Chapter 4: Upgrading the Computer
B: Remove the processor
The processor is secured on the mainboard with a lock which is
easily opened using a small regular screwdriver.
With the heat sink already removed you will need to set the lock
to the open position before removing the processor:
processor mounted on the socket
Processor socket
Lock
4-13
