D-Link DES-3624i User Manual

Stackable nway ethernet switch
Hide thumbs Also See for DES-3624i:
Table of Contents

Advertisement

Quick Links

See also: Reference Manual
DES-3624 Series
Stackable NWay Ethernet Switch
User's Guide
Fifth Edition (December 2001)
651S3624.055
Printed In Taiwan
RECYCLABLE

Advertisement

Table of Contents
loading

Related Manuals for D-Link DES-3624i

Summary of Contents for D-Link DES-3624i

  • Page 1 DES-3624 Series Stackable NWay Ethernet Switch User’s Guide Fifth Edition (December 2001) 651S3624.055 Printed In Taiwan RECYCLABLE...

  • Page 2: Wichtige Sicherheitshinweise

    Wichtige Sicherheitshinweise Bitte lesen Sie sich diese Hinweise sorgfältig durch. Heben Sie diese Anleitung für den spätern Gebrauch auf. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Vervenden Sie keine Flüssig- oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch zur Reinigung.

  • Page 3: Limitation Of Liability

    FIRE, LIGHTNING OR OTHER HAZARD. LIMITATION OF LIABILITY IN NO EVENT WILL D-LINK BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF DATA, LOSS OF PROFITS, COST OF COVER OR OTHER INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES ARISING OUT THE INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE OR INTERRUPTION OF A D- LINK PRODUCT, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY.

  • Page 4: Limited Warranty

    Warranty service may be obtained by contacting a D-Link office within the applicable warranty period, and requesting a Return Material Authorization (RMA) number. If a Registration Card for the product in question has not been returned to D-Link, then a proof of purchase (such as a copy of the dated purchase invoice) must be provided.

  • Page 5: Fcc Warning

    No part of this publication may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from D-Link Corporation/D-Link Systems Inc., as stipulated by the United States Copyright Act of 1976.

  • Page 6: Table Of Contents

    ABLE OF ONTENTS ABOUT THIS GUIDE....................................10 ........................................ 10 ONVENTIONS ’ ................................10 VERVIEW OF THIS UIDE INTRODUCTION ......................................11 ................................. 11 THERNET ECHNOLOGY ................................11 IGABIT THERNET ECHNOLOGY ..................................12 WITCHING ECHNOLOGY ........................................12 EATURES Ports..........................................12 Performance features ....................................13 Management .......................................13 UNPACKING AND SETUP ..................................14 ........................................
  • Page 7 Aging Time ........................................30 Filtering Database....................................31 ..................................31 PANNING LGORITHM STA Operation Levels ....................................31 On the Bridge Level....................................31 On the Port Level....................................32 User-Changeable STA Parameters.................................32 Illustration of STA .....................................33 ......................................34 RUNKING VLAN & MAC-B ............................35 ASED ROADCAST OMAINS MAC-Based Broadcast Domains................................36 IEEE 802.1Q VLANs....................................36...
  • Page 8 Ping Test........................................85 Save Settings to TFTP Server................................86 Save Switch History to TFTP Server..............................87 Clear Address Table ....................................88 Community Strings and Trap Stations ..............................88 ....................................89 WITCH ONITORING Network Monitoring ....................................89 Traffic Statistics ...................................... 90 Port Utilization..................................... 91 Port Traffic Statistics...................................
  • Page 9 Port Error Packet Statistics .................................. 148 Port Packet Analysis Statistics ................................149 Browse Address Table ..................................151 IP Multicast & IGMP Information ..............................152 Browse GVRP Status .................................... 153 Browse GMRP Status................................... 154 Switch History ....................................... 155 Maintenance......................................155 Firmware and Configuration Update..............................156 Save Settings To TFTP Server ................................

  • Page 10: About This Guide

    Stackable NWay Ethernet Switch User’s Guide BOUT UIDE This User’s Guide tells you how to install your Stackable NWay Ethernet Switch, how to connect it to your Ethernet network, and how to set its configuration using either the built-in console interface or Web-based management (please note that Netscape Communicator/Navigator, 4.x or later, or Microsoft Internet Explorer, 4.x or later, are recommended).

  • Page 11: Introduction

    Stackable NWay Ethernet Switch User’s Guide NTRODUCTION This section describes the features of the Switch, as well as giving some background information about Ethernet/Fast Ethernet, Gigabit Ethernet, and switching technology. Fast Ethernet Technology The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need for high performance networks.

  • Page 12: Switching Technology

    Features The DES-3624 series of Switches can include one master (DES-3624I, DES-3624iF, or DES-3624iFM) and up to three clients (DES-3624, DES-3624F, or DES-3624FM). They are designed for easy installation and high performance in an environment where traffic on the network and the number of users increases continuously.

  • Page 13: Performance Features

    Stackable NWay Ethernet Switch User’s Guide Stacking Input/Output port slide-in module in the rear panel for stacking to another device to implement a high-port count, manageable switch. Three-port module for master device and one-port module for a client device. Performance features Store and forward switching scheme capability to support rate adaptation and protocol conversion.

  • Page 14: Unpacking And Setup

    One RS-232 cable (master only) This user’s guide on CD-ROM with a Registration Card If any item is found missing or damaged, please contact your local D-Link reseller for replacement. Setup The setup of the Switch can be performed using the following steps: The surface must support at least 5 kg.

  • Page 15: Rack Installation

    Stackable NWay Ethernet Switch User’s Guide Figure 2-1. Switch installed on a Desktop or Shelf Rack Installation The Switch can be mounted in an EIA standard size, 19-inch rack, which can be placed in a wiring closet with other equipment. To install, attach the mounting brackets on the Switch’s side panels (one on each side) and secure them with the screws provided.

  • Page 16: Power On

    Stackable NWay Ethernet Switch User’s Guide Power On The Switch can be used with AC power sources 100 - 240 VAC, 50 - 60 Hz. The power switch is located at the rear of the unit adjacent to the AC power connector and the system fan. The Switch’s power supply will adjust to the local power source automatically and may be turned on without having any or all LAN segment cables connected.

  • Page 17: Identifying External Components

    3624FM are equipped with MDI-X jacks for normal end-node connections and MDI-II jacks for uplink connections. Port number 1 on the DES-3624i, DES-3624iF, and DES-3624iFM are equipped with an MDI-X jack for normal end- node connection and an MDI-II jack for uplink connection.

  • Page 18: Rear Panel

    The rear panel of the DES-3624, DES-3624F, and DES-3624FM consist of a slot (labeled Slot2) for a Stacking input/output port and an AC power connector. The rear panel of the DES-3624i, DES-3624iF, and DES-3624iFM consist of two slots (labeled Slot2 and Slot3). Slot2 is for Stacking input/output ports Sio1, Sio2, and Sio3. Slot3 is for an optional Gigabit Ethernet uplink (MDI-II) port.

  • Page 19: Stack Operation

    Stack Operation The DES-3624i, DES-3624iF, and DES-3624iFM are all intelligent Switches capable of acting as a master for up to three slave Switches (DES-3624, DES-3624F, or DES-3624FM). Each port is referred to by unit ID and port number in your DES-3624 Series stack.

  • Page 20: Optional Plug-In Modules

    Stackable NWay Ethernet Switch User’s Guide Figure 3-5. Switch stack with example of possible connections Optional Plug-in Modules The DES-3624i/DES-3624iF/DES-3624iFM Stackable NWay Ethernet Switch is able to accommodate a range of plug-in modules in order to increase functionality and performance. Identi fying External Components...

  • Page 21: 100Base-Fx (Mt-Rj) Module

    Stackable NWay Ethernet Switch User’s Guide 100BASE-FX (MT-RJ) Module Figure 3-6. Two-port, 100BASE-FX (MT-RJ) module Two-port, front-panel module. Connects to 100BASE-FX devices at full- or half-duplex. Supports multi-mode fiber-optic cable connections of up to 412 meters in half-duplex or 2 km in full-duplex mode. 100BASE-FX (SC) Module Figure 3-7.

