Processor Baseboard Jumper Settings - HP D5970A - NetServer - LCII Service & Reference Manual

Number of
Processors
1
2
3
4

Processor Baseboard Jumper Settings

1 2
Disable VRMs
Disable Server Management
3 4
5 6 Bus Ratio Bit 1
Bus Ratio Bit 0
7 8
Bus Ratio Bit 0
9 10
11 12
13 14
15 16
400 Mhz Processor
46
Install Processor
in These Slots
Proc 1
Proc 1
Proc 2
Proc 1
Proc 2
Proc 3
Proc 1
Proc 2
Proc 3
Proc 4
Processor Baseboard Configurations for 1 Through 4 Processors
Pins 11-16 are
unused; spare
jumpers may be
placed here
Terminators Required
for These Slots
Proc 2
Proc 3
Proc 4
Proc 3
Proc 4
Proc 4
None
1
3
5
7
9
11
13
15
Voltage Regulator Modules
Required in These Slots
VRM 1
VRM 2
VRM 3
VRM 1
VRM 2
VRM 3
VRM 4
VRM 1
VRM 2
VRM 3
VRM 4
VRM 5
VRM 1
VRM 2
VRM 3
VRM 4
VRM 5
VRM 6
2
Disable VRMs
Disable Server Management
4
6
Bus Ratio Bit 1
Bus Ratio Bit 0
8
Bus Ratio Bit 0
10
12
Pins 11-16 are
unused; spare
14
jumpers may be
placed here
16
450 Mhz Processor
