- Page 1 User Manual SPC-xx81 Stationary Multi-Touch Panel Computer with Intel Core i Processor...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
-
Page 4: Declaration Of Conformity
This product has passed the CE test for environmental specifications when shielded cables are used for external wiring. We recommend the use of shielded cables. This kind of cable is available from Advantech. Please contact your local supplier for ordering information. -
Page 5: Safety Instructions
The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein. - Page 6 SPC-xx81 User Manual...
-
Page 7: Table Of Contents
LCD Specifications..................4 Touchscreen Specifications ..............4 Power ......................4 I/O Ports Arrangement ................5 Figure 1.1 SPC-1881 Rear View- I/O Port Arrangement ..... 5 VESA Mounting..................5 Figure 1.2 VESA Mounting ............5 Dimensions and Cutout................6 Figure 1.3 SPC-1881WP Dimensions ......... 6... - Page 8 UI Operating Process................34 Table B.1: Status indicator table..........34 Table B.2: Button code definition..........40 SPC-xx81 User Manual viii...
-
Page 9: Chapter 1 General Information
Chapter General Information... -
Page 10: Introduction
Introduction Winner of the 2013 iF product design award, the SPC-1881 series have high resolu- tion 18.5" 16:9 widescreen PCT multi-touch displays. By embedding an Intel Core i3-4010U 1.70 GHz processor with an independent GPU, the SPC-1881 supports advanced graphical performance in more complex applications. Built-in function and home key buttons are used for intuitive UI and operating safety. -
Page 11: Specifications
Specifications 1.3.1 General Certification: BSMI, CCC, CE, FCC Class A, UL Cooling System: Fanless design Dimensions (W x H x D): 488 x 309 x 65mm Enclosure: Front bezel: Die-cast Aluminium alloy Back housing: Die-cast Aluminium alloy ... -
Page 12: Lcd Specifications
LCD Specifications Display Type WXGA LED LCD Size (diagonal) 18.5" Maximum Resolution 1366 x 768 Maximum Colors 16.7 M Viewing Angle 170°/160° Luminance (cd / m2) Backlight Note! There might be several bright or dark pixels on the LCD. This phenome- non is normal in today’s LCD manufacturing. -
Page 13: I/O Ports Arrangement
The arrangement of the I/O ports is shown in Figure 1.1 Figure 1.1 SPC-1881 Rear View- I/O Port Arrangement VESA Mounting The SPC-1881 have been designed with support for the VESA mount standard. Refer to figure 1.2. Supports 100mm VESA dimension. Use M4 screws (Length 8mm to 10 mm). -
Page 14: Dimensions And Cutout
Dimensions and Cutout SPC-1881WP Weight: 8kg Dimensions (W x H x D): – 488 x 309 x 65mm (19.21" x 12.17" x 2.56") 309 [12.17] 100.00 [3.94] Figure 1.3 SPC-1881WP Dimensions SPC-xx81 User Manual... -
Page 15: Chapter 2 System Setup
Chapter System Setup... -
Page 16: System Setup
System Setup You can easily get SPC started by following the below steps. Unpack the SPC package. Check the packing list at the beginning of this man- ual to make sure all items have been included. Figure 2.1 Unpack the Package Open side cover and then install 2.5"... -
Page 17: Figure 2.3 Pin Definition Of Power Connector
Connect the power connector with M12 connector to the 24 V power lines. The power lines can either be of some power adapter or in-house power source. Power Input Pin Number Signal (Male) DC 24V- DC 24V- DC 24V+ M12-A-5P-M DC24V+ Power F_GND... -
Page 18: Installing The Drivers
Installing the Drivers 2.2.1 Installation of Touch Screen driver SPC-1881 will use built-in PCT touch driver of OS If operating under Windows. Note! If you are using Windows 7 or above, the OS has a built-in driver for multi-touch so that you don't need to install the Touch Screen Driver. -
Page 19: Installation Of Graphic Driver
2.2.2 Installation of graphic driver There is a VGA driver on the DVD, enter X:\TPC_SPC-xx81WP series then choose your OS type. Select the VGA folder and double-click the setup icon. Click “Install” Select “Express” and click “Next” SPC-xx81 User Manual... - Page 20 Click “Next” Click “Finish” to finish the installation SPC-xx81 User Manual...
-
Page 21: Installation Of Lan Driver
2.2.3 Installation of LAN driver Enter X:\TPC_SPC-xx81WP series then choose your OS type. Select LAN folder and double click the setup icon, and then click “Next” under setup wizard window. License Agreement, click “Next” Click ”Install” SPC-xx81 User Manual... -
Page 22: Installation Of Ec Driver
Click “Finish” to finish the installation 2.2.4 Installation of EC Driver Select “Advantech IAG tool” folder then enter EC folder. Double click “V1.05.001”. Click “Yes” and “Next” then select “Install this driver software anyway”. Select finish then restart your computer. -
Page 23: Installation Of Ec Brightness Driver
2.2.5 Installation of EC Brightness Driver Select “Advantech IAG tool” folder then enter “EC Brightness” folder. Double click “V2.02.002”. Click “Yes” and “Next” then select “Install this driver software anyway”. Select finish then restart your computer. 2.2.6 Installation of Lmsensor Select “Advantech IAG tool”... -
Page 24: Installation Of Watchdog Driver
2.2.7 Installation of Watchdog driver Enter into Watchdog folder, double click AdvWDT icon, and then click “Next” under InstallShield Wizard window.. At the welcome screen select click “Next” Select "Advantech<EC> WDT SPC-xx81 User Manual... - Page 25 Click “Install” Click “Finish” to finish the installation. Select “Restart” SPC-xx81 User Manual...