  • Page 22: 100Base-Tx Module

    Stackable NWay Ethernet Switch User’s Guide 100BASE-TX Module Figure 3-8. Two-port, 100BASE-TX module Two-port, front-panel module. Connects to 100BASE-TX devices at full- or half-duplex. Supports Category 5 UTP or STP cable connections of up to 100 meters. 1000BASE-SX Gigabit Module Figure 3-9.

  • Page 23: 1000Base-Lx Gigabit Module

    Stackable NWay Ethernet Switch User’s Guide 62.5 m 62.5 m 50 m 50 m Modal bandwidth (min. overfilled launch) Unit: MHz*km Operating distance Unit: meters Channel insertion loss 2.33 2.53 3.25 3.43 Unit: dB 1000BASE-LX Gigabit Module Figure 3-10. One-port, 1000BASE-LX gigabit module One- or two-port, rear-panel module.

  • Page 24: Led Indicators

    Stackable NWay Ethernet Switch User’s Guide Supports Category 5+ or higher cable connections of up to 100 meters. LED Indicators The LED indicators of the Switch include Power, Console, Slot, Giga, Speed, and Link/Act. The following shows the LED indicators for the Switch along with an explanation of each indicator. Figure 3-12.
  • Page 25 Stackable NWay Ethernet Switch User’s Guide 100M These indicators are illuminated green when a 100 Mbps device is connected to any of the 22+2 or 20+2 ports or uplink port. If a 10 Mbps device is connected to any of the 24 ports or uplink port, these LEDs remain dark. When a port is active, these indicators will blink green.

  • Page 26: Connecting The Switch

    Stackable NWay Ethernet Switch User’s Guide ONNECTING WITCH This chapter describes how to connect the Switch to your Ethernet network. Switch to End Node End nodes include PCs outfitted with a 10, 100 or 10/100 Mbps RJ-45 Ethernet/Fast Ethernet Network Interface Card (NIC) and most routers.

  • Page 27: 10Base-T Device

    Stackable NWay Ethernet Switch User’s Guide A 10BASE-T hub or switch can be connected to the Switch via a two-pair Category 3, 4 or 5 UTP/STP straight cable. A 100BASE-TX hub or switch can be connected to the Switch via a four-pair Category 5 UTP/STP straight cable. If the other switch or hub contains an unused Uplink port, we suggest connecting the other device’s Uplink (MDI-II) port to any of the switch’s (MDI-X) ports (1x - 22x, or one of the 100BASE-TX module ports) using a normal straight-through cable, as shown below.

  • Page 28: Switch Management Concepts

    Stackable NWay Ethernet Switch User’s Guide WITCH ANAGEMENT ONCEPTS This chapter discusses many of the features used to manage the switch, and explains many concepts and important points regarding these features. Configuring the Switch to implement these concepts is discussed in detail in the next chapters. Local Console Management Local console management involves the administration of the Switch via a direct connection to the RS-232 DCE console port.

  • Page 29: Ip Addresses And Snmp Community Names

    Stackable NWay Ethernet Switch User’s Guide IP Addresses and SNMP Community Names Each Switch has its own IP Address, which is used for communication with an SNMP network manager or other TCP/IP application (for example BOOTP, TFTP). You can change the default Switch IP Address to meet the specification of your networking address scheme.

  • Page 30: Mibs

    Stackable NWay Ethernet Switch User’s Guide Link Change Event This trap is sent whenever the link of a port changes from link up to link down or from link down to link up. Port Partition This trap is sent whenever a port is partitioned as a result of more than sixty-one collisions on the port (i.e., it is automatically partitioned).

  • Page 31: Filtering Database

    Stackable NWay Ethernet Switch User’s Guide Filtering Database A switch uses a filtering database to segment the network and control communications between segments. It also filters packets off the network for intrusion control (MAC Address filtering). For port filtering, each port on the switch is a unique collision domain and the switch filters (discards) packets whose destination lies on the same port as where it originated.

  • Page 32: On The Port Level

    Stackable NWay Ethernet Switch User’s Guide Bridge Identifier This is the combination of the Bridge Priority (a parameter that you can set) and the MAC address of the switch. Example: 4 00 80 C8 00 01 00, where 4 is the Bridge Priority. A lower Bridge Identifier results in a higher priority for the switch, and thus increases it probably of being selected as the Root Bridge.

  • Page 33: Illustration Of Sta

    Stackable NWay Ethernet Switch User’s Guide Port Priority A Port Priority can be from 0 to 255. The lower the number, the greater the probability the port will be chosen as the Root Port. Illustration of STA A simple illustration of three Bridges (or the Switch) connected in a loop is depicted in Figure 5-1. In this example, you can anticipate some major network problems if the STA assistance is not applied.

  • Page 34: Port Trunking

    Stackable NWay Ethernet Switch User’s Guide Bridge Priority lower the #, Increases chance Avoid, if the switch higher the of becoming the is used in workgroup priority Root Bridge level of a large network Hello Time 1 - 10 sec. No effect, if not Never s et greater Root Bridge...

  • Page 35: Vlans & Mac-Based Broadcast Domains

    Stackable NWay Ethernet Switch User’s Guide Figure 5-3. Port trunking example The switch treats all ports in a trunk group as a single port. As such, trunk ports will not be blocked by Spanning Tree (unless a redundant link with higher STP priority is present). Data transmitted to a specific host (destination address) will always be transmitted over the same port in a trunk group.

  • Page 36: Mac-Based Broadcast Domains

    Stackable NWay Ethernet Switch User’s Guide The untagging feature of IEEE 802.1Q VLANs allows VLANs to work with legacy switches that don’t recognize VLAN tags in packet headers. The tagging feature allows VLANs to span multiple 802.1Q-compliant switches through a single physical connection and allows Spanning Tree to be enabled on all ports and work normally (BPDU packets are not tagged).

  • Page 37: Sharing Resources Across 802.1Q Vlans

    Stackable NWay Ethernet Switch User’s Guide Sharing Resources Across 802.1Q VLANs Network resources such as printers and servers however, can be shared across 802.1Q VLANs. This is achieved by setting up overlapping VLANs as shown in the diagram below. VLAN 3 VLAN 2 VLAN 1 1 2 3 4...

  • Page 38: Vlans Over 802.1Q-Compliant Switches

    Stackable NWay Ethernet Switch User’s Guide Tagging The act of putting 802.1Q VLAN information into the header of a packet. Ports with tagging enabled will put the VID number, priority, and other VLAN information into all packets that flow out it. If a packet has previously been tagged, the port will not alter the packet, thus keeping the VLAN information intact.

  • Page 39: Port-Based Vlans

    Stackable NWay Ethernet Switch User’s Guide In the above example, step 4 is the key element. Because the packet has 802.1Q VLAN data encoded in its header, the ingress port can make VLAN-based decisions about its delivery: whether server #2 is attached to a port that is a member of VLAN 2 and, thus, should the packet be delivered;...

  • Page 40: Segmenting Broadcast Domains

    Stackable NWay Ethernet Switch User’s Guide Segmenting Broadcast Domains The Switch allows you to segment broadcast domains. It does this by forwarding packets only to ports in the same broadcast domain or VLAN. Thus, broadcast packets will only be forwarded to ports that are members of the same broadcast domain or VLAN.

  • Page 41: Using The Console Interface

    Stackable NWay Ethernet Switch User’s Guide SING THE ONSOLE NTERFACE Your Stackable NWay Ethernet Switch supports a console management interface that allows you to set up and control your Switch, either with an ordinary terminal (or terminal emulator), or over the network using the TCP/IP Telnet protocol. You can use this facility to perform many basic network management functions.

  • Page 42: Connecting To The Switch Using Telnet

    Stackable NWay Ethernet Switch User’s Guide Figure 6-1. Example of a console connection Connecting to the Switch Using Telnet Once you have set an IP address for your Switch, you can use a Telnet program (in a VT-100 compatible terminal mode) to access and control the Switch.
  • Page 43 Stackable NWay Ethernet Switch User’s Guide Figure 6-2. Initial Screen, first time connecting to the Switch Note: There is no initial username or password. Leave the username and password fields blank. Press <Enter> or <Return> in the username and password fields. You will be given access to the main menu shown below: Figure 6-3.

