- Page 1 User Manual TPC-2000 Series TPC-B200-J12AE TPC-B200-E12AE TPC-2121T TPC-2151T TPC-2181W Industrial Modular Touch Panel Computer with Intel® Atom™/ Celeron® Processor...
- Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
- Page 3 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
- Page 4 警告使用者：這是甲類資訊產品，在居住的環境中使用時，可能會造成射頻干擾，在 這種情況下，使用者會被要求採取某些適當對策。 Technical Support and Assistance Visit the Advantech web site at www.advantech.com/support where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...
- Page 5 The sound pressure level at the operator's position according to IEC 704-1:1982 is no more than 70 dB (A). DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech disclaims all responsibility for the accuracy of any statements contained herein.
- Page 6 TPC-2000 Series User Manual...
-
Page 7: Table Of Contents
3.1.2 Advanced BIOS Features Setup..........23 3.1.3 Chipset Configuration ..............32 3.1.4 Security ..................33 3.1.5 Boot..................... 34 3.1.6 Save & Exit ................. 35 3.1.7 Wake up on LAN................. 36 Appendix A Serial Port Settings ......37 TPC-2000 Series User Manual... - Page 8 LAN Driver Installation ................51 Intel® Trusted Execution Engine Driver Installation........ 53 Advantech EC Driver Installation ............56 Advantech EC Brightness Control Tool Installation ........ 58 Advantech EC Watchdog Timer Driver Installation......... 60 Advantech LMsensor Driver Installation ..........63 TPC-2000 Series User Manual...
-
Page 9: Chapter 1 General Information
Chapter General Information... -
Page 10: Introduction
– USB 2.0 x 2 – Audio line out x 1 – Display port 1.4 out x 1 – 10/100/1000 Base-T LAN x 2 (2 x Intel® I210) 1.2.2 O/S support Windows 10 IoT Enterprise LTSB TPC-2000 Series User Manual... -
Page 11: Certification And Environment
0 ~ 50°C (32 ~ 122°F) (J3455) Tempera- Operating ture -20 ~ 60°C (-4~140°F) (E3940) Storage -30 ~ 70°C (-22 ~ 158°F) -20~60°C (-4~140°F) Power Input Voltage: 24V +/- 20% Typical: – 24 V @ 2.5 Amp TPC-2000 Series User Manual... -
Page 12: I/O Port Arrangement
Insert the screws into each clamp and tighten them to fasten the clamp in place. Hook the clamps into the holes and fasten the screws Torque: 2 kgf-cm These screws will push the mounting panel and secure the unit. Figure 1.2 Panel mounting TPC-2000 Series User Manual... -
Page 13: Dimensions And Cutout
383.2 307.3 57.5 374.5 298.5 15.6" (FHD) 419.7 60.3 412.4 261.7 17'' (SXGA) 410.4 343.4 58.3 401.3 334.8 18.5" (HD) 60.3 479.3 300.3 21.5'' (FHD) 558.4 349.8 60.3 550.3 341.8 23.8'' (FHD) 595.9 374.1 60.3 365.3 TPC-2000 Series User Manual... - Page 14 TPC-2000 Series User Manual...
-
Page 15: Chapter 2 System Setup
Chapter System Setup... -
Page 16: Transport And Unpacking
12 hours must be allowed to make sure the TPC is completely dry before the TPC is switched on. System Setup Note! If you purchase the Computing Box (TPC-B200) & Panel (FPM-Display) separately, please simply use the five screws of 1930001361 to connect the Computer Box and Panel. TPC-2000 Series User Manual... - Page 17 Unscrew the cover of the box module and remove the HDD bracket. Figure 2.1 Install SSD - 1 Figure 2.2 Install SSD - 2 Fasten SSD onto the disk tray with the SSD screws. Figure 2.3 Install SSD – 2 TPC-2000 Series User Manual...
- Page 18 Figure 2.4 Power connector and pin assignment Plug the power wire into the system power receptor. Figure 2.5 Power receptor & button pin assignment Attach power to the system. Calibrate the touchscreen. (only applicable to 12.1”) TPC-2000 Series User Manual...
