The Hard Disk Drive (HDD)

The hard disk drive is used to store your data internally in the
notebook computer. It is mounted in a removable case and can be
taken out to accommodate other 2.5" IDE hard disk drives with a
height of 12.7 mm or 9.5 mm. The system supports PIO mode 4,
Master mode IDE, LBA mode and provides a high performance
data transfer rate at speeds up to 66 MBytes/second (ATA-66).
For data security you can easily remove the HDD.
Removing the HDD
1) Turn the computer off.
2) Turn the computer over.
3) Locate the HDD latch
4) Slide and hold the latch forward then slide the HDD out of
the computer.
5) Lift the hard disk drive out of
the computer.
Inserting the HDD
1) Turn off the computer.
2) Turn the computer over.
3) Place the HDD case into the computer.
4) Slide the HDD in until you hear a click.
2-8
.