  • Page 44: User Accounts Management

    Stackable NWay Ethernet Switch User’s Guide The first user automatically gets Administrator privileges (See Table 6-1). It is recommended to create at least one Administrator-level user for the Switch. User Accounts Management From the screen above, move the cursor to the User Accounts Management menu and press <Enter>, then the Users Accounts Management menu appears.

  • Page 45: Save Changes

    Stackable NWay Ethernet Switch User’s Guide Save Changes The Switch has two levels of memory normal RAM and non-volatile or NV-RAM. Settings need to be changed in all screens by pressing Ctrl + S. When this is done, the settings will be immediately applied to the switching software in RAM, and will immediately take effect.
  • Page 46 Stackable NWay Ethernet Switch User’s Guide 1. Choose Users Accounts Management from the main menu. The following User Accounts Management menu appears: Figure 6-5. User Accounts Management menu 2. Choose Create/Modify User Accounts. The following screen appears: Figure 6-6. Add/Modify User Accounts screen Using the Console Interface...

  • Page 47: User Accounts Control Table

    Stackable NWay Ethernet Switch User’s Guide 3. Type in your Username and press <Enter>. 4. If you are an old user, type in the Old Password and press <Enter>. 5. Type in the New Password you have chosen, and press <Enter>. Type in the same new password in the following field to verify that you have not mistyped it.

  • Page 48: Setting Up The Switch

    Stackable NWay Ethernet Switch User’s Guide Setting Up The Switch This section will help prepare the Switch user by describing the System Configuration, Update Firmware and Configuration Files, Save Changes, and System Utilities menus and their respective sub-menus. System Configuration Choose System Configuration to access the first item of the Switch’s main menu.

  • Page 49: Configure Console

    Stackable NWay Ethernet Switch User’s Guide Figure 6-9. IP Address Configuration screen The fields listed under the Current Settings heading are those that are presently being used by the Switch. Those fields listed under the Restart Settings heading will be used after the Switch has been reset. Fields that can be set include: Get IP from Determines whether the Switch should get its IP Address settings from the user (Manual), a BOOTP server, or a DHCP server.

  • Page 50: Configure Switch Stack

    Stackable NWay Ethernet Switch User’s Guide Note that the DES-3624i/DES-3624iF/DES-3624iFM has an RS-232C serial port but the DES-3624/DES-3624F/DES- 3624FM does not. Choose Configure Console to access the last item on the System Configuration menu. The following screen appears: Figure 6-10. Console Options screen...

  • Page 51: Information Of Individual Switch Unit

    Stackable NWay Ethernet Switch User’s Guide Choose Configure Switch Stack to access the second item on the System Configuration menu. The following screen appears: Figure 6-11. Switch Stack Configuration screen The fields you can set are: System Name Corresponds to the SNMP MIB II variable , and is used to give a name to system.sysName the Switch for administrative purposes.

  • Page 52: Advance Settings

    Stackable NWay Ethernet Switch User’s Guide Figure 6-12. Information of Individual Switch Unit screen Use the space bar to select the desired Switch in your stack. Advance Settings The Configure Advanced Switch Stack Features screen allows you to set an expiration time for MAC address entries and enable or disable auto-partitioning on all ports.

  • Page 53: Configure Port

    Stackable NWay Ethernet Switch User’s Guide Figure 6-13. Configure Advanced Switch Stack Features screen The fields you can set are: Auto-Partition Capability on All Ports When this function is enabled, if too many consecutive collisions occur on an individual port, the port will be blocked off until a good packet is seen on the wire. If a port is partitioned, the Switch can only transmit data, not receive it.
  • Page 54 Stackable NWay Ethernet Switch User’s Guide Figure 6-14. Port Configuration screen Items in the above window are defined as follows: Switch Specifies the Switch where the port is being configured. Module Specifies the module where the port is being configured. Port Specifies the port that will be configured.

  • Page 55: Configure Trunk Groups

    Stackable NWay Ethernet Switch User’s Guide Port Lock When Enabled, automatic learning for all stations connected to this port will stop and entries in the Forwarding Table for all devices residing on this port will age out. The only traffic this port will allow is traffic from machines whose MAC address is manually entered in the Static Forwarding Table.

  • Page 56: Configure Port Mirroring

    Stackable NWay Ethernet Switch User’s Guide Figure 6-15. Port Trunk screen The fields you can set are: Anchor There are either two or three listings representing the anchor port for each of the three trunk groups available on the Switch (the third listing will only be displayed if an optional two-port plug-in module is being used). The anchor port must fall within the port range and be included as a member port.

  • Page 57: Configure Spanning Tree Protocol

    Stackable NWay Ethernet Switch User’s Guide Figure 6-16. Port Mirroring Configuration screen To configure a mirror port, select the Switch, Module, and Port from where you want to copy frames in the Source fields. Then select the Switch, Module, and Port which receive the copies from the source port in the Destination fields. The destination (or target) port is where you will connect a monitoring/troubleshooting device such as a sniffer or an RMON probe.
  • Page 58 Stackable NWay Ethernet Switch User’s Guide Figure 6-17. Configure Spanning Tree Protocol menu 2. Choose STP Parameter Setting to access the following screen: Figure 6-18. STP Parameter Setting screen 3. Change the Disabled setting to Enabled in the Spanning Tree Protocol field. Using the Console Interface...
  • Page 59 Stackable NWay Ethernet Switch User’s Guide 4. Enter the Bridge Max Age in the Max Age (6-40 sec.) field. 5. Enter the Bridge Hello Time in the Hello Time (1-10 sec.) field. 6. Enter the Bridge Forward Delay time in the Forward Delay (4-30 sec.) field. 7.

  • Page 60: Stp Custom Settings

    Stackable NWay Ethernet Switch User’s Guide Bridge Priority (0–65535) A Bridge Priority is a read-write object that can be set from 0 to 65535. This is the priority number of the bridge. The value is used in conjunction with the bridge MAC address to set the bridge ID, which in turn is used when determining the root bridge of a multibridged network.

  • Page 61: Configure Filtering And Forwarding Table

    Stackable NWay Ethernet Switch User’s Guide Configure Filtering and Forwarding Table When a packet hits the Switch, it looks in the filtering and forwarding tables to decide what to do with the packet; either to filter it off the network, or to forward it through the port on which its destination lies. Dynamic Filtering and Static Filtering are among the two important features of the Custom Filtering Table.

  • Page 62: Configure Static Forwarding Table

    Stackable NWay Ethernet Switch User’s Guide Please refer to the Packet Forwarding section of the “Switch Management Concepts” chapter of this manual for more detailed information. Configure Static Forwarding Table The Static Forwarding Table Configuration screen displays a list of manually defined static unicast MAC address entries.

  • Page 63: Configure Mac Address Filtering

    Stackable NWay Ethernet Switch User’s Guide for the same MAC address. Static filters always take precedence over static forwarding entries. The Switch will automatically upgrade the Status to “in use” once the static filter is removed. Configure MAC Address Filtering The Static Filtering Table screen contains filtering information configured into the Switch by (local or network) management specifying destination addresses which are not allowed to be forwarded.

  • Page 64: Configure Igmp

    Stackable NWay Ethernet Switch User’s Guide Figure 6-23. Static Multicast Filtering Table Configuration screen To add an entry or make a change to an entry on the Static Multicast Filtering Table Configuation screen, select Add or Remove in the first field, enter the multicast MAC address in the next field, enter the VLAN ID number, assign the outgoing ports by typing a V, and then press APPLY to put the changes into effect.
  • Page 65 Stackable NWay Ethernet Switch User’s Guide Figure 6-24. IGMP Configuration screen Items in the above window are defined as follows: IP Multicast Filtering Age-out Timer(30-9999) When this timer expires and the Switch has not observed (snooped) any IGMP query packets asking whether any stations belong to any Multicast groups, the Switch itself will send out queries and become the IGMP host on your network.
  • Page 66 Stackable NWay Ethernet Switch User’s Guide Figure 6-25. IEEE 802.1Q IGMP Configuration screen Choose Add/Remove IGMP Entry from the screen above to define up to 12 VLANs on the Switch which can send and receive IGMP packets: Figure 6-26. Add/Remove IGMP Entry screen Using the Console Interface...