-
Page 19: Driver Installation
With administrator-level privileges, run the installer for the Advantech watchdog driver. Below is an example of the Advantech watchdog driver setup. To stop the setup pro- cess at any time, click the “Cancel” button on the pop-up screen. The setup program will stop the procedure automatically. - Page 20 Wait until the Advantech Watchdog Driver Setup Wizard has completed the installation. Click the Install button to continue the installation of the Advantech watchdog driver software. TPC-2000 Series User Manual...
-
Page 21: Panel Mounting
Click the Restart or Close button on the Advantech Watchdog Driver Setup Wizard pop-up screen to complete the setup. Panel Mounting Position the TPC against the panel. TPC-2000 Series User Manual... - Page 22 Insert the clamps into the side of the TPC. Secure the clamp to the panel using the included screws. TPC-2000 Series User Manual...
-
Page 23: Cabinet Installation And Earth Grounding Setup
TPC system’s ground, cabinet’s ground and earth ground should be connected together. Install the TPC system into the cabinet. Step A: Connect the cabinet to earth ground. Step B: Embed null TPC system into the cabinet without any I/O cable and power. System wiring. TPC-2000 Series User Manual... -
Page 24: Power/Digital Ground And Earth Ground
The Ethernet is isolated, a LAN connection will not impact the isolation design. For general USB devices, to solve EMI and ESD issues, they are designed as a chassis and digital short. But the TPC prevents damage to USB devices, ESD TPC-2000 Series User Manual... -
Page 25: Installation Of Extension
Figure 2.6 Install M.2 SSD -1 Remove the rear cover. Insert the M.2 (2242) SSD and tighten the screws in the screw holes. 2.7.2 Installation of iDoor Remove the box cover. Figure 2.7 Install iDoor -1 TPC-2000 Series User Manual... - Page 26 Remove the blank slot cover for iDoor. Figure 2.8 Install iDoor -2 Insert iDoor module. Figure 2.9 Install iDoor -3 TPC-2000 Series User Manual...
- Page 27 Tighten two screws to affix the module in place. Figure 2.10 Install iDoor -4 Install iDoor mPICe module and plug in the power cable of iDoor mPCIe mod- ule. Figure 2.11 Install iDoor -6 TPC-2000 Series User Manual...
- Page 28 TPC-2000 Series User Manual...
-
Page 29: Chapter 3 Bios Setup
Chapter BIOS Setup... -
Page 30: Entering Setup
This chapter illustrates the basic navigation of the BIOS Setup Utility on TPC-2000 series. TPC-2000 series BIOS ROM has a built-in setup program that allows users to modify the basic system configuration. This information is stored in flash ROM so it retains setup information when the power is turned off. -
Page 31: Advanced Bios Features Setup
3.1.2 Advanced BIOS Features Setup Select the Advanced tab from the TPC-2000 series setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as ACPI Settings and hit <enter> to go to the sub menu for that item. - Page 32 This item allows users to enable or disable System ability to hibernate (OS/S4 sleep State). This option may be not effective with some OS. ACPI Sleep State This item allows users to select the ACPI sleep state. The system will enter when the SUSPEND button is pressed. TPC-2000 Series User Manual...
- Page 33 3.1.2.2 Super I/O Configuration Serial Port 1 Configuration Set Parameters of Serial Port 1 (COMA) Serial Port 2 Configuration Set Parameters of Serial Port 2 (COMB) 3.1.2.3 Embedded Controller Configuration TPC-2000 Series User Manual...
- Page 34 This item allows users to set the IRQ number of EC watchdog. 3.1.2.4 S5 RTC Wake Settings Wake system with Fixed Time Enable or disable System wake on alarm event. Select FixedTime, system will wake on the hr:min:sec specified. TPC-2000 Series User Manual...
- Page 35 3.1.2.5 CPU Configuration Intel Virtualization Technology This item allows users to enable or disable Intel Virtualization Technology. When enabled, a VMM can utilize additional hardware capabilities provided by Vander- pool Technology. TPC-2000 Series User Manual...
- Page 36 Enable / Disable Serial ATA Port0 / Port1. SATA Port 0 / Port1 HotPlug Enable / Disable SATA Port0 / Port1 hotplug function. Note! Before installing WinCE image, IDE configuration must set SATA Mode to IDE Mode in BIOS to boot successfully. TPC-2000 Series User Manual...
