Page 1 DES-3624 Series Stackable NWay Ethernet Switch User’s Guide Second Edition (April, 2000) 6DES3624..02 Printed In Taiwan RECYCLABLE...
Page 2: Wichtige Sicherheitshinweise
Wichtige Sicherheitshinweise Bitte lesen Sie sich diese Hinweise sorgfältig durch. Heben Sie diese Anleitung für den spätern Gebrauch auf. Vor jedem Reinigen ist das Gerät vom Stromnetz zu trennen. Vervenden Sie keine Flüssig- oder Aerosolreiniger. Am besten dient ein angefeuchtetes Tuch zur Reinigung.
Page 3: Limitation Of Liability
OR BY ACCIDENT, FIRE, LIGHTNING OR OTHER HAZARD. LIMITATION OF LIABILITY IN NO EVENT WILL D-LINK BE LIABLE FOR ANY DAMAGES, INCLUDING LOSS OF DATA, LOSS OF PROFITS, COST OF COVER OR OTHER INCIDENTAL, CONSEQUENTIAL OR INDIRECT DAMAGES ARISING OUT THE INSTALLATION, MAINTENANCE, USE, PERFORMANCE, FAILURE OR INTERRUPTION OF A D- LINK PRODUCT, HOWEVER CAUSED AND ON ANY THEORY OF LIABILITY.
Page 4: Limited Warranty
Warranty service may be obtained by contacting a D-Link office within the applicable warranty period, and requesting a Return Material Authorization (RMA) number. If a Registration Card for the product in question has not been returned to D-Link, then a proof of purchase (such as a copy of the dated purchase invoice) must be provided.
Page 5: Copyright Statement
Copyright 2000 D-Link Corporation. Contents subject to change without prior notice. D-Link is a registered trademark of D-Link Corporation/D-Link Systems, Inc. All other trademarks belong to their respective proprietors. Copyright Statement No part of this publication may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from D-Link Corporation/D-Link Systems Inc., as...
Page 6: Table Of Contents
100BASE-TX Module ... 22 1000BASE-SX Gigabit Module ... 22 1000BASE-LX Gigabit Module ... 23 1000BASE-T Copper Gigabit Module... 23 LED I ... 24 NDICATORS CONNECTING THE SWITCH ... 26 ... 26 WITCH TO ... 26 WITCH TO UB OR WITCH 10BASE-T Device...
Page 7 System Configuration ... 48 Configure IP Address ... 49 Configure Console... 51 Configure Switch Stack ... 52 Information of Individual Switch Unit ... 53 Advance Settings ... 54 Configure Port ... 55 Configure Trunk ... 57 Configure Port Mirroring ... 59 Configure Spanning Tree Protocol ...
Page 8 Switch History ... 142 Maintenance... 142 Firmware and Configuration Update ... 143 Save Settings To TFTP Server... 144 Save Switch History To TFTP Server... 145 Save Changes... 146 Factory Reset ... 147 Restart System ... 148 TECHNICAL SPECIFICATIONS ... 149 RJ-45 PIN SPECIFICATION ...
Page 9 RUNTIME SOFTWARE DEFAULT SETTINGS ... 156 INDEX... 157...
Page 10: About This Guide
Explorer, 4.x or later, are recommended). Conventions References in this manual to the DES-3624 Series are frequently written simply as “Switch” or “Switches” where the text applies to all models. Model numbers are normally used only to differentiate among specific Switches where necessary.
Page 11: Introduction
Stackable NWay Ethernet Switch User’s Guide NTRODUCTION This section describes the features of the Switch, as well as giving some background information about Ethernet/Fast Ethernet, Gigabit Ethernet, and switching technology. Fast Ethernet Technology The growing importance of LANs and the increasing complexity of desktop computing applications are fueling the need for high performance networks.
Page 12: Switching Technology
Features The DES-3624 series of Switches can include one master (DES-3624I, DES-3624iF, or DES-3624iFM) and up to three clients (DES-3624, DES-3624F, or DES-3624FM). They are designed for easy installation and high performance in an environment where traffic on the network and the number of users increases continuously.
Page 13: Performance Features
2-port TX, 2-port FX (MT-RJ), and 1-port FX (SC). Stacking Input/Output port slide-in module in the rear panel for stacking to another device to implement a high-port count, manageable switch. Three-port module for master device and one-port module for a client device.
Page 14: Unpacking And Setup
One RS-232 cable (master only) This user’s guide on CD-ROM with a Registration Card If any item is found missing or damaged, please contact your local D-Link reseller for replacement. Setup The setup of the Switch can be performed using the following steps: The surface must support at least 5 kg.
Page 15: Rack Installation
Rack Installation The Switch can be mounted in an EIA standard size, 19-inch rack, which can be placed in a wiring closet with other equipment. To install, attach the mounting brackets on the switch’s front panel (one on each side) and secure them with the screws provided.
Page 16: Power On
Power On The Switch can be used with AC power sources 100 - 240 VAC, 50 - 60 Hz. The power switch is located at the rear of the unit adjacent to the AC power connector and the system fan. The Switch’s power supply will adjust to the local power source automatically and may be turned on without having any or all LAN segment cables connected.
Page 17: Identifying External Components
2-port TX, 2-port FX (MT-RJ), or 1-port FX (SC). One or two MDI-II uplink jacks are supported. Port numbers 1 and 2 on the DES-3624, DES-3624F, and DES-3624FM are equipped with MDI-X jacks for normal end-node connections and MDI-II jacks for uplink connections.
Page 18: Rear Panel
Rear Panel The rear panel of the DES-3624, DES-3624F, and DES-3624FM consist of a slot (labeled Slot2) for a Stacking input/output port and an AC power connector. The rear panel of the DES-3624i, DES-3624iF, and DES- 3624iFM consist of two slots (labeled Slot2 and Slot3). Slot2 is for Stacking input/output ports Sio1, Sio2, and Sio3.
Page 19: Stack Operation
The DES-3624i, DES-3624iF, and DES-3624iFM are all intelligent Switches capable of acting as a master for up to three slave Switches (DES-3624, DES-3624F, or DES-3624FM). Each port is referred to by unit ID and port number in your DES-3624 Series stack.
Page 20: Optional Plug-In Modules
Stackable NWay Ethernet Switch User’s Guide Figure 3-5. Switch stack with example of possible connections Optional Plug-in Modules The DES-3624i/DES-3624iF/DES-3624iFM Stackable NWay Ethernet Switch is able to accommodate a range of plug-in modules in order to increase functionality and performance. Identifying External Components...
Page 21: 100Base-Fx (Mt-Rj) Module
Stackable NWay Ethernet Switch User’s Guide 100BASE-FX (MT-RJ) Module Two-port, front-panel module. Connects to 100BASE-FX devices at full- or half-duplex. Supports multi-mode fiber-optic cable connections of up to 412 meters in half-duplex or 2 km in full-duplex mode. 100BASE-FX (SC) Module One-port, front panel module.