  • Page 67: Configure Vlans & Mac-Based Broadcast Domains

    Stackable NWay Ethernet Switch User’s Guide The above screen is used to specify an agent to interface between IGMP and VLAN. The agents are assigned to a VLAN and allow IGMP query and report packets to be present on the given VLAN. Only 12 agents can exist on the switch at any one time.

  • Page 68: Configure Mac-Based Broadcast Domains

    Stackable NWay Ethernet Switch User’s Guide NONE. Please note that the Switch can only support one mode at any given time. Also, each time the mode is changed, the Switch must be rebooted before the new mode is activated. If you have selected MAC-based Broadcast Domains and then rebooted the Switch, Configure MAC-based Broadcast Domains will appear at the bottom of the VLAN Configuration screen (System Configuration à...
  • Page 69 Stackable NWay Ethernet Switch User’s Guide Figure 6-29. MAC-Based Broadcast Domains Configuration menu Choose Add/Remove MAC-based Broadcast Domains to access the following screen: Figure 6-30. Add/Remove MAC-based Broadcast Domains screen The fields you can set are: Using the Console Interface...
  • Page 70 Stackable NWay Ethernet Switch User’s Guide Action Select the desired action by toggling between Add and Remove. Domain Name Enter the name of the broadcast domain. Press APPLY to add or remove the designated MAC-based broadcast domain. Broadcast Domains and Number of Members reflect the current status. They are read-only fields and cannot be changed. Choose Add/Remove MAC-based Broadcast Domain Members from the MAC-Based Broadcast Domains Configuration menu to access the following screen: Figure 6-31.

  • Page 71: Configure Port-Based Vlans

    Stackable NWay Ethernet Switch User’s Guide Figure 6-32. Add/Remove MAC-based Broadcast Domain Members screen The fields you can set are: Action Select the desired action by toggling between Add and Remove. MAC Address The MAC address of the broadcast domain member being added or removed. Please note that the Status field for the MAC address you have entered may read Not-Apply.
  • Page 72 Stackable NWay Ethernet Switch User’s Guide Figure 6-33. Port-based VLAN Configuration menu The field you can set is: Management Vlan ID Enter a VLAN ID (VID) from 1 to 12 for use with management packets. Select Configure Port-based VLAN Entry at the bottom of the menu above to access the following screen: Using the Console Interface...
  • Page 73 Stackable NWay Ethernet Switch User’s Guide Figure 6-34. Port-based VLAN Configuration screen The fields you can set are: VLAN ID (VID) Enter a VLAN ID from 1 to 24 and hit <Enter>. This is the VLAN that will be defined on this screen.

  • Page 74: Configure 802.1Q Vlans

    Stackable NWay Ethernet Switch User’s Guide Figure 6-35. Browse Port-based VLANs screen Configure 802.1Q VLANs To configure an 802.1Q VLAN, you must do three things: 1. Decide if you want to enable Ingress Filtering and enable it on the chosen ports. Ingress filtering applied on a port causes the port to examine all incoming packets and check whether the port itself is a member of the VLAN.
  • Page 75 Stackable NWay Ethernet Switch User’s Guide Figure 6-36. 802.1Q VLAN Configuration menu Choose Configure Port Ingress Filter to access the first item on the menu. The following screen appears: Figure 6-37. Ingress Filter screen This screen allows you to set Ingress filtering for each port to either Enabled or Disabled. When a packet arrives at the port and Ingress filtering is Enabled, the port will check the VLAN ID number of the packet, and its own VIDs.
  • Page 76 Stackable NWay Ethernet Switch User’s Guide match, the port will receive the packet. If the packet doesn’t have a VLAN tag or the port is not a member of the VLAN for which the packet is tagged, the packet will be discarded. Note: If a port is a member of a trunk group but is not the anchor, the items shown in the above table will be read- only and the values will be the same as those for the anchor port.
  • Page 77 Stackable NWay Ethernet Switch User’s Guide Figure 6-39. Port GVRP Configuration screen This screen allows you to enable or disable GARP VLAN Registration Protocol (GVRP), where GARP is the Generic Attribute Registration Protocol, on individual ports. GVRP updates dynamic VLAN registration entries and communicates the new VLAN information across the network.
  • Page 78 Stackable NWay Ethernet Switch User’s Guide Figure 6-40. 802.1Q Static VLAN Settings screen The fields you can set are: VID Enter a VLAN ID from 1 to 4094 and hit <Enter>. This is the VLAN that will be defined on this screen. VLAN Name Description of the VLAN.

  • Page 79: Configure Gmrp

    Stackable NWay Ethernet Switch User’s Guide Figure 6-41. Browse 802.1Q VLAN Entries screen This table displays the current VID and VLAN Name as well as Tag/Untag and Egress/Forbidden/Non-Member status for all 802.1Q static VLAN entries. Configure GMRP Group Multicast Registration Protocol (GMRP) allows multicasts to be sent on a single VLAN without affecting other VLANs or broadcast domains.
  • Page 80 Stackable NWay Ethernet Switch User’s Guide Figure 6-42. GMRP Configuration menu The Switch GMRP field allows you to either enable or disable GMRP on the Switch by toggling between the two choices and then pressing APPLY to let the change take effect. Once GMRP is enabled for the Switch, you then must enable specific ports by selecting Configure Port GMRP Settings from the GMRP Configuration menu above.
  • Page 81 Stackable NWay Ethernet Switch User’s Guide Figure 6-43. GMRP Configuration screen Use this screen to enable or disable GMRP on individual ports. Press APPLY to let your changes take effect. Choose Configure Static Multicast Forwarding from the GMRP Configuration menu to access the Static Multicast Forwarding Table Configuration screen that appears below: Using the Console Interface...
  • Page 82 Stackable NWay Ethernet Switch User’s Guide Figure 6-44. Static Multicast Forwarding Table Configuration screen To add an entry or make a change to an entry on the Static Multicast Forwarding Table, enter a VLAN ID number, enter a MAC address, choose Egress or Forbidden for each port, choose a State (Delete on Reset, Delete on Timeout, Invalid, or Permanent), and then press APPLY to put the change into effect.

  • Page 83: Update Firmware And Configuration Files

    Stackable NWay Ethernet Switch User’s Guide Figure 6-45. Browse Static Multicast Forwarding Table screen This screen contains information pertaining to the Static Multicast Forwarding Table. Update Firmware and Configuration Files The Switch is capable of obtaining its configuration settings (the same settings defined in this console program), as well as updated versions of its internal switching software (the console program itself), using TFTP (Trivial File Transfer Protocol).

  • Page 84: Special Note Concerning Firmware Updates

    Stackable NWay Ethernet Switch User’s Guide Figure 6-46. Update Firmware and Configuration Files screen After making your changes in the fields above, press REBOOT TO START UPDATE to initiate the update sequence. The fields you can set are: Software Update Mode Set to either network or SLIP. Determines whether the configuration file should be obtained through the Ethernet network or through the console port.

  • Page 85: System Utilities

    Stackable NWay Ethernet Switch User’s Guide 4. Firmware updates are handled by the PROM code, which doesn’t recognize VLAN tags. You should therefore make sure the Switch port to which the TFTP server is connected is not a tagging port. System Utilities The Utilities menu offers four system utility options, Ping Test, Save Settings to TFTP Server, Save Switch History to TFTP Server, and Clear Address Table.

  • Page 86: Save Settings To Tftp Server

    Stackable NWay Ethernet Switch User’s Guide Figure 6-48. Ping Test screen After filling in the fields above, press START to initiate the Ping test. The fields you can set are: Destination IP Address The IP address of the device to be Pinged. No.

  • Page 87: Save Switch History To Tftp Server

    Stackable NWay Ethernet Switch User’s Guide Figure 6-49. Save Settings to TFTP Server screen Press START to begin the upload. The result will be displayed in the lower part of the screen. The fields you can set are: Server IP Address The IP address of the TFTP server where you wish to save the settings for the Switch. File Name The complete path and filename for the file.

