MOUNTING
MOTOR SUPPORT ASSEMBLY
TO SHAPER
1.
Place V-belt
on motor
pulley
and attach
motor
mount
plate
to shaper base with
two
bolts
13/8-18
x t-inch}
and washers,
Leave bolts
finger tight.
2,
Roll
the
belt
onto
spindle
pulley,
pull motor
mount
plate
toward
end of
base until
bett is tight
enough
to
prevent
slipping
and tighten
the two
bolts,
Each
bolt
should
be in approximately
the same position
in the
base slots.
3.
Position
elevating
rod in approximate
mid position
and
turn
spindle
pulley
by hand several times to see that the
belt
rides
in the
approximate
mid
position
of
motor
pulley.
If
not,
recheck
assembly.
The
belt
should
change positions
on motor
pulley
as the lever position
is
changed
(while
the spindle
pulley
is rotated by hand}.
MOTOR
MOUNT
PLATE
EL EVATI NG
ROD
SPINDLE
PU LL EY
BASE
MOTOR
I.
MOUNTING
SWITCH ASSEMBLY
Attach
the
switch
assembly
to the
underside
of the
Shaper
table
using
the
two
screws
and
lockwashers
packed with
the switch.
/
%
I
ASSEMBLING
STEEL LEGS
1. Assemble
the
two
(2)
End Stiffeners
and the two
(2)
Side Stiffeners
using four
(4)
1/4-20
Truss head screws.
The
End
Stiffeners
are
placed
on
top
of
each
Side
Stiffener
as shown.
Insert
screws through
the 9/32
inch
diameter
holes and finger
tighten
1/4-20
nuts.
2. Attach
the four
(4) legs to the side and End Stiffener
using 1/4-20
screws, lockwashers
and nuts as shown.
3. Remove
the
four
(4)
Truss
head
screws
whict_ were
assembled
in
Paragraph
No,
One,
Place
the
two
(2)
Support
Channels
as shown,
in position,
align holes in
supports
with
holes
in
the
side
Stiffeners,
replace
Iockwashers
and
nuts.
Tighten
all
nuts
using
7/16"
wrench.
4, The two
(2) Stiffeners,
(F} are fastened
to the top side
of
each
side stiffener
using
N8
x
t/2
self-threading
screws. The guard plate
is mounted
as shown
using same
screws,
5. Install
leveling
feet
as shown.
To
level
Leg Set, loosen
nut on inside
of leg and turn
nut on outside
to raise or
lower feet. Adjust
all four levelers,
if necessary,
and then
tighten nuts on inside of leg.
NOTE:
These
levelers
are
not
intended
for
I_eight
adjust ment.
