User's Manual
E: Changing the SW1 DIP Switch settings
If you have installed the processor with Intel Speedstep you
will have to change the SW1 DIP Switch settings. Follow these
steps to get to change the SW DIP Switch setings:
1) Turn off the computer.
2) Press the two keyboard latches to elevate the keyboard
from its normal position (refer to page 4-7, Figure 4-1)
3) Carefully lift the keyboard assembly out to expose the
mainboard.
4) Remove the metal protective shield (refer to the picture
on page 4-17)
5) Locate the SW1 DIP Switch on the right side.
6) Change the settings to the following:
SW1 settings for Intel Speedstep® Processor
SW1-1
ON
7) Put the metal shield back into place
8) Put the keyboard back into place.
4-16
SW1-2 SW1-3
ON ON
SW1-4
OFF