- Page 37 OS Selection to choose =Windows 7 / Windows 10 3.1.2.8 LAN Controller LAN A Controller Enable or disable onboard NIC. LAN B Controller Enable or disable onboard NIC. Wake on LAN Enable Enable/Disable integrated LAN to wake the system. TPC-2000 Series User Manual...
- Page 38 Controls the execution of UEFI and Legacy Storage OpROM. Video Controls the execution of UEFI and Legacy Video OpROM Other PCI devices Determines OpROM execution policy for devices other than Network, Storage, or Video. TPC-2000 Series User Manual...
- Page 39 3.1.2.10 USB Configuration 3.1.2.11 COM Configuration TPC-2000 Series User Manual...
-
Page 40: Chipset Configuration
3.1.3 Chipset Configuration TPC-2000 Series User Manual... -
Page 41: Security
Setup options, such as password protection and virus protection are described in this section. To access the sub menu for the following items, select the item and press <Enter>: Setup Administrator Password Set Administrator Password. User Password Set User Password. TPC-2000 Series User Manual... -
Page 42: Boot
Boot Option #2 Sets the system boot order Fast Boot Enables or disables boot with initialization of a minimal set of devices required to launch active boot option. Has no effect for BBS boot options. TPC-2000 Series User Manual... -
Page 43: Save & Exit
This item allows you to restore the user defaults to all the options. Boot Override Boot device select can override your boot priority. Launch EFI Shell from files system device Attempts to Launch EFI Shell application (Shell.efi) from one of the available file system devices. TPC-2000 Series User Manual... -
Page 44: Wake Up On Lan
Connect the RJ-45 cables and ping each other to ensure the connection is suc- cessful. Step 6 Check Connection Connect the RJ-45 cables and ping each other to ensure the connection is suc- cessful. TPC-2000 Series User Manual... -
Page 45: Appendix A Serial Port Settings
Appendix Serial Port Settings... -
Page 46: Jumper, Dip Switch And Connector Location
M.2 B-Key slot Display Port CN10 Audio Out 3.5mm Jack CN12 Mini PCIE slot CN13 COM1 RS232/422/485 connector CN14 COM2 RS232/422/485 connector CN18 Power in connector CN19 RTC battery connect CN20 SIM card slot CN22 Power button/Reset TPC-2000 Series User Manual... -
Page 47: Jumper Setting And Description
3.3V power output 3.3V 3.3V power output system ground system ground system ground 5V power output 5V power output 5V power output system ground floating system ground 12V power output 12V power output 12V power output TPC-2000 Series User Manual... -
Page 48: Mini Pcie Slot (Cn12)
PCIE data receive 3.3V_AUX PCIE_RX- input negative mini PCIE device PCIE_RESET# system ground reset input WIFI_DIS- mini PCIE wifi mod- floating ABLE# ule disable input system ground floating SIM card program- SIM_VPP system ground ing power input TPC-2000 Series User Manual... -
Page 49: Power-In Connector (Cn18)
3.3V PCIE_WAKE# input ger output A.3.3 Power-in connector (CN18) Table A.4: Power-in connector (CN18) Signal Description 24V POWER+ 24V power positive input 24V POWER- 24V power negative input Chassis GND connect to earth ground TPC-2000 Series User Manual... -
Page 50: Lan Rj45 Connector (Cn3)
USB3_TX- USB3.0 data transmit negative USB3_TX+ USB3.0 data transmit positive VBUS 5V power output USB2_D- USB2.0 data negative USB2_D+ USB2.0 data positive system ground USB3_RX- USB3.0 data receive negative USB3_RX+ USB3.0 data receive positive system ground TPC-2000 Series User Manual... -
Page 51: Usb 2.0 Connector (Cn6)
Table A.7: USB 2.0 connector (CN6) Signal Description VBUS 5V power output USB2_D- USB2.0 data negative USB2_D+ USB2.0 data positive system ground VBUS 5V power output USB2_D- USB2.0 data negative USB2_D+ USB2.0 data positive system ground TPC-2000 Series User Manual... -
Page 52: Com1 Rs232/422/485 Connector (Cn13)
DTR# ready positive system ground system ground system ground DSR# data set ready RTS# request to send CTS# clear to send ring indicator Legend: “-” = “no data” TPC-2000 Series User Manual... -
Page 53: Appendix B Driver Installation And Config
Appendix Driver Installation and Config... -
Page 54: Intel Chipset Software Installation Utility Installation
Intel Chipset Software Installation Utility Installation Follow the steps below to install the Intel Chipset Software Installation Utility: Launch <Driver Root Path>\Intel Chipset Software Installation Utility\Setup- Chipset_XX.X.XX_PV. Install SetupChipset.exe. Click Next. TPC-2000 Series User Manual... - Page 55 Click Accept. Click Install. TPC-2000 Series User Manual...
