- Page 1 User Manual SPC-200 Series (SPC-221/218) Encapsulated Multi-Touch Panel Computer with Intel Skylake Processor 申請商 : 研華股份有限公司 地址 : 台北市內湖區瑞光路 26 巷 20 弄 1 號 電話 :02-27927818...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 4 This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information.
- Page 5 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
- Page 6 SPC-200 Series User Manual...
-
Page 7: Table Of Contents
USB pin definition with M12 connector ........... 22 Power Input pin definition with M12 connector........23 Appendix B UI Operating Process ......25 UI Operating Process................26 Table B.1: Status indicator table ..........26 Table B.2: Button code definition ..........31 SPC-200 Series User Manual... - Page 8 SPC-200 Series User Manual viii...
-
Page 9: Chapter 1 General Information
Chapter General Information... -
Page 10: Introduction
Introduction With a brand-new ID design, the SPC-200 series provide high resolution 18.5"/21.5" display and PCT multi-touch in 16:9 wide format. By embedding an Intel 6th Gen Intel® Core™ U-series processor with independent GPU, the SPC-200 series can support advanced graphical performance in more complex applications. -
Page 11: Specifications
16.7 M 16.7 M Maximum Colors 170°/160° 178°/178° Viewing Angle Luminance (cd / m2) Backlight Note! There might be several bright or dark pixels on the LCD. This phenome- non is normal in today’s LCD manufacturing. SPC-200 Series User Manual... -
Page 12: Touchscreen Specifications
This product is intended to be supplied by a Listed Power Adapter or DC power source, rated 24Vdc, 2.5A minimum and Tma 55 degree C minimum, if need further assistance, please contact Advantech for further information. I/O Ports Arrangement The arrangement of the I/O ports is shown in Figure 1.1. -
Page 13: Vesa Mounting
The SPC-200 have been designed with support for the VESA mount standard. Refer to figure 1.2. Supports 100mm VESA dimension. Use M4 screws (Length 8mm to 10 mm). Warning! Use suitable mounting apparatus to avoid risk of injury. Figure 1.2 VESA Mounting SPC-200 Series User Manual... -
Page 14: Dimensions And Cutout
Dimensions and Cutout SPC-218 Weight: 8kg Dimensions (W x H x D): – 488 x 309 x 65mm (19.2" x 21.2" x 2.6") 309 [12.17] 100.00 [3.94] Figure 1.3 SPC-218 Dimensions SPC-200 Series User Manual... -
Page 15: Figure 1.4 Spc-221 Dimensions
SPC-221 Weight: 8.5kg Dimensions (W x H x D): – 558.4 x 349.8 x 65 mm (21.98” x 13.77” x 2.56”) 349.8[13.77] 100.00 [3.94] Figure 1.4 SPC-221 Dimensions SPC-200 Series User Manual... - Page 16 SPC-200 Series User Manual...
-
Page 17: Chapter 2 System Setup
Chapter System Setup... -
Page 18: System Setup
Open side cover and then install 2.5" HDD in the HDD tray which contains Win- dows Embedded Standard 7, Windows Embedded Standard 2009 or another operating system. Then fix the side cover with screws, after that stopper the screw hole with waterproof rubber. Figure 2.2 2.5" Hard Disk Drive SPC-200 Series User Manual... -
Page 19: Figure 2.3 Pin Definition Of Power Connector
DC 24V+ M12-A-5P-M DC24V+ Power F_GND Figure 2.3 Pin Definition of Power Connector Figure 2.4 Power Receptor with M12 Connector Plug the power lines into the system power receptor with M12 connector. Power on the system. SPC-200 Series User Manual... -
Page 20: Installing The Drivers
SPC-218/221 will use built-in PCT touch driver of OS If operating under Windows 7 and Windows 10. 2.2.2 Installation of Watchdog driver Enter into Watchdog folder, double click AdvWDT icon, and then click "Next" under InstallShield Wizard window. Select "Advantech [SCH311X] WDT” and click “Next”. Click “Install”. SPC-200 Series User Manual... - Page 21 Click “Finish” to finish the installation. Select “Yes, I want to restart my computer now” and click “OK”. After installing Watchdog driver, a "Watchdog Service Configuration" icon will show in control panel. SPC-200 Series User Manual...
