Replacing the Power Supply
Insert the AC-input power supply into the chassis from the front.
Step 1
Install the two power supply retaining screws. Torque to 8 to10 in-lbf (0.9 to 1.1 N-m). See
Step 2
Connect the primary power supply cable to the power supply. Make sure that the locking feature on the
Step 3
power supply end snaps into position. See
Figure 46
.
1
Step 4 Install the bezel onto the front of the chassis as follows:
a.
b.
If you are finished installing modules, install the cover on the router. See the
Step 5
Cover" section on page
Installing and Upgrading Internal Modules in Cisco 2800 Series Routers
46
Primary Power Cable Connection in a Cisco 2821 or Cisco 2851 Router
1
Power supply
Engage the plastic tabs of the bezel into the slots in the chassis.
Slide the bezel until it is centered and tight against the chassis.
51.
Figure 46.
2
2 Primary power cable connector
Figure 43.
"Installing the Chassis
OL-5792-04
