fiery S300.
Page 26: Tips For Experts-Windows With Tcp/Ip
2-2 Setting up Network Servers Typical system combinations are: • Print server running Windows NT 4.0/2000 Server; clients running Windows NT 4.0/2000/XP Workstation and Windows 9x/Me • Print server running Windows NT 4.0/2000/XP Workstation and clients running Windows 9x/Me With TCP/IP protocols loaded, you can run Fiery utilities and Fiery WebTools from a Windows computer.
Page 27: Conﬁguring A Windows Nt 4.0/2000 Server To Communicate With The Fiery S300
2-3 Fiery S300 on a TCP/IP network with Windows NT 4.0/2000/XP Conﬁguring a Windows NT 4.0/2000 server to communicate with the Fiery S300 To conﬁgure a Windows NT 4.0/2000 server to communicate with the Fiery S300, follow these general steps. More detail is provided in subsequent sections in this chapter and in your Microsoft documentation.
Page 28 2-4 Setting up Network Servers S300 TCP/IP O ADD THE IERY TO A NETWORK WITH A NT 4.0/2000 INDOWS SERVER 1. Register the IP address of the Fiery S300 in the host name database used by your system. For installations that do not have a network administrator or central host name database, add the Fiery S300 to the hosts ﬁle on the Windows NT 4.0/2000 server.
Page 29 2-5 Fiery S300 on a TCP/IP network with Windows NT 4.0/2000/XP Installing the Fiery S300 as a shared printer The ﬁrst step in creating a printer is installing the printer driver ﬁles, which give your applications access to printer features. You can use the installation instructions in the User Software Installation Guide for every workstation that will print directly and independently to the Fiery S300.
Page 30 2-6 Setting up Network Servers Conﬁguring clients of a Windows NT 4.0/2000 server Each client of a Windows NT 4.0/2000 server is already using a network protocol to communicate with the server. Each client can print to the Fiery S300 if it has been shared by a Windows NT 4.0/2000 server or Windows NT 4.0/2000/XP computer.
Page 31 2-7 Fiery S300 on a TCP/IP network with Windows NT 4.0/2000/XP Conﬁguring Windows computers without a Windows NT 4.0/2000 server If your network does not have a Windows NT 4.0/2000 server, Windows 9x/Me and Windows NT 4.0/2000/XP workstations can still print to the Fiery S300. This method of printing is called Windows, or SMB printing.
Page 32: Fiery S300 On A Netware Network
2-8 Setting up Network Servers Fiery S300 on a NetWare network The NetWise ™ features built into the Fiery S300 support the following network operating environments: • NetWare—NDS (Novell Directory Services) • Servers running NetWare in bindery emulation mode The term “Netware” is used to refer to Netware 4.x, 5.x, and 6.x. For Ethernet-based networks, the IPX/SPX protocol is supported.
Page 33: Tips For Experts-Ipx Networks
2-9 Fiery S300 on a NetWare network Tips for experts—IPX networks Setting up the Fiery S300 is similar to setting up any other PostScript printer on the network. The Fiery S300 with IPX connections has the following characteristics: • A minimum connection to the Fiery S300 consists of a NetWare ﬁle server, a NetWare print server, and a NetWare queue.
Page 34: Conﬁguring A Netware Server For Printing
2-10 Setting up Network Servers You do not need to rerun Setup when you add or remove a NetWare queue; however, you should restart the Fiery S300 after you create or remove a queue. When the Fiery S300 is conﬁgured to connect to a NetWare server, it polls the NetWare server for jobs in each of its queues.
Page 35 2-11 Fiery S300 on a NetWare network Conﬁguring an NDS connection Abbreviations: FS = ﬁle server PS = print server PQ = print queue (on the NetWare server) In Setup from On NDS FS On client workstation Command WorkStation In NETADMIN: Port Setup Install user software.
Page 36 2-12 Setting up Network Servers Setting up an NDS connection In NDS, all NetWare entities (objects) are organized in a hierarchical tree structure. Objects have a name, properties, and a context that deﬁnes the location of the object in the directory tree. For the Fiery S300, you are mainly concerned with deﬁning a printer, a print server object, and one or more Print queue objects.
Page 37 2-13 Fiery S300 on a NetWare network Setting up a NetWare Print queue for bindery For NetWare in emulation mode, the NetWare print server and the Fiery S300 Print queue are created and conﬁgured from NetWare Print Console (PCONSOLE), a NetWare utility that is stored in the NetWare PUBLIC directory.
Page 38: Fiery S300 On A Netware Network With Ndps
2-14 Setting up Network Servers Fiery S300 on a NetWare network with NDPS The Fiery S300 supports printing over a NetWare 5.x or later network running either the TCP/IP protocols or the IPX protocol. For pure IP printing, the Fiery S300 takes advantage of features in NDPS (Novell Distributed Print Services).
Page 39: Conﬁguring A Netware Server For Printing With Ndps
2-15 Fiery S300 on a NetWare network with NDPS Conﬁguring a NetWare server for printing with NDPS Before you begin The following procedure assumes NDPS has been installed during NetWare 5.x or later installation and that a Broker is running on the server. Unless you have manually unloaded the Broker, it loads and runs when you install NDPS.
Page 40 2-16 Setting up Network Servers O SET UP THE PRINTER DRIVER FOR INDOWS 1. Log on to the Novell ﬁle server as a superuser or Administrator. 2. In the SYS:ndps\resdir\Prndrv\Win9x/Me directory, create a folder called Fiery. 3. From the User Software CD, copy the contents of the ENGLISH\INSTALRS\PS_DRVR\WIN_9x/Me folder to the Fiery directory.
Page 41: Fiery S300 On A Network With Unix Workstations
2-17 Fiery S300 on a network with UNIX workstations 5. Under Gateway Types, select Novell Printer Gateway, and click OK. 6. In the Conﬁgure Novell PDS for Printer Agent dialog box, select “((NONE))”, and click OK. 7. In the Conﬁgure Port Handler dialog box, choose “Remote LPR on IP” as the connection type and click Next.
Page 42: Tips For Experts-Unix Workstations
2-18 Setting up Network Servers Tips for experts—UNIX workstations Setting up the Fiery S300 in a UNIX environment has the same requirements as setting up any printer or new device: • A distinct IP address is required for the Fiery S300 as well as for each workstation on the network.