Page 22: 100Base-Tx Module
One- or two-port, rear-panel module. Connects to 1000BASE-SX devices at full duplex. Allows connections using multi-mode fiber optic cable in the following configurations: Figure 3-8. Two-port, 100BASE-TX module Figure 3-9. One-port, 1000BASE-SX gigabit module Stackable NWay Ethernet Switch User’s Guide Identifying External Components...
Page 23: 1000Base-Lx Gigabit Module
Stackable NWay Ethernet Switch User’s Guide Modal bandwidth (min. overfilled launch) Operating distance Channel insertion loss 1000BASE-LX Gigabit Module One- or two-port, rear-panel module. Connects to a 1000BASE-LX device at full duplex. Allows connections up to 5 km in length using single-mode fiber optic cable.
Page 24: Led Indicators
Sio1 This indicator is lit green when a Stacking IO port is present in the rear panel of the Switch. Sio2 This indicator is lit green when a Stacking IO port is present in the rear panel of the Switch.
Page 25 Stackable NWay Ethernet Switch User’s Guide 100M These indicators are illuminated green when a 100 Mbps device is connected to any of the 22+2 or 20+2 ports or uplink port. If a 10 Mbps device is connected to any of the 24 ports or uplink port, these LEDs remain dark.
Page 26: Connecting The Switch
MDI-II port must connect to an MDI-X port. An end node can be connected to the Switch via a two-pair Category 3, 4, 5 UTP/STP straight cable (be sure to use Category 5 UTP or STP cabling for 100 Mbps Fast Ethernet connections). The end node should be connected to any of the twenty-two ports (1x - 22x) of the Switch or to either of the two 100BASE-TX ports on the front-panel module that came preinstalled on the Switch.
Page 27: 10Base-T Device
If the other switch or hub contains an unused Uplink port, we suggest connecting the other device’s Uplink (MDI-II) port to any of the switch’s (MDI-X) ports (1x - 22x, or one of the 100BASE-TX module ports) using a normal straight-through cable, as shown below.
Page 28: Switch Management Concepts
Switch. Hardware components in the Switch allow it to be an active part of a manageable network. These components include a CPU, memory for data storage, other related hardware, and SNMP agent firmware. Activities on the Switch can be monitored with these components, while the Switch can be manipulated to carry out specific tasks.
Page 29: Ip Addresses And Snmp Community Names
Traps Traps are messages that alert you of events that occur on the Switch. The events can be as serious as a reboot (someone accidentally turned OFF the Switch), or less serious like a port status change. The Switch generates traps and sends them to the network manager (trap managers).
Page 30: Mibs
Switch transmits that packet through Port 2 only, and transmits nothing through the other ports. Aging Time The Aging Time is a parameter that affects the auto-learn process of the Switch in terms of the network configuration. Dynamic Entries, which make up the auto-learned-node address, are aged out of the address table according to the Aging Time that you set.
Page 31: Filtering Database
These backup paths are idle until the Switch determines that a problem has developed in the primary paths. When a primary path is lost, the switch providing the alternative path will automatically go into service with no operator intervention. This automatic network reconfiguration provides maximum uptime to network users.
Page 32: Sta Operation Levels
Designated Bridge. Root Path Cost The Root Path Cost of a switch is the sum of the Path Cost of the Root Port and the Root Path Costs of all the switches that the packet goes through. The Root Path Cost of the Root Bridge is zero.
Page 33: Illustration Of Sta
Stackable NWay Ethernet Switch User’s Guide Root Bridge. If you set a Hello Time for your Switch, and it is not the Root Bridge, the set Hello Time will be used if and when your Switch becomes the Root Bridge.
Page 34: Port Trunking
The Switch supports 3 trunk groups, which may include from 2 to 8 switch ports each, except for the third trunk group which consists of the 2 ports of the Slot 1, 100BASE-TX or 100BASE-FX front-panel module. The anchor port for the first group is preset as port 5, the anchor port for the second group is port 13 and the anchor port for the third group is the first port (1x) on the 2-port module.
Page 35: Vlan
Stackable NWay Ethernet Switch User’s Guide Figure 5-3. Port trunking example The switch treats all ports in a trunk group as a single port. As such, trunk ports will not be blocked by Spanning Tree (unless a redundant link with higher STP priority is present).
Page 36: Ieee 802.1Q Vlans
VLAN 2 packets). If port 10 is not a member of VLAN 2, then the packet will be dropped by the switch and will not reach it’s destination. If Port 10 is a member of VLAN 2, the packet will go through.
Page 37: Vlans Spanning Multiple Switches
Egress port A port on a switch where packets are flowing out of the switch, either to another switch or to an end station, and tagging decisions must be made. If an egress port is connected to an 802.1Q-compliant switch, tagging should be enabled so the other switch can take VLAN data into account when making forwarding decisions.
Page 38: Vlans Over 802.1Q-Compliant Switches
Broadcast transmissions, packets sent to every device on the LAN, are a vital part of any network. However, they can often cause problems on the network and even network failure. For this reason the Switch has a number of tools for managing broadcast packets on your network.
Page 39: Broadcast Storms
Port-based Broadcast Packet Filter The Switch is equipped with sensors that count the number of broadcast frames arriving at each port. When a certain level (rising threshold) is reached, the sensors can initiate a broadcast filter (rising action) which drops all broadcast packets arriving at the affected port.
Page 40: Using The Console Interface
Your Stackable NWay Ethernet Switch supports a console management interface that allows you to set up and control your Switch, either with an ordinary terminal (or terminal emulator), or over the network using the TCP/IP Telnet protocol. You can use this facility to perform many basic network management functions. In addition, the console program will allow you to set up the Switch for management using an SNMP-based network management system.
Page 41: Connecting To The Switch Using Telnet