-
Page 22: Installation Of Graphic Driver
Watchdog timer function. 2.2.3 Installation of graphic driver Enter into TS folder, enter into” graphic driver for Windows 7" Driver folder and double click setup icon, and then click “Next” under setup wizard window. Click “Install”. SPC-200 Series User Manual... - Page 23 Select “Express” and click “Next”. Click “Accept”. Click “Finish” to finish the installation. SPC-200 Series User Manual...
-
Page 24: Installation Of Lan Driver
Installation of LAN driver Enter into TS folder, enter into “Ethernet driver for Windows 7" Driver folder and double click setup icon, and then click “Next” under setup wizard window. Click ”Install”. Click “Finish” to finish the installation. SPC-200 Series User Manual... -
Page 25: Wake Up From Suspend Mode
Select "SB USB Configuration” and press “Enter” key. Select “USB Device Wake up from S3” and change to “Disable” , than save your change and exit. After reboot, The USB wake up function will be disabled. SPC-200 Series User Manual... - Page 26 SPC-200 Series User Manual...
-
Page 27: Features In Windows Embedded
Chapter Features in Windows Embedded... -
Page 28: Features In Windows Embedded
Advantech provides a pair of utilities to operate EWF, OSLock andOSUnLock. Refer the training slide in the folder, file name is “Advantech XPe Add-one.pdf”. -
Page 29: Appendix A M12 Connector I/O Pin Definition
Appendix M12 connector I/O pin definition... -
Page 30: Lan1 / Lan2 Pin Definition With M12 Connectors
Signal (Female) TX_D1+ TX_D1- RX_D2+ BI_D3+ M12-A-8P-F BI_D3- RX_D2- BI_D4+ BI_D4- RS-232 pin definition with M12 connector RS-232 Pin Number Signal (Male) M12-A-8P-M RS-232 USB pin definition with M12 connector Pin Number Signal (Female) M12-A-8P-F Shielding SPC-200 Series User Manual... -
Page 31: Power Input Pin Definition With M12 Connector
Power Input pin definition with M12 connector Pin Number Signal (Male) DC 24V- DC 24V- DC 24V+ M12-A-5P-M DC 24V+ Power F_GND SPC-200 Series User Manual... - Page 32 SPC-200 Series User Manual...
-
Page 33: Appendix Bui Operating Process
Appendix UI Operating Process... -
Page 34: Ui Operating Process
UI Operating Process This section is to introduce how to operate HMI utility(GL_Utility), you can download the utility from Advantech's product support portal of SPC-218/221 at http://support.advantech.com. See the process below: As you can find 2 function buttons in the lower right corner of front panel, represents “intelligent”... - Page 35 Long press Home Key-> Home - Long press to disable / enable touch function Note! When touch function is disabled, you'll see a message up in the lower right corner of screen SPC-200 Series User Manual...
- Page 36 One press Intelligent Key-> Intelligent - Advantech Intelligent Utility A. Quick start-> – Press “+” to add shortcut. – Long press the icon to perform “right click” until an “X” mark appears in upper right corner to “delete”. SPC-200 Series User Manual...
- Page 37 Password confirmation for authority confirmation when first log in, default password is “1234” without input order to active. – Setting - Home-key: Select an execute file to set up as "Home-key" App, in default path is to show “desktop”. SPC-200 Series User Manual...
- Page 38 Setting - Brightness: Brightness control from 1 to 8. Note! If you use other brightness setting tools such as iManager, remember not to adjust below 10 percent to prevent a black screen. – Setting - Password: Change password function. SPC-200 Series User Manual...
-
Page 39: Table B.2: Button Code Definition
SPC-218/221 also provides open button code as following definition for customer's configuration to their Apps/SW applications. The codes are defined from general keyboard input. Table B.2: Button code definition One press Long press I key(icon) Ctrl+Shift+Alt+I Ctrl+Shift+Alt+U H Key(icon) Ctrl+Shift+Alt+H Ctrl+Shift+Alt+L SPC-200 Series User Manual... - Page 40 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2019...