Page 43: Setting Up The Fiery S300 On Tcp/Ip Networks
2-19 Fiery S300 on a network with UNIX workstations Setting up the Fiery S300 on TCP/IP networks Every machine (host) on a TCP/IP network, including the Fiery S300, must have a unique 32-bit internet address (IP address). Contact your network administrator to obtain an address for the Fiery S300.
Page 44 2-20 Setting up Network Servers 4. To verify the TCP/IP connection, ping the IP address or the host name. From any computer on the network, at the command prompt, type: ping <IP address> Type the Fiery S300 IP address assigned in Fiery S300 Network Setup. After the Fiery S300 is set up as a network printer, you can also ping the name you gave to the Fiery S300: ping <hostname>...
Page 45: Managing Print Jobs
2-21 Fiery S300 on a network with UNIX workstations Managing print jobs UNIX network administrators can use UNIX utilities for viewing the list of jobs, and for printing and removing jobs that are spooled to UNIX servers. If the network includes a Windows NT 4.0/2000/XP workstation that has TCP/IP protocols loaded, you can use Command WorkStation or Fiery Downloader ™...
Page 47: Levels Of Access And Control
3-1 Levels of access and control To prepare for printing at your site, you must do some initial Fiery S300 Chapter 3: conﬁguration, or Setup, to specify the network environment and the kind of printing Preparing for you will do. Before you perform Setup, you must decide the levels of access you will Fiery S300 implement for your site.
Page 48 3-2 Preparing for Fiery S300 Setup In addition, you can enable the Printed queue, which is a storage area for the most recent jobs from the Print queue. The Printed queue makes it convenient to reprint those jobs. In Setup, you can enable the Printed queue and specify the maximum number of jobs retained in the queue (see page 4-16).
Page 49: Passwords
3-3 Levels of access and control Passwords You can implement passwords as a means of controlling access to Fiery S300 functions. The Fiery S300 allows you to set the following passwords in Setup: ™ • Administrator—from the Control Panel, WebSetup , or Command WorkStation (or local Setup, if you have installed the Fiery Advanced Controller Interface) •...
Page 50: Fiery Webtools
3-4 Preparing for Fiery S300 Setup Fiery WebTools The Fiery S300 can support Internet or intranet access from Windows computers with Fiery WebTools. To enable use of Fiery WebTools, you must do the following in Setup: • Enable TCP/IP. • Set an IP address, subnet mask, and gateway address for the Fiery S300. •...
Page 51 3-5 Levels of access and control WebLink WebLink provides all users with a link to an address on the Internet. To change the WebLink Internet address, see page 6-3. This function requires the Administrator password, if one has been set (see “Passwords”...
Page 52: Control Level Scenarios
3-6 Preparing for Fiery S300 Setup Control level scenarios Typical scenarios of access and control, ranging from minimum control to maximum control, are described in this section. Choose the scenario that best matches your site requirements, and then refer to the corresponding number in the table for guidance on how to conﬁgure your system for those requirements.
Page 53: Fiery S300 System Software
3-7 Fiery S300 system software 5. An administrator and an operator; operator controls all jobs; no WebTool access (Maximum control) Only an administrator can perform Setup, calibration, and other administrator functions, and only an operator or administrator can control jobs from the job management tools;...
Page 54: About Setup
3-8 Preparing for Fiery S300 Setup • Command WorkStation—Command WorkStation is the interface tool for the Server. It provides a graphical interface for viewing and controlling Server functions. About Setup Setup conﬁgures the Fiery S300 to communicate with other devices and manage print jobs.
Page 55: Ensuring The Copier Connection
3-9 About Setup You must conﬁgure the Fiery S300 with the correct Windows NT 4.0/2000 domain name. This is especially important for Windows printing, also known as SMB printing. For Fiery S300 systems that include the Fiery Advanced Controller Interface, click Start and then choose Settings >...
Page 56: Ensuring Virus-Free Operation Of The Fiery S300 On A Network
3-10 Preparing for Fiery S300 Setup Ensuring virus-free operation of the Fiery S300 on a network The Fiery S300 is prone to computer viruses since it uses Windows NT system architecture. We highly recommend that a network administrator periodically run an anti-virus program on the Fiery S300 to ensure network security in your environment.
Page 57 3-11 About Setup S300 O CHANGE THE IERY DEFAULT PASSWORD 98/M FROM WINDOWS 1. Click Start in the Window 98/Me taskbar, choose Programs, and then choose MS-DOS Prompt. The MS-DOS Prompt window appears. 2. At the command prompt, type the following. For example, if you want to change to “Fiery.2”: >...
Page 58 3-12 Preparing for Fiery S300 Setup 2. In the Windows Security dialog box, click Change Password, and then enter the following: For example, if you want to change to “Fiery.2”: For User name, administrator For Domain (Windows NT 4.0) or Log on to (Windows 2000/XP),\\Fiery S300 name For Old Password, Fiery.1 For New Password, Fiery.2 For Conﬁrm New Password, Fiery.2...
Page 59: Chapter 4: Performing Setup From The Control Panel
4-1 Fiery S300 Setup from the Control Panel Setup is required the ﬁrst time the Fiery S300 is turned on after new system software is Chapter 4: loaded. If you do not conﬁgure a particular Setup option, the Fiery S300 uses default Performing settings.
Page 60 4-2 Performing Setup from the Control Panel The Control Panel on the front of the Fiery S300 allows you to set options and view information about jobs printed to the Fiery S300. It comprises the following parts: • Activity light—indicates normal or problem activity •...
Page 61 4-3 Fiery S300 Setup from the Control Panel Front view of the Fiery S300 (with cover door off) DVD ROM drive Power button Reset button...
Page 62: Fiery S300 Control Panel
4-4 Performing Setup from the Control Panel Fiery S300 Control Panel Use the Fiery S300 Control Panel to view status information, print special pages, and set up printing. While most elements in the Control Panel display have counterparts in Command WorkStation, you can view current functions on the Control Panel even when Command WorkStation is not connected to the server or is not running.
Page 63: Activity Light
4-5 Fiery S300 Control Panel Activity light The activity light indicates the current Fiery S300 activity. If the light is: Solid red An error has occurred, causing the Fiery S300 to be disabled. Flashing red An error has occurred, causing printing to be disabled, but the Fiery S300 is capable of processing.