Connecting to the Switch Using Telnet Once you have set an IP address for your Switch, you can use a Telnet program (in a VT-100 compatible terminal mode) to access and control the Switch. Most of the screens are identical, whether accessed from the console port or from a Telnet interface.
Page 42 Stackable NWay Ethernet Switch User’s Guide Figure 6-2. Initial Screen, first time connecting to the Switch Note: There is no initial username or password. Leave the username and password fields blank. Press <Enter> or <Return> in the username and password fields. You will be given access to the main menu...
Page 43: User Accounts Management
Stackable NWay Ethernet Switch User’s Guide The first user automatically gets Administrator privileges (See Table 6-1). It is recommended to create at least one Administrator-level user for the Switch. User Accounts Management From the screen above, move the cursor to the User Accounts Management menu and press Enter, then the Users Accounts Management menu appears.
Page 44: Save Changes
RAM, and will immediately take effect. Some settings, though, require you to restart the Switch before they will take effect. Restarting the Switch will erase all settings in RAM and reload them from the NV-RAM. Thus, it is necessary to save all settings to the NV-RAM before restarting the Switch.
Page 45: Login On The Switch Console By Registered Users
Figure 6-4. Save Changes screen After the settings have been saved to NV-RAM, they will become the default settings for the Switch, and they will be used every time it is powered on, reset or rebooted. The only exception to this is a factory reset, which will clear all settings and restore them to their initial values listed in Appendix D, which were present when the Switch was purchased.
Page 46 Stackable NWay Ethernet Switch User’s Guide 1. Choose Users Accounts Management from the main menu. The following User Accounts Management menu appears: Figure 6-5. User Accounts Management menu 2. Choose Create/Modify User Accounts. The following screen appears: Using the Console Interface...
Page 47: View/Delete User Accounts
Stackable NWay Ethernet Switch User’s Guide Figure 6-6. Add/Modify User Accounts screen 3. Type in your Username and press Enter. 4. If you are an old user, type in the Old Password and press Enter. 5. Type in the New Password you have chosen, and press Enter. Type in the same new password in the following field to verify that you have not mistyped it.
Page 48: Setting Up The Switch
This section will help prepare the Switch user by describing the System Configuration, Update Firmware and Configuration Files, Save Changes, and System Utilities menus and their respective sub-menus. System Configuration Choose System Configuration to access the first item of the Switch’s main menu. The following menu appears: Using the Console Interface...
Page 49: Configure Ip Address
Figure 6-8. System Configuration menu You will need to change some settings to allow you to be able to manage the Switch from an SNMP-based Network Management System such as SNMP v1 or to be able to access the Switch using the Telnet protocol.
Page 50 The BOOTP protocol allows IP addresses, network masks, and default gateways to be assigned on a central BOOTP server; if this option is set the Switch will first look for a BOOTP server to provide it with this information before using the supplied settings.
Page 51: Configure Console
SLIP or console port type settings. Baud Rate Determines the serial port bit rate that will be used the next time the Switch is restarted. Applies only when the serial port is being used for out-of-band (SLIP) management; it does not apply when the port is used for the console port.
Page 52: Configure Switch Stack
The fields you can set are: System Name Corresponds to the SNMP MIB II variable name to the Switch for administrative purposes. The Switch’s fully qualified domain name is often used, provided a name has been assigned. System Location Corresponds to the SNMP MIB II variable indicate the physical location of the Switch for administrative purposes.
Page 53: Information Of Individual Switch Unit
Figure 6-12A. Information of Individual Switch Unit screen Use the space bar to select the desired Switch in your stack. For example, if there were two Switches, the master would look like the screen above and the client would look like the screen below:...
Page 54: Advance Settings
Figure 6-12B. Information of Individual Switch Unit screen Advance Settings The Configure Advanced Switch Features screen allows you to set an expiration time for MAC address entries and enable or disable auto-partitioning on all ports. Press ADVANCE SETTINGS on the Switch...
Page 55: Configure Port
If a port is partitioned, the Switch can only transmit data, not receive it. Head Of Line (HOL) Blocking Prevention Enables or disables Head-Of-Line Blocking Prevention.
Page 56 Flow Ctrl Toggles flow control On or Off. It is useful during periods of heavy network activity when the Switch’s buffers can receive too much traffic and fill up faster than the Switch can forward the information. In such cases, the Switch will intervene and tell the transmitting device to pause to allow the information in the port buffer to be sent.
Page 57: Configure Trunk
They are read-only fields and cannot be changed. Configure Trunk Ports on the Switch can be grouped together in a single logical port called a trunk. This is discussed in detail in the Port Trunking section of the “Switch Management Concepts” chapter of this manual.
Page 58 Anchor There are either two or three listings representing the anchor port for each of the three trunk groups available on the Switch (the third listing will only be displayed if an optional two-port plug-in module is being used). The anchor port must fall within the port range and be included as a member port.
Page 59: Configure Port Mirroring
Choose Configure Port Mirroring on the System Configuration menu to access the following screen: To configure a mirror port, select the Switch, Module, and Port from where you want to copy frames in the Source fields. Then select the Switch, Module, and Port which receive the copies from the source port in Destination fields.
Page 60: Stp Parameter Settings
Stackable NWay Ethernet Switch User’s Guide recommended that you read this, as well as the introductory section in the same chapter entitled Spanning Tree Algorithm, before changing any of the parameters. STP Parameter Settings To change the Protocol Parameters: 1. Choose Configure Spanning Tree Protocol from the System Configuration menu. The following Configure Spanning Tree Protocol menu will be displayed: Figure 6-17.
