3.1.1 Specification
Model
Model
CPU
System
memory
Memory
Kernel Module
part WDT
RTC
Power Input
OS
I/O ports
Serial Ports
Ethernet
USB host port 2 X USB 1.1 host ports
USB Client
Port
PCMCIA
CF
DI & DO
GPIO
Display
LCD
CRT
System JTAG
Part
Inverter
touch-screen
PCM-7230 SBC for SPC-57
®
Intel PXA255 processor at 200 MHz
1MB NOR flash for bootloader and 64MB SDRAM
N/A
PXA-255 Internal (2, 5, 10 Sec as default)
HT-1381 with rechargeable coin battery
DC 10V~28V, with power protect (protect for over voltage,
over current & short).
®
Microsoft Windows
Three full-function RS-232 ports and one RS-485 w/ AFC
-COM1 full-function transceiver level RS-232
-COM2 full-function transceiver level RS-232
-COM3 full-function transceiver level RS-232
-COM4 RS-485 w/ AFC
10/100 BASE-T Ethernet Port
USB Client Port for ActiveSync function
One type-II hot-swappable PCMCIA slot
One type-II hot-swappable CF slot
8 digital input pins & 8 digital output pins. All are TTL level.
8 GPIO pin headers out put. Default as hotkeys.
5.7" TFT LCD. Resolution VGA 320 x 240
SVGA at default to align with LCD setting, Pin header output
7x1 pin header for upgrade the bootloader in AMD flash.
4-pin inverter interface for 5V inverter
4-wire resistive T/S interface. 2x2 2.00mm pin header.
PCM-7230 SBC for SPC-57
®
CE.NET 4.2