-
Page 56: Intel Graphics Driver Installation
Click Finish Intel Graphics Driver Installation Follow the steps below to install the Intel Graphics driver: Launch folder <Driver Root Path>\Graphics Driver\Intel EMGD win7 XX bit\ Install Setp.exe TPC-2000 Series User Manual... - Page 57 Click Next. Click Yes. TPC-2000 Series User Manual...
- Page 58 Click Next. Click Install. Click Next TPC-2000 Series User Manual...
-
Page 59: Lan Driver Installation
Choose Yes, then click Finish to restart LAN Driver Installation Follow the steps below to install the LAN driver: Launch folder <Driver Root Path>\LAN\Win7 \Install_Win7_7077_XXX- _XXXXXXXX Install setup.exe TPC-2000 Series User Manual... - Page 60 Click Next. Click Install. TPC-2000 Series User Manual...
-
Page 61: Intel® Trusted Execution Engine Driver Installation
Click Finish. Intel® Trusted Execution Engine Driver Installation Follow the steps below to install the Intel Trusted Execution Engine driver: Launch folder <Driver Root Path>\TXE\Intel TXE Firmware\Win7 Install kmdf-1.11-Win-6.1-x86.msu TPC-2000 Series User Manual... - Page 62 Click Yes. Click Next. Click Next. TPC-2000 Series User Manual...
- Page 63 Click Next Choose Yes, then click Finish to restart. TPC-2000 Series User Manual...
-
Page 64: Advantech Ec Driver Installation
Advantech EC Driver Installation Follow the steps below to install the EC drivers: Launch folder <Driver Root Path>\EC\Vx.xx.xxxx Install AdvEC_Vx.xx.xxxx.exe Click Next. TPC-2000 Series User Manual... - Page 65 Click Install. Click Finish. Choose Yes, then click OK to restart. TPC-2000 Series User Manual...
-
Page 66: Advantech Ec Brightness Control Tool Installation
Advantech EC Brightness Control Tool Installation Note! The Advantech EC driver must be installed first. Follow the steps below to install the EC brightness control tool: Launch folder <Driver Root Path>\EC Brightness\Vx.xx.xxxx Install AdvECBrightness_Vx.xx.xxxx.exe Click Next. TPC-2000 Series User Manual... - Page 67 Click Install. Click Finish. Choose Yes, then click OK to restart TPC-2000 Series User Manual...
-
Page 68: Advantech Ec Watchdog Timer Driver Installation
Advantech EC Watchdog Timer Driver Installation Note! The EC driver must be installed first. Follow the steps below to install the EC Watchdog Timer driver: Launch folder <Driver Root Path>\WDT\Vx.xx.xxxx Install AdvWDT_Vx.xx.xxxx.exe TPC-2000 Series User Manual... - Page 69 Click Next. Choose Advantech [EC]WDT, then click Next TPC-2000 Series User Manual...
- Page 70 Click Install. Click Finish. TPC-2000 Series User Manual...
-
Page 71: Advantech Lmsensor Driver Installation
Choose Yes, then click OK to restart. Advantech LMsensor Driver Installation Follow the steps below to install the LMsensor driver: Launch folder <Driver Root Path>\Lmsensor\Vx.xx.xxxx Install AdvLmsensor_EC_Vx.xx.xxxx.exe Next. TPC-2000 Series User Manual... - Page 72 Restart. Note! Go to Advantech’s product support page for the detailed driver user manual. Note! The drivers and utilities used for the panel PCs are subject to change without notice. If in doubt, check Advantech's website or contact our application engineers for the latest information regarding drivers and utilities.
- Page 73 TPC-2000 Series User Manual...
- Page 74 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2021...