Page 64: Display Window
4-6 Performing Setup from the Control Panel Display window The display window provides information about the status of the Fiery S300, displays menu information, and allows you to view and edit information in the Setup menus. The status area at the bottom of the display window displays the screen name and highlights one of the icons to indicate what the Fiery S300 is doing.
Page 65 4-7 Fiery S300 Control Panel Info Status When the Fiery S300 is not processing or printing a job, it displays information about the current server and software: —The Fiery S300 name, as it is conﬁgured in Setup. Server Name —The current status of the Fiery S300. The Fiery S300 status can be: Idle, Status Initializing, Busy, Processing, or Printing.
Page 66: Functions Menu
4-8 Performing Setup from the Control Panel Functions menu The Functions menu provides many of the options available from Command WorkStation. Choose the following commands from this menu: Print Pages Print special pages from the Fiery S300. You can print the following pages from the submenu that appears: —A Test Page allows you to conﬁrm that the Fiery S300 is properly Test Page...
Page 67 4-9 Fiery S300 Control Panel Suspend Printing Suspend communication between the Fiery S300 and the copier. Resume Printing Resume communication between the copier and the Fiery S300. Shut Down Shut down all Fiery S300 activity in the correct manner and then restart. Use this option instead of the power switch on the back of the Fiery S300.
Page 68: Accessing Setup Options
4-10 Performing Setup from the Control Panel Accessing Setup options S300 O ACCESS ETUP WHEN THE IERY 1. Make sure the information screen on the Control Panel reads Idle. If Printing or RIPping appears, the Fiery S300 is processing, and you must wait until the system ﬁnishes and reaches the Idle state.
Page 69: About The Control Panel Setup Interface
4-11 Fiery S300 Control Panel About the Control Panel Setup interface When you perform Setup from the Control Panel, you can select one menu after another and enter information about your Fiery S300 and your network and printing environment. In each Setup screen, the last line of the display window shows the name of the current Setup menu.
Page 70: Types Of Setup Screens
4-12 Performing Setup from the Control Panel Types of Setup screens There are two types of Setup options: Multiple choice You are given choices (for example, Yes or No, or a list questions of options from which to choose). Only one choice is displayed at a time, in highlighted text.
Page 71 4-13 Fiery S300 Control Panel Example: Multiple choice Publish Print Queue Publish Print Queue Printer Setup Printer Setup Press the up or down When the setting you want arrow buttons to display the appears, press the button other option or options. beside OK to continue.
Page 72: Server Setup Options
4-14 Performing Setup from the Control Panel If you make a mistake during Setup, you can always use the Menu button to cancel without saving changes. Pressing the Menu button cancels what you are doing in the current screen to bring you to the next higher-level menu. You may need to press Menu more than once to return to the top level for the particular Setup in which you are working.
Page 73 4-15 Server Setup options System Time Enter the correct system time. Enter the time based on the 24-hour clock in the form HH:MM (Hours:Minutes). The time appears on the Job Log. Print Start Page Yes/No [Yes] Specify whether the Fiery S300 should print a start page every time it restarts. The start page displays information about the Fiery S300, including the server name, current date and time, amount of memory installed in the Fiery S300, network protocols enabled, and connections published.
Page 74: Network Setup Options
4-16 Performing Setup from the Control Panel Jobs Saved in Printed Queue 1-99 [10] This option appears only if Enable Printed Queue is set to Yes. Specify the number of jobs to be stored in the Printed queue. Jobs in the Printed queue take up space on the Fiery S300 hard disk.
Page 75 4-17 Network Setup options If the Fiery S300 is configured to enable more than one protocol, it automatically switches to the correct protocol when it receives a print job. The available network types, and the Setup areas that pertain to them, are summarized in the following table.
Page 76: Port Setup Options
4-18 Performing Setup from the Control Panel 7. When you have ﬁnished entering protocol settings, choose Exit Protocol Setup, and then choose Service Setup. 8. Enter the appropriate settings for the services you will use. The options are described in detail in the following pages. O EXIT ETWORK ETUP...
Page 77: Protocol Setup Options
4-19 Network Setup options Protocol Setup options To conﬁgure the Fiery S300, choose each protocol and enter the settings for that Exit Protocol Setup AppleTalk Setup protocol. You can enable AppleTalk, TCP/IP, and IPX/SPX communication TCP/IP Setup simultaneously. IPX/SPX Setup Protocol Setup Network Setup Protocol Setup...
Page 78 4-20 Performing Setup from the Control Panel TCP/IP Setup with Ethernet Network Setup Protocol Setup TCP/IP Setup Ethernet Setup Enable TCP/IP for Ethernet Yes/No [Yes] Select Yes if you have a TCP/IP network connected to the Fiery S300 over Ethernet cabling. If you are using TCP/IP for printing from Windows computers, enabling TCP/IP here also enables you to use Fiery utilities from Windows computers using TCP/IP protocols.
Page 79 4-21 Network Setup options IP Address [127.0.0.1] Enter the Fiery S300 IP address for Ethernet. This IP address, unlike an IP address set automatically, remains the same if you restart the Fiery S300. You must change the default to a valid address for your network. For information about setting up printing with TCP/IP, see Chapter Subnet Mask...
Page 80 4-22 Performing Setup from the Control Panel IPX/SPX Setup options To specify the frame types the Fiery S300 uses for IPX/SPX protocols, choose Exit Protocol Setup AppleTalk Setup IPX/SPX Setup from the Protocol Setup menu. You must choose at least one frame TCP/IP Setup IPX/SPX Setup type to enable IPX/SPX protocols.
Page 81: Service Setup Options
4-23 Network Setup options Clear Frame Types You can clear all frame types at once by choosing Exit IPX/SPX Setup, choosing IPX/SPX Setup, and then choosing Clear Frame Types. Service Setup options PServer is a program in the Fiery S300 software that can service the Novell Print queues assigned to the Novell print servers you have set up for printing to the Fiery S300.
Page 82 4-24 Performing Setup from the Control Panel Network Setup Service Setup PServer Setup NDS Setup Before entering NDS settings, make sure the Fiery S300 is connected to the network and that you have conﬁgured an NDS directory tree with a printer, print server, and one or more Print queue objects for Fiery S300 jobs (see page 2-13).
