User's Manual
2
Warning
Before removing
the HDD, please
check with your
dealer to find out
if this will VOID
your warranty.
2 - 8

The Hard Disk Drive (HDD)

The hard disk drive is used to store your data internally in the notebook com-
puter. It is mounted in a removable case and can be taken out to accommodate
other 2.5" IDE hard disk drives with a height of 9.5 mm or 12.7 mm. The
system supports DMA mode 2, PIO mode 4, and ATA-33/ATA-66/ATA-100 IDE
HDD.

Removing the HDD

1) Turn off the computer.
2) Press the four keyboard latches at
the top of the keyboard to elevate
the keyboard from its normal posi-
tion.
figure 2-6
