User's Manual
Parallel Printer
You can connect any standard Centronics parallel printer to your
computer using the parallel port.
To connect a printer simply:
1) Turn off the computer.
2) Connect the cable to the parallel port on the rear of the
computer
3) Tighten the screws that fasten the cable to the parallel port
.
4) Insert the other end of the cable to the printer's connector.
5) Fasten the cable's connector.
6) Turn on the printer and computer.
Note: You may also need to install the manufacturer-supplied
driver for the printer. Refer to the device's user guide for more
information. If the connected printer supports Enhanced Paral-
lel Port (EPP) or Extended Capabilities Port (ECP) mode,
please enter the System Configuration Utility (SCU) to config-
ure the required setting.
3-6
.
