CN 18 : TTL level LCD signal conn
Pin Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
note : User can use JP3 to change the LCD signals level.
ector
Pin function
VCC
VCC
GND
GND
VCC3P3
VCC3P3
LCD_VEE
GND
LCD_D0
LCD_D1
LCD_D2
LCD_D3
LCD_D4
LCD_D5
LCD_D6
LCD_D7
LCD_D8
LCD_D9
LCD_D10
LCD_D11
LCD_D12
LCD_D13
LCD_D14
LCD_D15
LCD_D16
LCD_D17
LCD_D18
LCD_D19
LCD_D20
LCD_D21
LCD_D22
LCD_D23
GND
GND
SHCLK
FLM_VSYNC
M_DE
LP_HSYNC
N.C.
ENVEE
38
Ps.
+5V
+5V
+3.3V
+3.3V
no function
