key: = LED off
The Main Menu
By default, the HP NetServer' s control panel display shows something like this:
HP LXr 8000
To reach the main menu from this default screen, press the control panel' s Enter button. The main menu
appears:
The menu selections are:
HW Sys Info. Information on the server's hardware configuration.
FW Info. The version numbers of the server's firmware.
HW P/N. Part number and serial number of the server's chassis.
Event Log. The server's log of current and resolved error conditions.

Rear View

HP TopTools
Remote Control
Card and Connectors
AC
Inlet
Control
PWR
(Power)
PRFL
(Predictive Fail)
power supply or fan, for example), the server may still be operating.
A condition exists which may cause the failure of a server
component.
The server is operating normally.
= LED on = LED blinking
External
SCSI Port
Power Supplies
Lights solid green when system is powered up. If the system is not
powered up but is connected to AC power (so that standby voltage is
available), the LED blinks green. If there is no AC power, the LED is
dark.
Blinks yellow if the speed of the power supply's internal fan falls below
acceptable levels. Power supply has not failed, but may do so soon.
Parallel, Serial,
Keyboard, Mouse,
Monitor Ports
PWR
PRFL
Description
FAIL
33