Page 61 Changes usually occur on the network when backup paths are activated. Designated Root Read-only object displays the MAC (Ethernet) address of the bridge/switch on the network that has been chosen as the STP root.
Page 62: Stp Custom Settings
BPDU packets sent by the Root Bridge to tell all other switches that it is indeed the Root Bridge. If you set a Hello Time for your Switch, and it is not the Root Bridge, the set Hello Time will be used if and when your Switch becomes the Root Bridge.
Page 63: Configure Filtering And Forwarding Table
Configure Filtering and Forwarding Table When a packet hits the Switch, it looks in the filtering and forwarding tables to decide what to do with the packet; either to filter it off the network, or to forward it through the port on which its destination lies.
Page 64 The Configure Filtering and Forwarding table screen allows you to stop or start address learning, change the way the Switch treats MAC address table entries, and select an age-out time of the MAC address in the selected address table. This screen also permits you to access three additional configuration screens from the menu at the bottom of the window.
Page 65: Configure Static Forwarding Table Entry
A total of ten destination addresses per page will be seen at the bottom of the screen. The Switch can hold up to 256 entries. Using the Console Interface...
Page 66: Configure Mac Address Filtering
Switch, Module, and Port The Switch, module, and port number are entered in these fields at the top of the screen. The Switch will always forward traffic to the specified device through this port. The bottom of the screen will display each corresponding destination address for these three items.
Page 67: Configure Permanent Multicast Filtering
Filtering is enabled, the Switch can intelligently forward (rather that broadcast) IGMP queries and reports sent between devices connected to the Switch and an IGMP-enabled device hosting IGMP on your network. Basically, in these submenus you define whether the Switch can intelligently forward IGMP packets, and you must also define which 802.1Q VLANs (if present) can send and receive IGMP and Multicast packets.
Page 68 IGMP and Multicast packets instead of broadcasting (flooding) them on all ports. This setting also enables IGMP Snooping, which enables the switch to read IGMP packets being forwarded through the switch in order to obtain forwarding information from them (learn which ports contain Multicast members).
Page 69 Stackable NWay Ethernet Switch User’s Guide Figure 6-25. IEEE 802.1q IGMP Configuration screen Choose Add/Remove IGMP Control Table from the screen above to define up to 12 VLANs on the Switch which can send and receive IGMP packets: Using the Console Interface...
Page 70 The above screen is used to specify an agent to interface between IGMP and VLAN. The agents are assigned to a VLAN and allow IGMP query and report packets to be present on the given VLAN. Only 12 agents can exist on the switch at any one time. Items in the above screen are described below: Action Adds/Removes an entry (agent) from the table.
Page 71: Configure Vlans & Mac-Based Broadcast Domains
VLAN ID This is the VID number for the VLAN that has an agent attached to it which enables IGMP packets to be sent and received. Age-out Timer If no IGMP query packet has arrived at the Switch before this timer has expired, the Switch will become the IGMP host for this VLAN.
Page 72: Configure Mac-Based Broadcast Domains
SNMP Vlan If the IEEE 802.1Q VLANs mode is selected, you must also enter a SNMP VLAN ID number in this field. This is a special VLAN that you designate for SNMP management packets. Make sure the Switch port that the management station is connected to has this PVID number and is a static member of this VLAN.
Page 73 Stackable NWay Ethernet Switch User’s Guide Please note that if the mode is set to MAC-Based Broadcast Domains, then the Port Lock function is not supported in the Port Configuration screen and the Lock Address Table function located on the Configure Filtering and Forwarding table screen is not available.
Page 74 Broadcast Domains and Number of Members reflect the current status. They are read-only fields and cannot be changed. Choose Add/Remove MAC-based Broadcast Domain Members from the MAC-Based Broadcast Domains Configuration menu to access the following screen: Stackable NWay Ethernet Switch User’s Guide Using the Console Interface...
Page 75 Stackable NWay Ethernet Switch User’s Guide Figure 6-31. Add/Remove MAC-based Broadcast Domain Members screen To configure a broadcast domain, highlight the desired entry on the screen above and press ENTER. The following Add/Remove MAC-based Broadcast Domain Members screen appears: Using the Console Interface...
Page 76: Configure Ieee 802.1Q Vlans
MAC Address The MAC address of the broadcast domain member being added or removed. Please note that the Status field for the MAC address you have entered may read Not-Apply. Once the Switch is restarted in MAC-based broadcast domain mode, the MAC-addresses will be applied, meaning that the broadcast domain is active.
Page 77 Stackable NWay Ethernet Switch User’s Guide 2. Define which ports will be active members of the VLAN. A port can transmit packets onto only one VLAN. It can receive packets (be a passive member) on many VLANs. Active VLANs are designations defined by assigning Port VLAN ID numbers (PVIDs) in the Default port VLAN assignment screen.
Page 78 Stackable NWay Ethernet Switch User’s Guide Figure 6-34. Ingress Filtering Check screen This screen allows you to set Ingress filtering for each port to either Enabled or Disabled. When a packet arrives at the port and Ingress filtering is Enabled, the port will check the VLAN ID number of the packet, and its own VIDs.
Page 79 Stackable NWay Ethernet Switch User’s Guide Figure 6-35. Default port VLAN assignment screen This screen allows you to set a Default port VLAN ID number (PVID) for each port. Press CTRL+S to let the changes take effect. Note: If a port is a member of a trunk group but is not the anchor, the items shown in the above table will be read-only and the values will be the same as those for the anchor port.
Page 80 State Toggle between Active and Inactive. Choose Browse 802.1Q VLAN Entries at the bottom of the 802.1Q Static VLAN Settings screen to access the following screen: Figure 6-36. 802.1Q Static VLAN Settings screen Stackable NWay Ethernet Switch User’s Guide Using the Console Interface...