  • Page 88: Clear Address Table

    Stackable NWay Ethernet Switch User’s Guide Figure 6-50. Save Switch History to TFTP Server screen Press START to begin the file save. The result will be displayed in the lower part of the screen. The fields you can set are: Server IP Address The IP address of the TFTP server where the switch history file will be located.

  • Page 89: Switch Monitoring

    Stackable NWay Ethernet Switch User’s Guide Choose Community Strings and Trap Stations to access the third item on the main menu. The following screen appears: Figure 6-51. SNMP Manager Configuration screen The following SNMP Manager and Trap Manager Configuration parameters can be set: The community string that will be included on SNMP Community String/Trap Community String SNMP packets sent to and from the Switch.

  • Page 90: Traffic Statistics

    Stackable NWay Ethernet Switch User’s Guide Figure 6-52. Network Monitoring menu The first item on this menu permits you to access four different tables that observe the condition of each individual port. Traffic Statistics To display the Traffic Statistics menu, choose the first item on the Network Monitoring menu. The following menu appears: Using the Console Interface...

  • Page 91: Port Utilization

    Stackable NWay Ethernet Switch User’s Guide Figure 6-53. Traffic Statistics menu Port Utilization To access the first item on the Traffic Statistics menu, choose Port Utilization. The following table appears: Figure 6-54. Port Utilization screen Using the Console Interface...

  • Page 92: Port Traffic Statistics

    Stackable NWay Ethernet Switch User’s Guide Select the desired device in the Switch field and the desired increment setting in the Update Interval field: 5 sec, 15 sec, 30 sec, 1 min, or Suspend. The statistic counters displayed are defined as follows: TX/sec The number of good bytes sent from the respective port per second.

  • Page 93: Port Packet Error Statistics

    Stackable NWay Ethernet Switch User’s Guide Frames Recv. The number of good frames received. This also includes local and dropped packets. Frames Sent The number of good frames sent from the respective port. Total Bytes Recv. The number of bytes received, good and bad. Total Frames Recv.

  • Page 94: Port Packet Analysis Statistics

    Stackable NWay Ethernet Switch User’s Guide The number of frames with length more than 1536 bytes and with CRC error or misalignment (bad Jabber framing). Late Collision The number of collisions that occur at or after the 64 byte (octet) in the frame. Mac Rx Error The number of frames with received MAC Errors.

  • Page 95: Browse Address Table

    Stackable NWay Ethernet Switch User’s Guide TX (GOOD) The number of good frames sent from the respective port. Total RX The number of frames received, good and bad. TX Octets The number of good bytes sent from the respective port. RX Octets The number of good bytes received.

  • Page 96: Switch History

    Stackable NWay Ethernet Switch User’s Guide To browse by VLAN ID, select VID in the Search By field, enter the desired VLAN in the field offered, and then press FIND. To browse by sequence, select Sequence in the Search By field, and then press FIND. The lower part of the screen is a read-only Browse Address Table that contains the Total Addresses in Table, as well as the Switch, Module, Port, MAC Address, VLAN, and Learned status of each entry.

  • Page 97: Browse Gvrp Status

    Stackable NWay Ethernet Switch User’s Guide To display the IP Multicast & IGMP Information screen, choose Network Monitoring from the main menu and then choose Browse IGMP Status. The following screen appears: Figure 6-60. IP Multicast & IGMP Information screen This screen displays the number of IGMP queries and reports for each active IP multicast group detected by the Switch.

  • Page 98: Browse Gmrp Status

    Stackable NWay Ethernet Switch User’s Guide To display the GVRP Status screen, choose Network Monitoring from the main menu and then choose Browse GVRP Status. The following screen appears: Figure 6-61. GVRP Status screen This screen contains information pertaining to GVRP. Press N to view the status of additional IEEE 802.1Q VLANs. Browse GMRP Status The Browse GMRP Status screen allows you to browse Group Multicast Registration Protocol (GMRP).

  • Page 99: Resetting The Switch

    Stackable NWay Ethernet Switch User’s Guide Figure 6-62. GMRP Status screen This screen contains information pertaining to the GMRP status of IEEE 802.1Q VLANs. Resetting the Switch You can use the console interface to reset the Switch, either performing a Restart System or a Factory Reset (which sets all of the Switch’s parameters to what they were when the Switch was delivered from the factory).

  • Page 100: Factory Reset

    Stackable NWay Ethernet Switch User’s Guide Figure 6-63. Restart System screen The computer will be rebooted once you press RESTART. Factory Reset Before performing a Factory Reset, be absolutely certain that this is what you want to do. Once the reset is done, all of the Switch’s settings stored in NV-RAM (including TCP/IP parameters, SNMP parameters, the enabled/disabled settings of ports, security settings, etc.) will be erased and restored to values present when the Switch was purchased.

  • Page 101: Logout

    Stackable NWay Ethernet Switch User’s Guide Figure 6-64. Factory Reset NV-RAM to Default Value screen Logout To exit the console program, choose Logout from the main menu. Make sure you have performed a Save Changes if you have made changes to the settings and wish them to become defaults for the switch. After logging out, you will be returned to the opening login screen.

  • Page 102: Web-Based Network Management

    Stackable NWay Ethernet Switch User’s Guide ASED ETWORK ANAGEMENT Introduction The Switch offers an embedded Web-based (hypertext) interface allowing users to manage the Switch from anywhere on the network through a standard browser such as Netscape Navigator/Communicator, 4.x or later, or Microsoft Internet Explorer, 4.x or later.

  • Page 103: Configuration

    Stackable NWay Ethernet Switch User’s Guide Clicking on one of the ports opens a configuration window for that particular port. Each page contains the following list of buttons in the panel on the left side: Configuration, Management, Monitoring, and Maintenance. These are the main categories for Switch management. Clicking on one of the categories causes a list of options to appear below.

  • Page 104: Switch Module

    Stackable NWay Ethernet Switch User’s Guide Switch MAC Address The Ethernet address for the device. Also known as the physical address. Get IP From Determines whether the Switch should get its IP Address settings from the user (Manual), a BOOTP server, or a DHCP server. If Manual is chosen, the Switch will use the IP Address, Subnet Mask and Default Gateway settings defined in this screen upon being rebooted.

  • Page 105: Switch Module Information

    Stackable NWay Ethernet Switch User’s Guide Two hyperlinks at the bottom of this window provide access to the Switch Module Information and Advanced Switch Stack Features windows, respectively. These windows are described in the two sections that immediately follow. The information in the window above is described as follows: Device Type A description of the Switch type.

  • Page 106: Advanced Settings

    Stackable NWay Ethernet Switch User’s Guide This window displays the Module, Type, and Hardware Revision of each individual Switch unit. Select the desired Switch in the field in the lower left-hand corner. The information above is described as follows: Module The module location in the Switch unit. Type The type of module in the Switch unit.

  • Page 107: Port

    Stackable NWay Ethernet Switch User’s Guide Head of Line (HOL) Blocking Prevention This option prevents forwarding a packet to a port where an excess of packets are queued up. Note that when a multicast packet or a packet with an unknown destination address needs to be forwarded to several ports, and if some of them are “blocking,”...
  • Page 108 Stackable NWay Ethernet Switch User’s Guide speed/duplex field above and flow control is enabled, flow control (whether f u ll- or half-duplex) will only be implemented if the other device can auto-negotiate flow control. Note that you must reboot the Switch before a flow control change can take effect.

  • Page 109: Trunk Groups

    Stackable NWay Ethernet Switch User’s Guide Trunk Groups Figure 7-6. Trunk Groups window The Switch supports up to three trunk groups. Trunks are groups of ports that are banded together to form a single, logical, high-bandwidth data pipe. Items in the above window are defined as follows: Anchor The Anchor port for the trunk group.

  • Page 110: Port Mirroring

    Stackable NWay Ethernet Switch User’s Guide Port Mirroring Figure 7-7. Port Mirroring window The Switch allows you to copy frames transmitted and received on a port and redirect the copies to another port. You can attach a monitoring device to the mirrored port, such as a sniffer or an RMON probe, to view details about the packets passing through the first port.

