Installing a Memory Module
1) Turn off the computer.
2) Press the two keyboard
latches at the top of the
keyboard to elevate the
keyboard from its normal
position.
3) Carefully lift the key-
board assembly out to
expose the mainboard.
4) Locate the memory banks, Bank 0 is on the right and Bank 1
is on the left.
Note: Only use Bank 0 if you have one memory module. If you are
using two memory modules always use the larger module in Bank
0.
Bank 1
Chapter 4: Upgrading the Computer
Figure 4-1
Bank 0
Figure 4-2
4-7