Page 81: Update Firmware And Configuration Files
Update Firmware and Configuration Files The Switch is capable of obtaining its configuration settings (the same settings defined in this console program), as well as updated versions of its internal switching software (the console program itself), using TFTP (Trivial File Transfer Protocol).
Page 82 File Name The complete path and filename of the runtime image file on your TFTP server to be uploaded to the Switch. Use Config File Toggle to Enabled to use the settings in a configuration text file when the switch is reset (rebooted). The configuration file is explained in detail in the Sample Configuration File Appendix.
Page 83: Special Note Concerning Firmware Updates
4. Firmware updates are handled by the PROM code, which doesn’t recognize VLAN tags. You should therefore make sure the Switch port to which the TFTP server is connected is not a tagging port. System Utilities The Utilities menu offers four system utility options, Ping Test, Save Settings to TFTP Server, Save Switch History to TFTP Server, and Clear Address Table.
Page 84: Ping Test
The fields you can set are: Destination IP Address The IP address of the device to be Pinged. Repetition Amount of times the Switch should send the Ping (1-255). If zero is chosen, the Switch will continue Pinging indefinitely. In the lower part of the Ping Test screen, you can view the Ping status, including Result, Reply, Time out, and Unreachable.
Page 85: Save Switch History To Tftp Server
File Name The complete path and filename for the file. Save Switch History to TFTP Server Choose Save Switch History to TFTP Server from the Utilities menu (under System Utilities on the main menu) to access the following screen: Using the Console Interface...
Page 86: Clear Address Table
The Switch sends out SNMP traps to network management stations whenever certain exceptional events occur, such as when the Switch is turned on or when a system reset occurs. The Switch allows traps to be routed to up to four different network management hosts.
Page 87 A community name is an arbitrary string of characters used as a “password” to control access to the Switch. If the Switch receives a request with a community name it does not recognize, it will trigger an authentication trap.
Page 88: Switch Monitoring
The Switch uses an SNMP agent which monitors different aspects of network traffic. The SNMP agent keeps counters and statistics on the operation of the Switch itself, and on each port on the Switch. The statistics obtained can be used to monitor the conditions and general efficiency of the Switch.
Page 89: Traffic Statistics
Stackable NWay Ethernet Switch User’s Guide Traffic Statistics To display the Traffic Statistics menu, choose the first item on the Network Monitoring menu. The following menu appears: Figure 6-45. Traffic Statistics menu Port Utilization To access the first item on the Traffic Statistics menu, choose Port Utilization. The following table...
Page 90: Port Traffic Statistics
Select the desired device in the Switch field and the desired increment setting in the Update Interval field: 5 sec, 15 sec, 30 sec, 1 min, or Suspend. The statistic counters displayed are defined as follows: TX/sec The number of good bytes sent from the respective port per second.
Page 91 Stackable NWay Ethernet Switch User’s Guide Select the desired device in the Switch field, the desired setting in the Ports field, and the desired increment setting in the Update Interval field: 5 sec, 15 sec, 30 sec, 1 min, or Suspend.
Page 92: Port Packet Error Statistics
To access the third item on the Traffic Statistics menu, choose Port Packet Error Statistics. The following table appears: Select the desired device in the Switch field, the desired setting in the Ports field, and the desired increment setting in the Update Interval field: 5 sec, 15 sec, 30 sec, 1 min, or Suspend.
Page 93: Port Packet Analysis Statistics
To access the fourth item on the Traffic Statistics menu, choose Port Packet Analysis Statistics. The following table appears: Select the desired device in the Switch field, the desired port in the Port field, and the desired increment setting in the Update Interval field: 5 sec, 15 sec, 30 sec, 1 min, or Suspend.
Page 94: Browse Address Table
Browse Address Table The Browse Address Table allows the user to view which Switch port(s) a specific network device uses to communicate on the network. You can sort this table by MAC address or port. This is useful for viewing which ports one device is using, or which devices are using one port.
Page 95: Switch History
The lower part of the screen is a read-only Browse Address Table that contains the Total Addresses in Table, as well as the Switch, Module, Port, MAC Address, and Learned status of each entry. Use F3 to advance to the next page and F4 to return to the previous page.
Page 96: Browse Igmp Status
Switch is able to recognize IGMP queries and reports sent between stations and an IGMP router. When enabled for IGMP snooping, the Switch can open or close a port to specific devices based on the IGMP messages sent from the device to the router or vice versa.
Page 97 This screen displays the number of IGMP queries and reports for each active IP multicast group detected by the Switch. You can also view which Switch ports support each multicast group and enter a VLAN number in the field on the right.
Page 98: Resetting The Switch
Resetting the Switch You can use the console interface to reset the Switch, either performing a Restart System or a Factory Reset (which sets all of the Switch’s parameters to what they were when the Switch was delivered from the factory).
Page 99: Logout
To exit the console program, choose Logout from the main menu. Make sure you have performed a Save Changes if you have made changes to the settings and wish them to become defaults for the switch. After logging out, you will be returned to the opening login screen.
Page 100: Web-Based Network Management
This opens the main page in the management module. The top of each page contains an interactive view of the Switch’s front panel. If your Switch is part of a stack, there will also be an icon representing each Switch in the stack on the left side of this panel. Click on the desired Switch to view that Switch’s front panel.
Page 101: Configuration
Each page contains the following list of buttons in the panel on the left side: Configuration, Management, Monitoring, and Maintenance. These are the main categories for Switch management. Clicking on one of the categories causes a list of options to appear below.