  • Page 111: Stp Switch Settings

    Stackable NWay Ethernet Switch User’s Guide STP Switch Settings Figure 7-8. STP Switch Settings window To configure Spanning Tree Protocol functions for the Switch or individual ports, enter the desired information in the fields on this screen (see the descriptions below for assistance) and then click Apply. The information above is described as follows: Spanning Tree Protocol This option offers Disabled or Enabled to implement the Spanning Tree Protocol.

  • Page 112: Stp Port Settings

    Stackable NWay Ethernet Switch User’s Guide STP Port Settings Figure 7-9. STP Port Settings window Enter the desired Spanning Tree custom settings on this window and then click Apply. The information above is described as follows: STP Status The Spanning Tree Protocol state for a selected port can either be Enabled or Disabled. Cost The Path Cost is a changeable parameter and may be modified according to the Spanning Tree Algorithm specification.
  • Page 113 Stackable NWay Ethernet Switch User’s Guide Figure 7-10. Configure Forwarding Table And Filtering Table window This window allows you to stop or start address learning, use an address look-up mode, and select an age-out time of the MAC address in the selected address table. Click Apply to let your changes take effect. The following fields above can be set: Lock Address Table Mostly used for security purposes, when the forwarding table is locked the Switch will no longer learn the MAC addresses for new hosts.

  • Page 114: Static Forwarding Table

    Stackable NWay Ethernet Switch User’s Guide Static Forwarding Table Figure 7-11. Static Forwarding Table window MAC forwarding allows the Switch to permanently forward outbound traffic to specific destination MAC addresses over a specified port. You can also use this feature to restrict inbound traffic based on source MAC addresses. Click New to access the Static Forwarding Table - Edit window: Web-Based Network Management...
  • Page 115 Stackable NWay Ethernet Switch User’s Guide Figure 7-12. Static Forwarding Table --- Edit window To use the MAC forwarding function, enter the MAC address, switch, and module of the device to which the specified port permanently forwards traffic in the MAC Address field, enter a VLAN ID (if applicable), and enter the port number that permanently forwards traffic from the specified device in the Port field.

  • Page 116: Mac Address Filtering Table

    Stackable NWay Ethernet Switch User’s Guide MAC Address Filtering Table Figure 7-13. Static MAC Address Filtering window The static filtering function allows the Switch to block inbound traffic from unknown or unwanted devices by mapping a port to a source MAC address. Click New to access the Static MAC Address Filtering --- Edit window: Web-Based Network Management...
  • Page 117 Stackable NWay Ethernet Switch User’s Guide Figure 7-14. Static MAC Address Filtering --- Edit window To use the static filtering function, enter the MAC address of the device allowed to send traffic in the MAC Address field, enter a VLAN ID (if applicable), and then click Apply. Web-Based Network Management...

  • Page 118: Static Multicast Filtering

    Stackable NWay Ethernet Switch User’s Guide Static Multicast Filtering Figure 7-15. Static Multicast Filtering window Static multicast filtering blocks or forwards traffic over each port for one multicast group. You can configure each port on the Switch to forward traffic for the specified multicast group. Click New or the pointer icon to access the Static Multicast Filtering --- Edit window: Web-Based Network Management...

  • Page 119: Igmp

    Stackable NWay Ethernet Switch User’s Guide Figure 7-16. Static Multicast Filtering --- Edit window To edit or create a new filter, enter the desired MAC address in the Multicast MAC Address field as well as a VLAN ID in the next field (if applicable). Next, check each port that you want to block traffic for the specified multicast group. Click Apply to activate the filter.

  • Page 120: Igmp Settings

    Stackable NWay Ethernet Switch User’s Guide IGMP Settings Figure 7-17. IGMP Configuration window To configure the IGMP, enter a value between 30 and 999 seconds in the IP Multicast Filtering Age-out Timer field and then change the IP Multicast Filtering (IGMP Snooping) setting from Disabled to Enabled. Click the Apply button to let the changes take effect.

  • Page 121: 802.1Q Igmp

    Stackable NWay Ethernet Switch User’s Guide 802.1Q IGMP Figure 7-18. Add/Remove IGMP Entries window Click the X in the Delete column next to an entry to remove it from the table. Click the pointer icon on the far right to access the Add/Remove IGMP Entries --- Edit window: Web-Based Network Management...
  • Page 122 Stackable NWay Ethernet Switch User’s Guide Figure 7-19. Add/Remove IGMP Entries --- Edit window To edit an 802.1Q IGMP entry, enter a value from 1 to 4094 in the VLAN ID field and then click Apply. Web-Based Network Management...
  • Page 123 Stackable NWay Ethernet Switch User’s Guide Figure 7-20. Configure IGMP Entries window To edit an IGMP Entry on the table above, click the pointer icon on the right side. The Configure IGMP Entries --- Edit window opens: Web-Based Network Management...

  • Page 124: Vlans

    Stackable NWay Ethernet Switch User’s Guide Figure 7-21. Configure IGMP Entries --- Edit window Enter a VLAN ID number in the first field, enter an IGMP entry aging time in the next field, disable or enable IGMP status, and click Apply to let your changes take effect. VLANs This section allows you to create port-based VLANs, IEEE 802.1Q VLANs, and MAC-based Broadcast Domains.

  • Page 125: Mac-Based Broadcast Domains

    Stackable NWay Ethernet Switch User’s Guide Figure 7-22. Configure VLAN window To use one of these three modes, select MAC-based Broadcast Domains, or 802.1Q or Port-based VLANs under Restart VLAN Mode--otherwise, leave the setting at Disabled. Then click Apply and reboot the Switch. MAC-Based Broadcast Domains To use MAC-based Broadcast Domains, you must first create a MAC-based Broadcast Domain using the add/remove function and then add members to the Broadcast Domain using the add/remove member function.
  • Page 126 Stackable NWay Ethernet Switch User’s Guide Figure 7-23. Create/Remove MAC-based Broadcast Domain Entries window Items in this window are defined as follows: Description Lists all MAC-based broadcast domains. Number of MAC address members The number of MAC addresses belonging to the Broadcast Domains. Click the X in the Delete column next to an entry to remove it from the table.
  • Page 127 Stackable NWay Ethernet Switch User’s Guide Figure 7-24. Create/Remove MAC-based Broadcast Domain Entries --- Edit window To add a MAC-based broadcast domain, enter a Description in the field offered. Click Apply to let the change take effect. Description The name of the Broadcast Domain to be added. Web-Based Network Management...
  • Page 128 Stackable NWay Ethernet Switch User’s Guide Figure 7-25. Configure MAC-based Broadcast Domain Member window Items in this window are defined as follows: MAC Address The MAC Address of the broadcast domain member. Description Lists all MAC-based broadcast domains. Status Not-Apply or Active will be displayed here Click the X in the Delete column next to an entry to remove it from the table.
  • Page 129 Stackable NWay Ethernet Switch User’s Guide Figure 7-26. Configure MAC-based Broadcast Domain Member --- Edit window To add or edit a MAC-based broadcast domain member, enter the MAC Address in the first field and use the drop-down Description menu to select the desired broadcast domain. Click Apply to let the changes take effect. Items in this window are defined as follows: MAC Address The MAC address of the member you wish to add.

  • Page 130: Port-Based Vlans

    Stackable NWay Ethernet Switch User’s Guide Port-based VLANs Figure 7-27. Port-based VLAN window Click the pointer icon on the right of the window above to be able to create or change a port-based VLAN entry on the Port Based VLAN Entry window. A read-only version of this window appears when you click the magnifying glass icon in the Browse column.
  • Page 131 Stackable NWay Ethernet Switch User’s Guide Figure 7-28. Port Based VLAN Entry window To either create or make a change to a pre-existing port-based VLAN, enter a VLAN name and make the desired changes (by checking or unchecking port membership for all members of the switch stack). Click Apply to let your changes take effect.

