Figure 11 Front Panel of Cisco 2811 Router with DC Input Power
7
SYS AUX/ SYS
PWR PWR ACT CF
COMPACT FLASH
Do Not Remove During Network Operation
1 Input power connection
1
2
On/Stand-by switch
3 Cisco redundant power supply connector (covered if not used)
4 Console and auxiliary ports
1. This switch does not turn off the power supply completely, but rather puts it in stand-by mode.
Figure 12 Rear Panel of Cisco 2811 Router
1
1 Screw holes for ground lug
2 Fast Ethernet port 0/0
3
Fast Ethernet port 0/1
4 High-speed WAN interface card slot 0
1. The network module slot is compatible with Cisco network modules of type NM (network module) and NME (network module enhanced).
OL-5783-01
6 5 4
CONSOLE
1
AUX
0
8
3
OPTIONAL RPS INPUT
12V 11A
5 Universal serial bus (USB) ports
6
External CompactFlash memory card slot
7 LED indicators
7
H
W
I
C
3
H
W
I
C
1
5
5 High-speed WAN interface card slot 1
6 High-speed WAN interface card slot 2
7
High-speed WAN interface card slot 3
8 Network module enhanced (NME) slot
2
24-60 V
6
H
W
I
A= ACT
C
S= SPEED
2
A
FE 0/1
F
H S
W
I
L
C
0
PVDM1 PVDM0
4 3
1
Overview of Cisco 2800 Series Routers
Chassis Views
1
8A
1
A= FDX
A= LINK
A
FE 0/0
F
S
L
AIM1 AIM0
2