Page 83 4-25 Network Setup options Is user login needed to browse NDS tree? Yes/No [No] Select No if no password is required to browse the tree. You can proceed to navigate to the Print Server object. Select Yes if network permissions require that you log in to browse the NDS tree and see the Print Server object you want to select.
Page 84 4-26 Performing Setup from the Control Panel Enter Password Enter the login password for the NDS tree, using the up and down arrow buttons to select characters, and the left and right arrow buttons to move the cursor. Choose OK. Navigate the NDS tree to the Print Server.
Page 85 4-27 Network Setup options Server should look for print queues in: Entire NDS Tree/Specified Subtree [Entire NDS Tree] By default, the Fiery S300 searches the entire NDS tree for Fiery S300 print connections. This option lets you restrict the search for Fiery S300 print jobs to a subtree (the Print Queue root) in which the Fiery S300 print connections have been deﬁned.
Page 86 4-28 Performing Setup from the Control Panel Bindery Setup options Network Setup Service Setup PServer Setup Bindery Setup Use Bindery Setup if you have already conﬁgured one or more bindery servers (ﬁle servers running NetWare in bindery emulation) with a Print Server and a Print Queue for Fiery S300 jobs.
Page 87 4-29 Network Setup options Network Setup Service Setup PServer Setup Bindery Setup Add File Server This option gives you two ways to add a Novell NetWare ﬁle server. Select File Server From List/Search by Name [From List] You may select the ﬁle server from a scrollable list, or by a name search. Choose From List if your network does not have a large number of ﬁle servers.
Page 88 4-30 Performing Setup from the Control Panel File Server Login administrator/supervisor/Enter Login Name [supervisor] This option appears only if a password is required for login, if there is no guest account, or the guest account is restricted. Choose Enter Login Name to enter your own login name and password or log in as a guest.
Page 89 4-31 Network Setup options Network Setup Service Setup PServer Setup Bindery Setup View Server List Supported servers This option allows you to view the list of ﬁle servers currently connected to the Fiery S300—that is, servers you have added in Bindery Setup. You are notiﬁed if there are none.
Page 90 4-32 Performing Setup from the Control Panel Enter Your Print Server Password This option appears only if your NetWare print server is password-protected. Enter your print server password. The Bindery Setup menu is displayed again. You can edit other connections, choose another Bindery Setup option, or choose Exit Bindery Setup.
Page 91 4-33 Network Setup options Polling Interval options Network Setup Service Setup PServer Setup Polling Interval Whether you use NDS or Bindery services, choose Polling Interval from the main PServer Setup menu. If you do not reset the interval, the default value of 15 seconds is used.
Page 92 4-34 Performing Setup from the Control Panel Use Automatic Configuration Yes/No [Yes] This option appears if you chose DHCP or BOOTP as the protocol for automatically obtaining the IP address of the Fiery S300. Choose Yes and the Fiery S300 uses a WINS name server and automatically obtains its IP address.
Page 93 4-35 Network Setup options Set Domain Name Select from list/Enter manually [Select from list] This option provides two ways to specify the workgroup or domain in which you want the Fiery S300 to appear. If you selected If you selected Select from list Enter manually Choose Domain...
Page 94 4-36 Performing Setup from the Control Panel Port 9100 Setup Network Setup Service Setup Port 9100 Setup Enable Port 9100 Yes/No [Yes] This option enables applications to open a TCP/IP socket to the Fiery S300 at Port 9100 to download a print job. Port 9100 Queue Direct/Print Queue/Hold Queue Specify the Fiery S300 print connection for downloading jobs to Port 9100.
Page 95 4-37 Network Setup options Incoming Server [127.0.0.1] [mailservername] Enter the IP address name of the server (POP3/IMAP) on your network that handles incoming e-mail. Server Type POP3/IMAP [POP3] Choose the type of mail server. Fiery E-mail User Name Enter the user name of the e-mail account. This is typically the part of the e-mail address that precedes the @ symbol.
Page 96 4-38 Performing Setup from the Control Panel Administrator E-mail Domain Name Enter the name of the domain in which the administrator has an account. This is typically the part of the e-mail address that follows the @ symbol. For example, in the address , the domain name is pat@test.com...
Page 97: Printer Setup Options
4-39 Printer Setup options Printer Setup options Printer Setup conﬁgures the connections and printing behavior associated with a particular printing device. For more information on Fiery S300 print connections, page 3-1. O ACCESS PRINTER SETUP OPTIONS 1. In the main Setup menu, choose Printer Setup. Exit Setup Server Setup Network Setup...
Page 98: Postscript Setup Options
4-40 Performing Setup from the Control Panel Save Changes Yes/No [Yes] Select Yes to activate any changes made in the Printer Setup; select No to return to the main Setup menu without making any changes. PostScript Setup options PS (PostScript) Setup allows you to set defaults for the Fiery S300. Users can override most of these defaults on a job-by-job basis.
Page 99: Color Setup Options
4-41 Color Setup options Print to PS Error Yes/No [No] Specify whether the Fiery S300 should print the available portion of a print job when it encounters a PostScript error. Select Yes to print the portion of the job that was processed before the error occurred;...
Page 100 4-42 Performing Setup from the Control Panel O ACCESS OLOR ETUP OPTIONS In the list of options that follows, default values, where applicable, appear in square brackets. RGB Source Profile EFIRGB/sRGB (PC)/Apple Standard/None [EFIRGB] The RGB source is the color space used to control color for conversion from monitor to printed output.
Page 101 4-43 Color Setup options CMYK Simulation Method Quick/Full (Source GCR)/Full (Output GCR) [Full (Source GCR)] Quick simulation assumes that the copier toners match the printer’s inks, and all changes affect only one color (C, M, Y, or K) at a time. Full (Source GCR) simulation allows for more ﬂexibility in matching toner to ink and all changes interact to maintain a better color balance.
Page 102: Administrative Functions In The Setup Menu
4-44 Performing Setup from the Control Panel Save Changes Yes/No [Yes] Select Yes to activate any changes made in Color Setup; select No to return to the main Setup menu without making any changes. Administrative functions in the Setup menu The remaining choices in the Setup menu are intended to help you manage print jobs and color output but are not required for printing.