  • Page 132: 802.1Q Vlans

    Stackable NWay Ethernet Switch User’s Guide 802.1Q VLANs Figure 7-29. Port Ingress Filter window Use this window to enable or disable the ingress filtering check for each desired port. Ingress filtering means that a receiving port will check to see if it is a member of the VLAN ID in the packet before forwarding the packet. Click Apply to let the settings take effect.
  • Page 133 Stackable NWay Ethernet Switch User’s Guide Figure 7-30. Port VLAN ID (PVID) window Use this window to assign a default VLAN ID for each desired port. Click Apply to let the settings take effect. Web-Based Network Management...
  • Page 134 Stackable NWay Ethernet Switch User’s Guide Figure 7-31. Port GVRP Settings window Use this window to enable or disable GVRP for each desired port. Click Apply to let the settings take effect. Web-Based Network Management...
  • Page 135 Stackable NWay Ethernet Switch User’s Guide Figure 7-32. 802.1Q Static VLANs window Click the X in the Delete column next to an entry to remove it from the table. Click the pointer icon to access the second 802.1Q Static VLANs --- Edit window: Web-Based Network Management...

  • Page 136: Gmrp

    Stackable NWay Ethernet Switch User’s Guide Figure 7-33. 802.1Q Static VLANs --- Edit window To configure an 802.1Q VLAN entry, enter a VLAN ID number and VLAN Name in the first two fields. Next, select the desired Switch. Finally, check Tag for each member port you wish to be a tagging port. None should be checked if you don’t want a port to belong to a VLAN.
  • Page 137 Stackable NWay Ethernet Switch User’s Guide Figure 7-34. GMRP Configuration window Use this window to disable or enable GMRP on the Switch. Click Apply to let the change take effect. Web-Based Network Management...
  • Page 138 Stackable NWay Ethernet Switch User’s Guide Figure 7-35. Port GMRP Settings window Use this window to enable or disable GMRP on individual ports. Click Apply to let your changes take effect. Web-Based Network Management...
  • Page 139 Stackable NWay Ethernet Switch User’s Guide Figure 7-36. Static Multicast Forwarding window This function forwards traffic over each port for one multicast group. You can configure each port on the Switch to forward traffic for the specified multicast group. Click the pointer icon on the right side of the table above to access the Static Multicast Forwarding --- Edit window: Web-Based Network Management...

  • Page 140: Management

    Stackable NWay Ethernet Switch User’s Guide Figure 7-37. Static Multicast Forwarding --- Edit window To make changes to a static multicast forwarding table entry, enter the multicast MAC address as well as the VLAN ID in the first two fields, respectively. Next, select the desired Switch from the drop-down menu. None, Egress, or Forbidden for each port, and select a State, Permanent, Invalid, Delete on Reset, or Delete on Timeout.

  • Page 141: Community Strings And Trap Receivers

    Stackable NWay Ethernet Switch User’s Guide Community Strings and Trap Receivers Figure 7-38. Community Strings and Trap Receivers window To use the functions on this window, enter the appropriate SNMP information in the Community Strings and Trap Receiving Stations sections--you may enter up to four entries in each section. A trap receiving station is a device that constantly runs a network management application to receive and store traps.

  • Page 142: User Accounts Management

    Stackable NWay Ethernet Switch User’s Guide User Accounts Management Figure 7-39. User Accounts Control Table window Click the pointer icon on the right side to access the User Accounts Control Table --- Edit window: Web-Based Network Management...
  • Page 143 Stackable NWay Ethernet Switch User’s Guide Figure 7-40. User Accounts Control Table - Edit window To add or change a User Account, fill in the appropriate information in the User Name, Old Password (if applicable), New Password, and Confirm New Password fields. Then select the desired access, Normal User or Administrator in the Access Level control and click Apply.

  • Page 144: Console

    Stackable NWay Ethernet Switch User’s Guide Console Figure 7-41. Configure Console window This window allows you to choose the refresh rate in the Console Timeout field (2 minutes, 5 minutes, 10 minutes, 15 minutes or Never). Select the protocol for communicating through the console port, Console or SLIP, in the Serial Port field.

  • Page 145: Switch Overview

    Stackable NWay Ethernet Switch User’s Guide Address Table, IP Multicast & IGMP Information, Browse GVRP Status, Browse GMRP Status, and Switch History. Switch Overview Figure 7-42. Switch Statistics window The information is described as follows: Update Interval Choose the desired setting: 5 seconds, 15 seconds, 30 seconds, 60 seconds or Suspend. Port The selected port to be monitored.

  • Page 146: Port Utilization

    Stackable NWay Ethernet Switch User’s Guide Port Utilization Figure 7-43. Port Utilization window The information is described as follows: Update Interval Choose the desired setting: 5 seconds, 15 seconds, 30 seconds, 60 seconds or Suspend. Last Detected Source Address The MAC address of the last device that sent packets over this port. Web-Based Network Management...

  • Page 147: Port Traffic Statistics

    Stackable NWay Ethernet Switch User’s Guide Port Traffic Statistics Figure 7-44. Port Traffic Statistics window The port statistics shown by default are those for the port you last configured. Once in the individual window, you can click any port on the Switch graphic to show statistics for that port. The information is described as follows: Update Interval Choose the desired setting: 5 seconds, 15 seconds, 30 seconds, 60 seconds or Suspend.

  • Page 148: Port Error Packet Statistics

    Stackable NWay Ethernet Switch User’s Guide Frames Sent Counts the total number of frames transmitted from the port. Frames Received Counts all valid frames received on the port. Total Frames Received Counts the number of frames received on the port, whether they were valid or not. Port Error Packet Statistics Figure 7-45.

  • Page 149: Port Packet Analysis Statistics

    Stackable NWay Ethernet Switch User’s Guide Jabber The number of frames with length more than 1536 bytes and with CRC error or misalignment (bad framing). Late Collision Counts collisions that occur at or after the 64 byte (octet) in the frame. This may indicate that delays on your Ethernet are too long, and you have either exceeded the repeater count or cable length specified in the Ethernet standard.
  • Page 150 Stackable NWay Ethernet Switch User’s Guide The information is described as follows: Update Interval Choose the desired setting: 5 seconds, 15 seconds, 30 seconds, 60 seconds or Suspend. 64 The total number of packets (including bad packets) received that were 64 octets in length (excluding framing bits but including FCS octets).

  • Page 151: Browse Address Table

    Stackable NWay Ethernet Switch User’s Guide Browse Address Table Figure 7-47. Browse Address Table window The Switch allows you to display a table containing Switch ports, MAC addresses, VIDs, and respective learned statuses. If the table doesn’t display the information you want, fill in the requested information in the Search Table By VID, Search Table By MAC Address, or Search Table By Port sections above and then click the Find button on the right side of the section used.

  • Page 152: Ip Multicast & Igmp Information

    Stackable NWay Ethernet Switch User’s Guide IP Multicast & IGMP Information Figure 7-48. IP Multicast & IGMP Information window This window allows you to enter a VID at the top of the window and then display the Queries (Tx)/(Rx), IGMP Snooping status, and current Age-out Time setting for that VLAN ID.

  • Page 153: Browse Gvrp Status

    Stackable NWay Ethernet Switch User’s Guide Browse GVRP Status Figure 7-49. GVRP Status window This window contains information pertaining to GARP (Generic Attribute Registration Protocol) VLAN Registration Protocol (GVRP). Click the Next button at the bottom of the window to view the status of additional IEEE 802.1Q VLANs. Web-Based Network Management...

  • Page 154: Browse Gmrp Status

    Stackable NWay Ethernet Switch User’s Guide Browse GMRP Status Figure 7-50. GMRP Status window This window contains information pertaining to the Group Multicast Registration Protocol (GMRP) status of IEEE 802.1Q VLANs. Web-Based Network Management...

  • Page 155: Switch History

    Stackable NWay Ethernet Switch User’s Guide Switch History Figure 7-51. Switch History window This window allows you to view the Switch history. This works like a trap and event receiver except it only captures trap/events generated by the Switch itself. Click the Next button to view additional pages. Maintenance The fourth and last main category of the Switch Web-based management program includes: Firmware and Configuration Update, Save Settings To TFTP Server, Save Switch History To TFTP Server, Clear...

  • Page 156: Firmware And Configuration Update

    Stackable NWay Ethernet Switch User’s Guide Firmware and Configuration Update Figure 7-52. Firmware and Configuration Update window To update firmware or change a configuration file, fill in the requested information above and then click the Apply button. The information is described as follows: Software Update Mode &...