Page 102: Switch
You can change the IP Address, Subnet Mask, and Default Gateway on the Switch. If your are not using BOOTP, enter the IP Address, Subnet Mask, and Default Gateway of the Switch. If you enable BOOTP Service, you do not need to configure any IP parameters because a BOOTP server automatically assigns IP configuration parameters to the Switch.
Page 103 Stackable NWay Ethernet Switch User’s Guide To set basic Switch settings, enter a System Name in the first field, the physical location of the Switch in the System Location field, and the name of the contact person responsible for the Switch in the System Contact field.
Page 104: Advanced
Advanced Figure 7-3. Configure Switch Stack – Advanced window The first setting allows you to enable or disable port auto-partitioning by the Port’s Auto-Partition Capability on All Ports function. If you enable auto-partitioning on all ports, when more than 62 collisions occur while a port is transmitting data, the port automatically stops transmissions.
Page 105: Switch Unit
Figure 7-4. Information Of Individual Switch Unit window This window displays the Module, Type, and Hardware Revision of each individual Switch unit. Select the desired Switch in the field in the lower left-hand corner. A Refresh button is located in the lower right-hand corner.
Page 106: Port
Port Select the port you want to configure by clicking on the port in the Switch front panel display at the top of the screen or by using the Switch, Slot, and Port fields at the bottom of the screen. Then follow these steps: 1.
Page 107: Port Trunk
4. Configure the Locked setting to prevent the port from learning the MAC addresses of new hosts. This will help keep intruders off your network since any packet coming from an unknown source address will be dropped by the Switch, that is, not added to your MAC Address Forwarding Table. Select Enabled or Disabled.
Page 108: Port Mirroring
The Switch supports up to three trunk groups. Trunks are groups of ports that are banded together to form a single, logical, high-bandwidth data pipe. Items in the above window are defined as follows: Anchor The Anchor port for the trunk group. All configuration settings changes made to the anchor port will automatically be made to the other ports in the trunk.
Page 109: Spanning Tree Protocol
Stackable NWay Ethernet Switch User’s Guide To configure a mirror port, select the Switch, Slot, and source Port from where you want to copy frames in the Source section. Next, select the Switch, Slot and target Port which will receive the copies from the source port in the Destination section.
Page 110: Stp Custom Setting
BPDU packets sent by the Root Bridge to tell all other switches that it is indeed the Root Bridge. If you set a Hello Time for your Switch, and it is not the Root Bridge, the set Hello Time will be used if and when your Switch becomes the Root Bridge.
Page 111: Forwarding And Filtering
Forwarding and Filtering When a packet hits the Switch, it looks in the filtering and forwarding tables to decide what to do with the packet; either to filter it off the network, or to forward it through the port on which its destination lies.
Page 112: Static Forwarding Table
Lock Address Table(Stop Learning) Mostly used for security purposes, when the forwarding table is locked the Switch will no longer learn the MAC addresses for new hosts. If your network configuration doesn’t change, locking the forwarding table helps keep intruders off your network since any packet coming from an unknown source address will be dropped by the Switch.
Page 113 Stackable NWay Ethernet Switch User’s Guide To use the MAC forwarding function, enter the MAC address of the device to which the specified port permanently forwards traffic in the Destination MAC Address field and enter the port number that permanently forwards traffic from the specified device in the Destination Port Number field. Then click Apply.
Page 114: Mac Address Filtering Table
MAC Address Filtering Table Figure 7-13. Static MAC Address Filtering window The static filtering function allows the Switch to block inbound traffic from unknown or unwanted devices by mapping a port to a source MAC address. Click New to access the Static MAC Address Filtering - Edit window:...
Page 115 Stackable NWay Ethernet Switch User’s Guide Figure 7-14. Static MAC Address Filtering---Edit window To use the static filtering function, enter the MAC address of the device allowed to send traffic in the MAC Address field and then click Apply. The information above is described as follows: MAC Address The Ethernet address of the Static MAC Address Filtering table entry.
Page 116: Permanent Multicast Filtering
Static multicast filtering blocks or forwards traffic over each port for one multicast group. You can configure each port on the Switch to forward traffic for the specified multicast group. Click New to access the Static Permanent Multicast Filtering - Edit window:...
Page 117: Igmp
Figure 7-16. Static Permanent Multicast Filtering--Edit window To edit or create a new filter, enter the MAC address in the MAC Address field, select the desired Switch and Port in the next two fields. Next, select Forward or Block for each port, deciding whether that port transmits or blocks traffic for the specified multicast group.
Page 118: Igmp Settings
Stackable NWay Ethernet Switch User’s Guide IGMP Settings Figure 7-17. Configure IGMP window To configure the IGMP, enter a value between 30 and 999 seconds in the IP Multicast Filtering Age-out Timer field and then change the IP Multicast Filtering (IGMP Snooping) setting from Disabled to Enabled.
Page 119: 802.1Q Igmp
Stackable NWay Ethernet Switch User’s Guide 802.1Q IGMP Figure 7-18. Add/Remove IGMP Table window Click the X in the Delete column next to an entry to remove it from the table. Click the pointer icon on the far right to access the Add/Remove IGMP Table-Edit window:...
Page 120: Vlans & Mac-Based Broadcast Domains
Stackable NWay Ethernet Switch User’s Guide Figure 7-19. Add/Remove IGMP Table-Edit window To edit an 802.1Q IGMP entry, enter a value from 1 to 4094 in the VLAN ID field and then click Apply. VLANs & MAC-based Broadcast Domains IEEE 802.1Q VLANs allow you to construct a port group as well as to reduce traffic. All packets are limited to members of the VLAN.
Page 121: Mac-Based Broadcast Domains