Page 103: Exit Setup
4-45 Administrative functions in the Setup menu Auto Print Job Log Every 55 Jobs Yes/No [No] Use this option to specify whether the Fiery S300 prints the Job Log after every 55 jobs. Setting the Job Log for automatic printing is useful if accounting for each printed page is important at your site.
Page 105: Chapter 5: Setting Up The Fiery S300 From A Windows Computer
5-1 Accessing Setup After you perform initial Setup (Server, Network, and Printer Setup) from the Control Chapter 5: Panel, you can change most Setup options from a Windows computer. Setting up the Fiery S300 from Accessing Setup a Windows In addition to using the Control Panel, you can set up the Fiery S300 two ways: locally Computer and remotely.
Page 106: Local Fiery Setup
5-2 Setting up the Fiery S300 from a Windows Computer Local Fiery Setup You can access Fiery S300 Server Setup in any of the following ways: • Right-click the FieryBar on the Windows NT 4.0 desktop and choose Set Up Fiery. •...
Page 107: Remote Fiery Setup
5-3 Accessing Setup Remote Fiery Setup You can access remote Setup from Command WorkStation. O ACCESS ETUP FROM OMMAND TATION 1. Start the Command WorkStation application. 2. Log in as Administrator. 3. Choose Setup from the Server menu.
Page 108: General Setup Options
5-4 Setting up the Fiery S300 from a Windows Computer General Setup options You can specify Fiery S300 system settings that affect all users, such as the name of the Fiery S300, system date and time, passwords, and Job Log printing. The interface of local Fiery S300 Setup and remote Setup is similar.
Page 109 5-5 General Setup options If you are using local Setup, click Modify, click Change, and then type the Server Name in the Computer Name ﬁeld. Do not use the device name ( 31C-M ) as the server name. If you have more than one Fiery S300, do not give them the same name.
Page 110: Job Log Setup
5-6 Setting up the Fiery S300 from a Windows Computer Job Log Setup —Specify whether the Fiery S300 prints the Job Log Auto Print Job Log every 55 Jobs after every 55 jobs. The Job Log lists the last 55 jobs processed on the Fiery S300, with accounting information about each one, including user name, document name, time and date printed, number of pages, and other job information.
Page 111: Network Setup
5-7 Network Setup Network Setup Network Setup conﬁgures the Fiery S300 to receive print jobs over the networks used at your site. If the Fiery S300 is conﬁgured to enable more than one protocol, it automatically switches to the correct protocol when it receives a print job. When two network ports are enabled, print jobs can be received over all ports at the same time.
Page 112: Adapters/Ports
5-8 Setting up the Fiery S300 from a Windows Computer Adapters/Ports In local Setup only, the installed network boards are displayed. You cannot change this information. From remote Setup, you can enable Ethernet. These options are described in the following section. Ethernet (Port Setup) —Select to connect the Fiery S300 to an Ethernet network.
Page 113: Protocols
5-9 Protocols Protocols You can change AppleTalk, IPX/SPX, and TCP/IP protocol settings for the Fiery S300. From remote Setup, you change these settings on the Protocol1 and Protocol2 tabs. Local Setup works in conjunction with the Windows NT Network Control Panel. When you click Modify or Advanced next to the setting in local Setup, the system opens the Network Control Panel, where you complete the settings.
Page 114 5-10 Setting up the Fiery S300 from a Windows Computer Unlike remote Setup, local Setup does not provide separate settings for enabling and conﬁguring a protocol. For example, remote Setup has two settings for AppleTalk: one to enable AppleTalk and the other to set the AppleTalk zone. In local Setup, there is only the setting for AppleTalk zone.
Page 115 5-11 Protocols AppleTalk The current AppleTalk zone is displayed.
Page 116 5-12 Setting up the Fiery S300 from a Windows Computer IPX/SPX Use this option to specify IPX/SPX frame types. The Fiery S300 supports the following Ethernet frame types for IPX/SPX: Ethernet 802.2, Ethernet 802.3, Ethernet II, and Ethernet SNAP. You can also allow the Fiery S300 to select the frame type automatically.
Page 117 5-13 Protocols TCP/IP Specify TCP/IP settings. The current settings for IP address, subnet mask, and default gateway address are displayed. For information about setting up printing with TCP/IP, see Chapter 2. The Fiery S300 requires a unique, valid IP address. You can set a static address or specify that the Fiery S300 use DHCP or BOOTP to obtain IP addresses automatically.
Page 118 5-14 Setting up the Fiery S300 from a Windows Computer To set the subnet mask, enter one of the following values: 255.0.0.0 if the IP address starts with a number less than 128 if the IP address starts with a number from 128 through 191 255.255.0.0 if the IP address starts with a number greater than 191 255.255.255.0...
Page 119: Services
5-15 Protocols Services You can conﬁgure the following network services: —enable or disable LPD print services. LPD Printing (TCP/IP) —specify NDS and Bindery services (see page 5-16). NetWare Printing (PServer) —enable or disable SMB print services. Windows Print Sharing (SMB) —enable or disable support for WebTools.
Page 120 5-16 Setting up the Fiery S300 from a Windows Computer LPD Printing —Select to enable or disable LPD printing services. Enable LPD Print Services —Select to enable or disable Port 9100 printing services. Enable Port 9100 —Select to enable or disable web services. Enable Web Services NetWare Printing (PServer) options The following procedures for setting up NetWare printing depict the windows from...
Page 121 5-17 Protocols Setting up the Fiery S300 for NDS printing Only one NDS tree can be connected. To specify or change the NDS Tree, click Modify and specify settings in the NDS Print Server dialog box, as follows. The currently selected NDS Tree and Print Server are displayed. S300 S O SPECIFY THE TREE SETTING FROM LOCAL...
Page 122 5-18 Setting up the Fiery S300 from a Windows Computer 2. In the NDS Connection dialog box that appears, double-click an NDS tree in the list on the left. 3. Navigate to the NDS container and click OK. If necessary, enter the password.
Page 123 5-19 Protocols 4. Select a container from the Containers list. 5. Double-click a print server from the Select Print Server list. The full path to the print server appears. Another way to change the path is to click Edit and type the path to the print server.