- Page 26 After installing Watchdog driver, a "Watchdog Service Configuration" icon will show in control panel. Double click the "Watchdog Service Configuration" icon, and you can configure the Watchdog timer function. SPC-xx81 User Manual...
-
Page 27: Wake Up From Suspend Mode
Wake up from Suspend Mode Brief Solution - Step by Step: Enable “allow this device to wake the computer” in device manager -> Human interface device -> HID compliant consumer and control, HID compliant device-> power management. Double click and select power management page, then enable "Allow this device to wake the computer”. - Page 28 SPC-xx81 User Manual...
-
Page 29: Chapter 3 Features In Windows Embedded
Chapter Features in Windows Embedded... -
Page 30: Features In Windows Embedded Platform
Applying changes to an image applies all changes made to the operat- ing system during a specific period of time. Advantech provide utility to operate EWF. Refer below steps if you want to enable. Click Start Menu->All Programs->Advantech->AdvWF and click EWF Utility... -
Page 31: File-Based Write Filter (Fbwf)
Writes to folders with write- through exceptions will be persisted when the device restarts. Advantech provide utility to operate FBWF. Refer to the below steps if you want to enable it. - Page 32 Move volume you want to protect from “Available Volume” to “Protected Vol- ume” and choose “Write-Through Files and Folders” Click “Apply”, and the system is rebooted automatically. Then FBWF is enabled. SPC-xx81 User Manual...
-
Page 33: Horm
To set a HORM environment, follow the steps below. Make sure EWF is disabled. You can run OSUnLock to disable EWF. a. Click Start Menu->All Programs->Advantech->AdvWF b. Click EWF Utility and go to General page to check EWF is disabled. SPC-xx81 User Manual... - Page 34 Enable Hibernate a. Open command prompt as Administrator and type "powercfg -h on" b. Check the hibernate state in general page. Enable HORM a. Open AdvWF, click EWF Utility and go to EWF tab SPC-xx81 User Manual...
- Page 35 Click "Enable" in EWF tab Click OK and it will reboot automatically to make EWF become effective. After system is rebooted, open AdvWF and click EWF Utility Go to HORM page, and click "HORM" button SPC-xx81 User Manual...
-
Page 36: Uwf
Click OK and it will shutdown automatically Unified Write Filter (UWF) is a sector-based write filter that you can use to protect your storage media. UWF intercepts all write attempts to a protected volume and redirects those write attempts to a virtual overlay. This improves the reliability and stability of your device and reduces the wear on write-sensitive media, such as flash memory media like solid-state drives. -
Page 37: Appendix A M12 Connector I/O Pin Definition
Appendix M12 connector I/O pin definition... -
Page 38: Lan1 / Lan2 Pin Definition With M12 Connectors
LAN1 / LAN2 pin definition with M12 connectors Pin Number Signal (Female) TX_D1+ TX_D1- RX_D2+ BI_D3+ M12-A-8P-F BI_D3- RX_D2- BI_D4+ BI_D4- RS-232 pin definition with M12 connector RS-232 Pin Number Signal (Male) M12-A-8P-M RS-232 USB pin definition with M12 connector Pin Number Signal (Female) -
Page 39: Power Input Pin Definition With M12 Connector
Power Input pin definition with M12 connector Pin Number Signal (Male) DC 24V- DC 24V- DC 24V+ M12-A-5P-M DC24V+ Power F_GND SPC-xx81 User Manual... - Page 40 SPCxx81 User Manual...
-
Page 41: Appendix Bui Operating Process
Appendix UI Operating Process... -
Page 42: Ui Operating Process
UI Operating Process This section is to introduce how to operate HMI utility(GL_Utility), you can download the utility from Advantech's product support portal of SPC-1881 at http://support.advantech.com. See the process below: As you can find 2 function buttons in the lower right corner of front panel, represents “intelligent”... - Page 43 One press Home Key-> Home – Back to desktop (default setting) Home - Execute Home-key App (Set up in setting page) Long press Home Key-> Home - Long press to disable / enable touch function Note! When touch function is disabled, you'll see a message up in the lower right corner of screen SPC-xx81 User Manual...
- Page 44 SPC-xx81 User Manual...
- Page 45 One press Intelligent Key-> Intelligent - Advantech Intelligent Utility A. Quick start-> – Press “+” to add shortcut – Long press the icon to perform “right click” until an “X” mark appears in upper right corner to “delete” SPC-xx81 User Manual...
- Page 46 B. Setting -> Password confirmation for authority confirmation when first log in, default password is “1234” without input order to active. – Setting - Home-key: Select an execute file to set up as "Home-key" App, in default path is to show “desktop” SPC-xx81 User Manual...
- Page 47 – Setting - Brightness: Brightness control from 10 to 100 percent Note! If you use other brightness setting tools such as iManager, remember not to adjust below 10 percent to prevent a black screen. – Setting - Password: Change password function SPC-xx81 User Manual...
-
Page 48: Table B.2: Button Code Definition
– System information: – Self Diagnosis: Note!* SPC-1881 also provides open button code as following definition for customer's configuration to their Apps/SW applications. The codes are defined from general keyboard input. Table B.2: Button code definition One press Long press... - Page 49 SPC-xx81 User Manual...
- Page 50 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2016...
