External Monitor (CRT)

The computer can support an XGA compatible external monitor.
The external monitor can be used simultaneously with the LCD
display turned on or off. You can setup your computer to use an
external monitor by entering the System Configuration Utility
(SCU) and selecting the appropriate parameters or using the Fn +
F6 keys (refer to Hot Keys in Chapter 2).
To install an external monitor you simply:
1) Turn off the computer.
2) Connect the cable to the CRT port on the rear of the
computer .
3) Tighten the screws that fasten the cable to the CRT
4) Insert the other end of the cable to the external monitor.
5) Turn on the computer.
Chapter 3: Attaching Peripherals
.
3-5