Stackable NWay Ethernet Switch User’s Guide Figure 7-20. Configure VLAN window To use one of these two modes, select MAC-based Broadcast Domains or IEEE 802.1Q VLANs under Restart VLAN Mode--otherwise, leave the setting at Disabled. Then specify the VLAN ID number in the SNMP VLAN field and click Apply.
Page 122 Click the X in the Delete column next to an entry to remove it from the table. Click New to access the Add/Remove MAC-based Broadcast Domains --- Edit window: Stackable NWay Ethernet Switch User’s Guide The number of MAC addresses belonging to the Broadcast...
Page 123 Stackable NWay Ethernet Switch User’s Guide Figure 7-22. Add/Remove MAC-based Broadcast Domains --- Edit window To add a MAC-based broadcast domain, enter a Description in the field offered. Click Apply to let the change take effect. Description The name of the Broadcast Domain to be added.
Page 124 Status Not-Apply or Apply will be displayed here Click the X in the Delete column next to an entry to remove it from the table. Click New to access the Add/Remove MAC-based Broadcast Domain Member --- Edit window: Stackable NWay Ethernet Switch User’s Guide Web-Based Network Management...
Page 125 Stackable NWay Ethernet Switch User’s Guide Figure 7-24. Add/Remove MAC-based Broadcast Domain Member ---Edit window To add or edit a MAC-based broadcast domain member, enter the MAC Address in the first field and use the drop-down Description menu to select the desired broadcast domain. Click Apply to let the changes take effect.
Page 126: Ieee 802.1Q Vlans
Stackable NWay Ethernet Switch User’s Guide IEEE 802.1Q VLANs Figure 7-25. Default Port VLAN ID window Use this window to assign a default VLAN ID for each desired port. Click Apply to let the settings take effect. Web-Based Network Management...
Page 127 Stackable NWay Ethernet Switch User’s Guide Figure 7-26. Port Ingress Filtering Check window Use this window to enable or disable the ingress filtering check for each desired port. Ingress filtering means that a receiving port will check to see if it is a member of the VLAN ID in the packet before forwarding the packet.
Page 128 Stackable NWay Ethernet Switch User’s Guide Figure 7-27. 802.1Q Static VLAN Entry window (number one) Click the X in the Delete column next to an entry to remove it from the table. Click the pointer icon to access the second 802.1Q VLAN Entry window:...
Page 129: Management
To configure an 802.1Q VLAN entry, enter a V-Id number and Description in the first two fields. Next, select the desired Switch. Finally, check Tag for each member port you wish to be a tagging port. None should be checked if you don’t want a port to belong to a VLAN. Otherwise, check Egress to statically set a port to belong to a VLAN.
Page 130: Community Strings And Trap Stations
The SNMP Trap Manager Configuration information is described as follows: Trap Receiving Station The IP address of the trap receiving station. Community String A user-defined SNMP community name. Status Option to set the trap receiving station to Enabled or Disabled. Stackable NWay Ethernet Switch User’s Guide Web-Based Network Management...
Page 131: User Account
Stackable NWay Ethernet Switch User’s Guide User Account Figure 7-30. User Accounts window Click the pointer icon on the right-hand side to access the User Account - Edit window: Web-Based Network Management...
Page 132 Stackable NWay Ethernet Switch User’s Guide Figure 7-31. User Account-Edit window To add or change a User Account, fill in the appropriate information in the User Name, Old Password, New Password, and Confirm New Password fields. Then select the desired access, Normal User or Administrator in the Access Level control and click Apply.
Page 133: Console
Console or SLIP, in the Serial Port field. Use SLIP for out-of-band management. If SLIP is being used, you may also set the Baud Rate in the last field. Click Apply and then reboot the Switch for console port settings to take effect.
Page 134: Monitoring
TX frames/sec Counts the total number of frames transmitted from a selected port per second since the Switch was last rebooted. RX frames/sec Counts all valid frames received on the port per second since the Switch was last rebooted. Figure 7-33. Switch Statistics window Stackable NWay Ethernet Switch User’s Guide...
Page 135: Port Utilization
Stackable NWay Ethernet Switch User’s Guide % of Utilization This shows the percentage of available bandwidth each port is using over the amount of time specified by the update interval. For example, when a 10 Mbps port is relaying packets at 5 Mbps, the utilization is 50%.
Page 136: Port Traffic Statistics
The port statistics shown by default are those for the port you last configured. Once in the individual window, you can click any port on the Switch graphic to show statistics for that port. The information is described as follows:...
Page 137: Port Error Packet Statistics
Stackable NWay Ethernet Switch User’s Guide Traffic in Frames: Frames Sent Counts the total number of frames transmitted from the port. Frames Received Counts all valid frames received on the port. Total Frames Received Counts the number of frames received on the port, whether they were valid or not.
Page 138 This may indicate noise on the line. Dropped Frames The number of frames which are dropped by this port since the last Switch reboot. Undersize Frames The number of frames detected that are less than the minimum permitted frame size of 64 bytes and have a good CRC.
Page 139: Port Packet Analysis Statistics
Stackable NWay Ethernet Switch User’s Guide Port Packet Analysis Statistics The information is described as follows: Update Interval Choose the desired setting: 5 seconds, 15 seconds, 30 seconds, 60 seconds or Suspend. The total number of packets (including bad packets) received that were 64 octets in length (excluding framing bits but including FCS octets).
Page 140: Browse Address Table
The total number of good packets that were received by and directed to a broadcast address. Note that this does not include multicast packets. Browse Address Table Figure 7-38. Browse Address Table window Stackable NWay Ethernet Switch User’s Guide Web-Based Network Management...
Page 141: Browse Igmp Status
Stackable NWay Ethernet Switch User’s Guide The Switch allows you to display a table containing Switch ports, MAC addresses, and respective learned statuses. If the table doesn’t display the information you want, fill in the requested information in the Find by MAC Address or Find by Port sections above and then click the button on the right side of the section used.
Page 142: Switch History
