LIST OF LOOSE PARTS
Item Part Name Qty.
A Leg ................................................................ 4
B ' Screw, Truss Hd. 1t4-20 x 5t8 ..................... 28
C * Nut, Hex 1./4-20 ............................................ 28
D * Lockwasher, 1/4 External ............................ 28
E Channel, Support .......................................... 2
F Stiffener ........................................................ 2
G Stiffener, Side ............................................... 2
H Stitloner, End ................................................ 2
J * Screw, Pan Hd. Ty A N8 x I/2 ....................... 4
K * Nut, Hex Hd. 3/8-16 ...................................... 8
L " Foot, Leveling ............................................... 4
M Motor ............................................................. 1
HARDWARE FOR MOUNTING TOOL
- " Screw, Hex Hd, 5116-18 x 3 .......................... 3
- * Lockwasher, 5,/t6 External ........................... 3
- * Nut, Hex Jam, 5/16_18 .................................. 3
- " Washe{, 11/32 x 11/16 x 1/16 ....................... 3
, These parts contained in Loose Part bag #508411.
,,,,,
7/'16-_NCH WRSNCH
1/2-INCH WRENCH
9t16-1NCH WRENCH
ASSEMBLY
t,=.
TOOLS NEEDED !!i
Coal the spindte assembly with cup grease, being sure to
wipe same of the grease intothe elevating slot milled in the
spindle assembly. Use a generous amount of grease to
cover the spindle.
SLOT
TAPPEO HOLE FOP-,
ELEVATING ROD
/
SPINDLEPULLEY
6