Page 124 5-20 Setting up the Fiery S300 from a Windows Computer 6. Click OK. The Server Setup dialog box appears, displaying the path to the selected print server on the Network Setup tab.
Page 125 5-21 Protocols S300 S O SPECIFY THE TREE SETTING FROM REMOTE IERY ETUP 1. Select Enable NDS and click Change Trees. 2. In the NDS Conﬁguration window that appears, double-click an NDS tree in the Available Trees list.
Page 126 5-22 Setting up the Fiery S300 from a Windows Computer 3. In the Select User Login window, select Use Default User Information or enter your password, and click Next. 4. Navigate to the NDS container, select it, and click Next. If necessary, enter the password.
Page 127 5-23 Protocols 5. Select Use Default Print Queue Root or navigate to the Print Queue Root and click Finish.
Page 128 5-24 Setting up the Fiery S300 from a Windows Computer 6. Click OK. The NDS Conﬁguration window appears, displaying information about the print server.
Page 129 5-25 Protocols Bindery Setup From the Network Setup tab, specify Bindery services. The currently connected servers are displayed. A maximum of eight bindery servers can be connected. To add, remove, or change bindery connections, click Modify and specify settings in the Bindery Connections dialog box, as described in the following procedures.
Page 130 5-26 Setting up the Fiery S300 from a Windows Computer S300 S O ADD BINDERY CONNECTIONS FROM LOCAL IERY ETUP 1. Click Modify in the Bindery Setup dialog box. The Bindery Connections dialog box appears. 2. Select a ﬁle server from the Select File Server list. If the File Server User Name and Password dialog box appears, enter the appropriate user name and password to log on to the selected ﬁle server.
Page 131 5-27 Protocols 3. Select a print server from the Select Print Server list, and click Add. The name of the newly added server appears in the Connected Servers list. To add another server, repeat the preceding steps. You can connect a maximum of eight servers.
Page 132 5-28 Setting up the Fiery S300 from a Windows Computer 4. When you ﬁnish adding servers, click OK. When you return to the Network Setup tab, the connected servers appears in the Bindery Setup area.
Page 133 5-29 Protocols S300 S O REMOVE BINDERY CONNECTIONS FROM LOCAL IERY ETUP 1. Click Modify in the Bindery Setup dialog box. The Bindery Connections dialog box appears. 2. Make your selections in the Select File Server and Select Print Server lists. The name of the connected server appears in the Connected Servers list.
Page 134 5-30 Setting up the Fiery S300 from a Windows Computer S300 S O ADD BINDERY CONNECTIONS FROM REMOTE IERY ETUP 1. Select Enable PServer mode from the Service1 tab. 2. Click Bindery Setup. 3. Select a ﬁle server from the Available Servers list. If the File Server User Name and Password dialog box appears, enter the appropriate user name and password to log on to the selected ﬁle server.
Page 135 5-31 Protocols 4. Select a print server from the list and click Finish. If necessary, enter the appropriate password in the Print Server Password dialog box to log on to the selected ﬁle server. The name of the newly added server appears in the Selected Servers list. 5.
Page 136 5-32 Setting up the Fiery S300 from a Windows Computer S300 S O REMOVE BINDERY CONNECTIONS FROM REMOTE IERY ETUP 1. Select Enable PServer mode from the Service1 tab. 2. Click Bindery Setup. The Novell Setup dialog box appears. 3. Make your selection in the Selected Servers list. 4.
Page 137 5-33 Protocols Poll Interval (local Setup) or PServer Poll Interval (remote Setup) Specify the polling interval (in seconds) for NetWare printing.
Page 138: Windows Print Sharing With Server Message Block (Smb)
5-34 Setting up the Fiery S300 from a Windows Computer Windows Print Sharing with Server Message Block (SMB) For setting up the Windows printing service, text ﬁelds may include uppercase letters, numerals, spaces, and the following characters: - _ . ~ ! @ # $ % ^ & ( ) { } \ ' , " Lowercase letters are not allowed, except in the Comment ﬁeld.
Page 139 5-35 Protocols —Enter the workgroup or domain where the Fiery S300 Domain or Workgroup should appear. —Enter the IP address of the Ethernet WINS name server. Ethernet WINS Server Broadcasts from SMB devices cannot be routed beyond their original network segment without a WINS name server.
Page 140: Printer Setup Options
5-36 Setting up the Fiery S300 from a Windows Computer Printer Setup options You can specify the following settings in the Printer Setup tab: • Printer Connections • PS (PostScript) Setup • Color Setup In the following illustrations, “Device name” represents the model of the copier connected to the Fiery S300, which is 31C-M Printer connections...
Page 141: Ps (Postscript) Setup
5-37 Printer Setup options PS (PostScript) Setup In the following illustrations, “Device name” represents the model of the copier connected to the Fiery S300, which is 31C-M —Specify whether to print color (CMYK) or Grayscale images to the Color Mode Fiery S300 by default.
Page 142: Color Setup
5-38 Setting up the Fiery S300 from a Windows Computer —Specify whether to convert paper sizes in documents Convert Paper Sizes automatically to the default paper sizes specified. For example, if you select Letter/11 17->A4/A3, a letter size job is automatically printed on A4 paper. If you select No, the Fiery S300 prints the job only if it ﬁnds a media source in the size speciﬁed by the job.
Page 143: Exiting Setup
5-39 Exiting Setup —Specify the RGB source space to be applied to RGB data. RGB Source Proﬁle —Specify the Rendering Style to be applied to RGB data. Rendering Style —Specify the simulation to be applied to CMYK data. CMYK Simulation Proﬁle —Specify the simulation method to be used.
Page 144: Printing The Conﬁguration Page
5-40 Setting up the Fiery S300 from a Windows Computer Printing the Conﬁguration page The Conﬁguration page lists the settings in effect for the current Setup. After you have performed Setup, print a Conﬁguration page to conﬁrm your settings. The other pages you can print from Command WorkStation include the Test Page, Job Log, color charts, and Font List.
Page 145: Chapter 6: Conﬁguring Fiery Webtools
6-1 Conﬁguring the Fiery S300 and clients for WebTools Fiery WebTools allow you to manage your Fiery S300 remotely from the Internet or Chapter 6: from your company’s intranet. The Fiery S300 has its own home page, from which you Conﬁguring can select a variety of functions, including Status, WebSetup, WebSpooler, WebLink, Fiery WebTools...