Figure 7-40. Switch History window This window allows you to view the Switch history. This works like a trap and event receiver except it only captures trap/events generated by the Switch itself. Click the Next button to view additional pages.
Page 143: Firmware And Configuration Update
Update Management Module Firmware: Firmware Update Determines whether or not the Switch should download its new firmware code the next time it is booted. File Name The path and the name of the file which holds the new firmware code on the TFTP server.
Page 144: Save Settings To Tftp Server
Change Configuration File: Use Config File Determines whether or not the Switch should download its configuration file the next time it is booted. Config File Name The path and configuration name on the TFTP server. Save Settings To TFTP Server To upload a configuration file, enter the Server IP Address where the configuration file is located and the File Name and file path.
Page 145: Save Switch History To Tftp Server
Save Switch History To TFTP Server Figure 7-43. Save Switch History To TFTP Server window To save a switch history file to your TFTP server, fill the fields in above and then click Apply. The information is described as follows: Server IP Address The IP address of the TFTP server where the log file will be saved.
Page 146: Save Changes
Stackable NWay Ethernet Switch User’s Guide Save Changes Figure 7-44. Save Changes window To save all the changes made in the current session to the Switch’s flash memory, click the Save Configuration button. Web-Based Network Management...
Page 147: Factory Reset
Figure 7-45. Factory Reset to Default Value window Doing a remote reset is equivalent to turning the Switch off and on again. All parameters are returned to the values stored in EEPROM. Click the Reset to Factory Default button to initiate the reset.
Page 148: Restart System
Stackable NWay Ethernet Switch User’s Guide Restart System Figure 7-46. Restart System window To perform a reboot of the Switch, which resets the system, click the Reset button. Web-Based Network Management...
Page 149: Technical Specifications
Stackable NWay Ethernet Switch User’s Guide Standards: Protocol: Data Transfer Rates: Ethernet Fast Ethernet Gigabit Ethernet Topology: Technical Specifications ECHNICAL General IEEE 802.3 10BASE-T Ethernet IEEE 802.3u 100BASE-TX Fast Ethernet IEEE 802.3z 1000BASE Ethernet IEEE 802.3z 1000BASE-SX/LX Gigabit Ethernet IEEE 802.3ab 1000BASE-T Gigabit Ethernet IEEE 802.1 P/Q VLAN...
Page 150: Physical And Environmental
441 mm x 367 mm x 44 mm (1U), 19 inch rack-mount width 5 kg FCC Class A, CE Class A, VCCI Class A, BSMI Class A, C-Tick Class A UL, CSA, TUV/GS Stackable NWay Ethernet Switch User’s Guide non-condensing; Technical Specifications...
Page 151 Stackable NWay Ethernet Switch User’s Guide Transmission Method: RAM Buffer: Filtering Address Table: Packet Filtering/Forwarding Rate: MAC Address Learning: Technical Specifications Performance Store-and-forward 12 Mbytes per device 12K MAC addresses per device (optimized condition) 148,800 pps per port (for 100Mbps)
Page 152: Pin Specification
RJ-45 P PECIFICATION When connecting the DES-3624 Switch to another switch, a bridge or a hub, a modified crossover cable is necessary. Please review these products for matching cable pin assignment. The following diagram and table show the standard RJ-45 receptacle/connector and their pin assignments for the switch-to-network adapter card connection, and the straight/crossover cable for the switch-to-switch/hub/bridge connection.
Page 153 The following shows straight cable and crossover cable connection: Figure B-2. Straight cable for Switch (uplink MDI-II port) to switch/Hub or other devices connection Figure B-3. Crossover cable for Switch (MDI-X port) to switch/hub or other network devices (MDI-X port) RJ-45 Pin Specification...
Page 154: Sample Configuration File
10.254.254.253 # – Remark. When placed as the first character on a line, the entire line will be ignored by the switch. This allows items to be labeled, or unused commands to remain in the file so that the syntax will not be forgotten.
Page 155 The Config image file, which contains all configuration settings and was created by the switch is prefixed with the version number of the runtime software to help with file management.
Page 156 Broadcast storm falling threshold Community string VLAN mode SNMP VLAN(802.1Q) Default port VID Ingress rule checking Mirror src port <->target port Mirror UNTIME OFTWARE Stackable NWay Ethernet Switch User’s Guide EFAULT ETTINGS Network Disable Disable 9600 Console 0.0.0.0 0.0.0.0 0.0.0.0 Enable 0.0.0.0...
Page 157 Stackable NWay Ethernet Switch User’s Guide 64, 95 65-127, 95 100BASE-TX networks, 12 100Mbps Fast Ethernet, 11 128-255, 95 256-511, 95 512-1023, 95 1024-1536, 95 AC inputs, 151 AC Power Connector, 18 AC power cord, 14 Access Rights read only, 88...
Page 158 IP Addresses and SNMP Community Names, 29 LED Indicators, 24 Local console management, 28 Logging In on the Console Screen, 41 Logging In on the Switch Console, 41 Lower Bridge Identifier, 32 MAC Address Learning, 152 Management, 13 Management feature...
Page 159 Stackable NWay Ethernet Switch User’s Guide Switch to 100BASE-TX hub, connecting the, 27 Switch to 10BASE-T hub, connecting the, 27 Switching Technology, 12 System Contact, 52 System Location, 52 System Name, 52 tagging, 35 Tagging, 37 TCP/IP Parameters Configuration, 49...
Page 160 D-LINK TAIWAN 2F, No. 119 Pao-Chung Road, Hsin-Tien, Taipei, Taiwan TEL: 886-2-2910-2626 FAX: 886-2-2910-1515 WEB: www.dlinktw.com.tw U.K. D-LINK EUROPE D-Link House, 6 Garland Road, Stanmore, London HA7 1DP U.K. TEL: 44-181-235-5555 FAX: 44-181-235-5500 WEB: www.dlink.co.uk E-MAIL: info@dlink.co.uk U.S.A. D-LINK U.S.A.
Page 161: Registration Card
3. What network protocol(s) does your organization use ? "XNS/IPX "TCP/IP "DECnet "Others_____________________________ 4. What network operating system(s) does your organization use ? "D-Link LANsmart "Novell NetWare "NetWare Lite "SCO Unix/Xenix "PC NFS "3Com 3+Open "Banyan Vines "DECnet Pathwork "Windows NT "Windows NTAS "Windows '95 "Others__________________________________________ 5.

D-Link DES-3624 Series User Manual

Introduction

Unpacking and Setup

Identifying External Components

Connecting the Switch

Switch Management Concepts

Using the Console Interface

Web-Based Network Management

Technical Specifications

Pin Specification

Sample Configuration File

Quick Links

Related Manuals for D-Link DES-3624 Series

Summary of Contents for D-Link DES-3624 Series

Table of Contents
