Signal
Pin
1
DCD
2
RXD
3
TXD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
RI
Figure 3.8 I/O Board COM1(RS-232) serial port
¡ ¹
CN
4 : RS-485 serial port