Page 146: Setting Up Webtools
6-2 Conﬁguring Fiery WebTools O ACCESS OOLS 1. Start your Internet browser. 2. Enter the IP address or DNS name of the Fiery S300. 3. Press Enter. The Fiery S300 home page appears. 4. Click the name of a particular WebTool. 5.
Page 147: Setting The Weblink Destination
6-3 Setting the WebLink destination Setting the WebLink destination You can change the pre-set WebLink destination; this function requires the Administrator password, if one has been set. O CHANGE THE INK DESTINATION 1. Start your Internet browser. 2. Enter the IP address or the DNS name of the Fiery S300. The Fiery S300 home page appears.
Page 149: Chapter 7: Administering The Fiery S300
7-1 Administrator functions This chapter provides tips on managing Fiery S300 printing. Chapter 7: Administering Administrator functions the Fiery S300 Administration features are included with the user software and are built into the Fiery S300 itself. The following table describes where to ﬁnd information on these features (page references refer to this manual).
Page 150: Setting Passwords
7-2 Administering the Fiery S300 For these operations And these tasks Getting users started Printing to the Fiery S300 Printing Guide with printing Setting job-speciﬁc options Using Fiery utilities Job Management Guide Controlling the job ﬂow Using WebTools, Command WorkStation and Fiery Printing Guide utilities and for managing job priorities, tracking current Job Management Guide...
Page 151: Passwords From The Control Panel
7-3 Setting passwords Passwords from the Control Panel For more information on Administrator access privileges, see page 3-3. For information on controlling print jobs with the job management tools, see the Job Management Guide. The Operator password can be set and changed only from Command WorkStation.
Page 152: Passwords
7-4 Administering the Fiery S300 Passwords You can set, change, and remove passwords for the Fiery S300. These passwords, speciﬁc to the Server process, have different uses than the Windows NT Administrator and Operator passwords. Keep careful track of the passwords you set for each. —Controls access to Setup;...
Page 153: Clearing The Fiery S300
7-5 Clearing the Fiery S300 O REMOVE A PASSWORD 1. Select the password you want to delete. 2. Delete the asterisks (*) in both the Enter New Password and Verify New Password ﬁelds. If you forget the Administrator password, contact your authorized service representative to reinstall Fiery S300 system software.
Page 154: Managing Fiery Address Books
7-6 Administering the Fiery S300 Managing Fiery Address Books The E-mail Service feature allows an administrator to import a list of e-mail addresses to the Fiery S300. This is done by sending messages to the Fiery S300 in e-mail form. The list will be added to the Fiery Address Books, designed for use in sending scan ﬁles to a particular e-mail address the user chooses at the Fiery S300 Control Panel and in controlling user access to E-mail Services.
Page 155 7-7 Managing Fiery Address Books The administrator can manage the address books by sending an e-mail to the Fiery S300 with command codes in the subject and message ﬁelds. The Fiery S300 responds by e-mail to these commands with information about each request. When managing address books, see the following table.
Page 156 7-8 Administering the Fiery S300 Fiery e-mail Fiery e-mail Administrator subject Task Administrator message ﬁeld response subject response message ﬁeld ﬁeld ﬁeld To delete #DeleteAddressFrom name name@domain Removed from Deleted Address 1 an address of address book Address Book name Deleted Address 2 from an “display name”...
Page 157: Printing A Conﬁguration Page From The Control Panel
7-9 Printing a Conﬁguration page from the Control Panel Printing a Conﬁguration page from the Control Panel The Conﬁguration page lists all the settings in effect in the current Setup. After you have ﬁnished running Setup, print a Conﬁguration page to conﬁrm your settings.
Page 158: Maintaining Optimal Fiery S300 Performance
7-10 Administering the Fiery S300 Maintaining optimal Fiery S300 performance The Fiery S300 does not require maintenance. Beyond the obvious requirements of servicing and maintaining the copier and replenishing consumables, you can improve the overall performance of your system by doing the following: •...
Page 159: Starting And Shutting Down The Fiery S300
7-11 Starting and shutting down the Fiery S300 Starting and shutting down the Fiery S300 Generally, you can leave the Fiery S300 running all the time. This section describes how to shut down and restart the Fiery S300 when necessary. Starting the Fiery S300 To start the Fiery S300, press the power button on the front of the Fiery S300.
Page 160: Restart The Fiery S300
7-12 Administering the Fiery S300 If an Administrator password has been set, you are required to enter it to access Setup. When you access Setup, the following options appear. Choose To do this Exit Setup Exit the Setup menus; the Fiery S300 restarts. Server Setup Enter the Server Setup menus.
Page 161: Rebooting The Fiery S300
7-13 Starting and shutting down the Fiery S300 Rebooting the Fiery S300 Use the following procedure to reboot the Fiery S300. Reboot System shuts down and restarts the Fiery S300 system software and operating system. S300 O REBOOT THE IERY 1.
Page 162 7-14 Administering the Fiery S300 3. Use the down arrow button to scroll to the last screen, and choose Shut Down. 4. Use the line selection button to choose Shut Down System. Proceed to the next step when the screen displays the message, “It is now safe to power off the server.”...
Page 163: Appendix A: Troubleshooting
A-1 Troubleshooting This chapter provides troubleshooting tips. Appendix A: Troubleshooting Troubleshooting the Fiery S300 Startup diagnostics are described in the Installation and Service Guide for service technicians. Contact your authorized service/support center if you see any startup error messages on Command WorkStation or if the Fiery S300 does not reach the Idle state. Troubleshooting during Setup from the Control Panel The following section explains some error and alert messages you may see during Setup that may not be self-explanatory.
Page 164 A-2 Troubleshooting After this Setup screen This message Means Enable NDS No NDS trees found. No NDS trees were found on the Novell network. Check to see that the frame types on the Fiery S300 are (Network Setup>Service properly conﬁgured. Setup >PServer Setup >NDS Setup) Select NDS Tree...
Page 165 A-3 Troubleshooting After this Setup screen This message Means Enter First Letters File server name not found. No ﬁle server with those letters was found when Fiery S300 of Server Name Try again? queried the network. Check the name of the NetWare ﬁle server, check cable connections, and make sure the (Network Setup>Service NetWare server is turned on.