  • Page 157: Save Settings To Tftp Server

    Stackable NWay Ethernet Switch User’s Guide Use Config File Determines whether or not the Switch should download its configuration file the next time it is booted. Config File Name The path and configuration name on the TFTP server. Save Settings To TFTP Server Figure 7-53.

  • Page 158: Save Switch History To Tftp Server

    Stackable NWay Ethernet Switch User’s Guide Save Switch History To TFTP Server Figure 7-54. Save Switch History To TFTP Server window To save a switch history file to your TFTP server, fill the fields in above and then click Apply. The information is described as follows: Server IP Address The IP address of the TFTP server where the log file will be saved.

  • Page 159: Clear Address Table

    Stackable NWay Ethernet Switch User’s Guide Clear Address Table Figure 7-55. Clear Address Table window Click Apply to clear the address table. Web-Based Network Management...

  • Page 160: Save Changes

    Stackable NWay Ethernet Switch User’s Guide Save Changes Figure 7-56. Save Changes window To save all the changes made in the current session to the Switch’s flash memory, click the Save Configuration button. Web-Based Network Management...

  • Page 161: Factory Reset

    Stackable NWay Ethernet Switch User’s Guide Factory Reset Figure 7-57. Factory Reset to Default Value window Doing a remote reset is equivalent to turning the Switch off and on again. All parameters are returned to the values stored in EEPROM. Click the Reset to Factory Default button to initiate the reset. Web-Based Network Management...

  • Page 162: Restart System

    Stackable NWay Ethernet Switch User’s Guide Restart System Figure 7-58. Restart System window To perform a reboot of the Switch, which resets the system, click the Reset button. Web-Based Network Management...

  • Page 163: Technical Specifications

    Stackable NWay Ethernet Switch User’s Guide ECHNICAL PECIFICATIONS General Standards: IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3z 1000BASE Ethernet IEEE 802.3z 1000BASE-SX/LX Gigabit Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.1 P/Q VLAN IEEE 802.3x Full-duplex Flow Control Protocol: CSMA/CD Data Transfer...

  • Page 164: Physical And Environmental

    Stackable NWay Ethernet Switch User’s Guide General Network 10BASE-T: Cables: 2-pair UTP Cat. 3,4,5 (100 m) EIA/TIA- 568 100-ohm STP (100 m) 100BASE-TX: 2-pair or 4-pair UTP Cat. 5 (100 m) EIA/TIA-568 100-ohm STP (100 m) 100BASE-FX 50µm and 62.5µm multi-mode fiber 1000BASE-SX: 50µm and 62.5µm multi-mode fiber 1000BASE-LX:...
  • Page 165 Stackable NWay Ethernet Switch User’s Guide Physical and Environmental EMI: FCC Class A, CE Class A, VCCI Class A, BSMI Class A, C-Tick Class A Safety: UL, CSA, TUV/GS Performance Transmission Method: Store-and-forward RAM Buffer: 12 Mbytes per device Filtering Address Table: 96 MAC addresses per device (optimized condition) Packet...

  • Page 166: Pin Specification

    Stackable NWay Ethernet Switch User’s Guide RJ-45 P PECIFICATION When connecting the DES-3624 Switch to another switch, a bridge or a hub, a modified crossover cable is necessary. Please review these products for matching cable pin assignment. The following diagram and table show the standard RJ-45 receptacle/connector and their pin assignments for the switch-to-network adapter card connection, and the straight/crossover cable for the switch-to-switch/hub/bridge connection.
  • Page 167 Stackable NWay Ethernet Switch User’s Guide RJ-45 Connector pin assignment Contact Media Direct Interface Signal Tx + (transmit) Tx - (transmit) Rx + (receive) Not used Not used Rx - (receive) Not used Not used Table B-1. The standard Category 3 cable, RJ-45 pin assignment The following shows straight cable and crossover cable connection: Figure B-2.

  • Page 168: Sample Configuration File

    Stackable NWay Ethernet Switch User’s Guide AMPLE ONFIGURATION This appendix provides a sample configuration file that can be used with the Update Firmware and Configuration Files screen in the console program. The configuration file is a simple text file that you create. It has two functions: to point to the location of a file on a TFTP server, and to set the IP address, subnet mask and default gateway for the Switch.
  • Page 169 Stackable NWay Ethernet Switch User’s Guide If both the Firmware Update and Use Config File options are enabled, the Firmware Update command will take precedence and only the firmware file will be uploaded to the switch. The Config image file, which contains all configuration settings and was created by the switch is prefixed with the version number of the runtime software to help with file management.

  • Page 170: Runtime Software Default Settings

    Stackable NWay Ethernet Switch User’s Guide UNTIME OFTWARE EFAULT ETTINGS Load Mode Network Configuration update Disable Firmware update Disable Out-of-band baud rate 9600 Rs232 mode Console Ip address 0.0.0.0 Subnet mask 0.0.0.0 Default router 0.0.0.0 Bootp service Enable TFTP server IP address 0.0.0.0 IGMP time out 300 secs...

  • Page 171: Index

    Stackable NWay Ethernet Switch User’s Guide NDEX 64, 95 Changing the Protocol Parameters, 61 65-127, 95 Changing theSNMP Manager Configuration parameters 100BASE-TX networks, 12 settings, 89 100Mbps Fast Ethernet, 11 Changing your Password, 46, 47 128-255, 95 Community name, definition of, 88 256-511, 95 Community names 512-1023, 95...
  • Page 172 Stackable NWay Ethernet Switch User’s Guide in-band communication, 49 Performing a factory reset, 100 Factory Reset, 100 Performing a System Reset, 99 Fast Ethernet Technology, 11 Port Configuration menu, 54 Features, 12 Port Level, STA Operation Level Ports, 12 Designated Port, 32 RE-232 DCE console port, 12 Path Cost, 32 Uplink/ MDI-II, 12...
  • Page 173 Stackable NWay Ethernet Switch User’s Guide Protocol Parameters, 58 Authentication Failure, 29 Spanning Tree Protocol (STP), 60 Broadcast Storm, 30 STA Operation Levels, 32 Cold Start, 29 On the Bridge Level, 32 Link Change Event, 30 Standard MIB-II, 30 New Root, 29 Static Filtering, definition of, 62 Port Partition, 30 Storage Temperature, 164...
  • Page 174 TEL: 39-02-2900-0676 FAX: 39-02-2900-1723 URL: www.dlink.it E-MAIL: info@dlink.it Japan D-Link Japan 10F, 8-8-15 Nishi-Gotanda, Shinagawa-ku, Tokyo 141, Japan TEL: 81-3-5434-9678 FAX: 81-3-5434-9868 URL: www.d-link.co.jp E-MAIL: kida@d-link.co.jp Netherlands D-Link Benelux Fellenoord 1305611 ZB, Eindhoven, the Netherlands TEL: 31-40-2668713 FAX: 31-40-2668666 URL: www.d-link-benelux.nl...
  • Page 175 South Africa D-Link South Africa 102 – 106 Witchhazel Avenue, Einstein Park 2, Block B, Highveld Technopark, Centurion, South Africa TEL: 27 (0) 12-665-2165 FAX: 27 (0) 12-665-2186 URL: www.d-link.co.za E-MAIL: attie@d-link.co.za Spain D-Link Iberia Gran Via de Carlos III, 843º Edificio Trade, 08028 Barcelona, Spain TEL: 34 93 4965751 FAX: 34 93 4965701 URL: www.dlinkiberia.es...

  • Page 176: Registration Card

    8. What category best describes your company? oAerospace oEngineering oEducation oFinance oHospital oLegal oInsurance/Real Estate oManufacturing oRetail/Chainstore/Wholesale oGovernment oTransportation/Utilities/Communication oVAR oSystem house/company oOther________________________________ 9. Would you recommend your D-Link product to a friend? oYes oNo oDon't know yet 10.Your comments on this product? __________________________________________________________________________________________...

This manual is also suitable for:

Des-3624Des-3624ifDes-3624ifmDes-3624fDes-3624fm

Table of Contents
