Signal
1
TPTX100P
2
TPTX100N
3
TPRX100P
4
N/C
5
N/C
6
TPRX100N
7
N/C
8
N/C
9
NC
10
NC
11
GND
12
GND
13
LED1+
14
nLINK
15
LED2+
16
nSPEED100
¡ ¹
CN
3 : USB Client port
Figure 3.10 I/O Board RJ-45 for Ethernet port