Page 166 A-4 Troubleshooting After this Setup screen This message Means Add Server, Enter Your Login No NetWare print No print server was found when Fiery S300 queried the ﬁle Name, Enter Your File Server server found. server you selected. Password You must conﬁgure a print server and a print queue for (Network Setup>Service every NetWare ﬁle server that will handle Fiery S300 print Setup >...
Page 167 A-5 Troubleshooting For any Novell error, make sure: • Your IPX (Novell) network is connected to the Fiery S300. • The NetWare server you are trying to access is running. • The Novell network has been conﬁgured with at least one print server and queue for the Fiery S300.
Page 168 A-6 Troubleshooting Novell error Cause Suggested action or exit The Novell ﬁle server is down or out Select a different ﬁle server (or try to get someone else to log off ). Unable to connect to of connections. file server. Pressing the Menu button returns to the PServer This error occurs while the server is File server is...
Page 169: Runtime Error Messages
A-7 Troubleshooting Runtime error messages For error messages related to canceling jobs and printing, including the Disk Full message and alerts to load media, see the Job Management Guide. These messages are reported by the job management tools. You can turn on PostScript error reporting as a print option from Mac OS applications.
Page 170 A-8 Troubleshooting See the following table for the appropriate name. In this location For this item IPX/SPX networks TCP/IP networks Server Setup Server Name option Administrator deﬁnes Administrator page 4-14 name deﬁnes name Windows NT hosts ﬁle host name — DNS name page 2-1 (TCP/IP host name)
Page 171 A-9 Troubleshooting Cannot connect to Fiery S300 with Fiery utilities If users cannot connect to the Fiery S300, check the following: • Fiery S300 Setup—the appropriate network protocol must be enabled, with the correct parameters (for example, for TCP/IP, the IP address), and you must publish either the Print queue or Hold queue.
Page 173 Index Index Numerics AppleTalk 1-5 color server name 4-14, 5-4 100BaseT connector 1-12 network diagram 1-5 10BaseT 1-12 protocol setup 4-19, 5-9 8-pin RJ-45 connector 1-12 supported on Ethernet only 1-4 AppleTalk Setup access level scenarios 3-6 from Control Panel 4-19 access to network and software 3-1 from Control Panel, summary 4-17 accessing Setup...
Page 174 I-2 Index color server back view showing connectors Cancel Job 1-10, 1-11, 4-3, 7-11 from the Control Panel during Control Panel 4-2 printing 4-6 display window 4-2 from the Control Panel during maintaining and improving RIPping 4-6 performance 7-10 canceling Setup changes 4-14 naming 4-14, 5-4 Change (Administrator) Password network installation summary 1-3...
Page 175 I-3 Index connected Novell servers, Bindery 4-31, 5-28 date, setting 4-14, 5-5 connecting Default Paper Sizes option 4-40, 5-37 copier interface cable 3-9 Delete Scan Jobs option 5-5 network cable 1-10 delete symbol, in Setup display 4-12 to a Bindery ﬁle server 4-29, 4-30 destination, Fiery WebLink 6-3 to multiple Bindery device name 4-14, 5-5, 5-36, 5-37, A-8...
Page 176 I-4 Index Enable Port 9100 Print Services Exit Bindery Setup 4-32, 4-38 option 4-36, 5-35 explained 4-28 Enable Printed Queue option 4-15, 5-5 Exit Setup option 7-12 Enable Printing Groups option 4-15 exiting Setup, Control Panel 4-14, 4-45 Enable PServer option 4-23 Enable TCP/IP for Ethernet Fiery E-mail Domain Name option, E-mail option 4-20, 5-13...
Page 177 I-5 Index IPX/SPX polling interval 5-33 gateway address, setting 4-21 protocol setup 4-22 General Setup options 5-5 to 5-6 selecting frame types 4-22 guest login (Novell) Setup 4-22 in Bindery Setup 4-29 summary of Setup options 4-17 in Network Setup A-4 Guest privileges (no password) for WebSpooler 3-4 Java to support Internet browser 6-1...
Page 178 I-6 Index Member Printing 4-15 NetWare File Server, Bindery Menu button 4-5, 4-14 connecting 4-28, 4-29 messages, see error messages ﬁnding available servers 4-29 multiple Bindery ﬁle servers, removing connection 4-32 connecting 4-28 selecting for editing 4-31 setting up more than one 4-28 NetWare Print Console 2-13 naming the color server 4-14, A-7 NetWare Print Server...
Page 179 I-7 Index Port Setup from Control Panel 4-17 Operator password 3-4, 7-3 Ethernet Setup 4-18 privileges 3-3 PostScript error 4-41 Outgoing Server option, PostScript Setup option, E-mail Setup 4-36 see PS Setup option Output Proﬁle option 5-39 PostScript Setup, see PS Setup power switch 7-11 PANTONE 4-8 Print Cover Page option 5-38...
Page 180 I-8 Index printing Conﬁguration page 4-8 Remove File Server, Bindery Setup 4-32 Conﬁguration page from Control explained 4-28 Panel 7-9 removing connections 3-1 Bindery ﬁle server connection 4-32 connections and queues 4-39 Rendering Style option 4-42, 5-39 font list 4-8 reprinting jobs 3-2 Job Log automatically 4-45 Resume Printing command...
Page 181 I-9 Index Server Name option, Windows superuser 2-19 printing 4-34, 5-34 Support option 5-5 Server Setup 3-8 Supported Servers, exiting 5-39 Bindery Setup 4-31 from Control Panel 4-14 Suspend Printing command from Windows computer 5-4 from Control Panel 4-9 part of initial Setup 5-1 System Date option 4-14, 5-5 Server Setup option 7-12 System Time option 4-15, 5-5...
Page 182 I-10 Index troubleshooting Command WorkStation connection warning problems A-9 display window breakage 4-4 connection to printer fails A-7 Web Services Setup 4-35, 5-35 Printer not found in the selection list of WebDownloader, see Fiery WebDownloader Fiery utilities A-9 WebLink, see Fiery WebLink Printer not found—TCP/IP or IPX WebSetup, see Fiery WebSetup networks A-7...
