System Switches
Specifications
NOTE
Voltage and frequency
Maximum continuous power
input
Maximum inrush current
Delayed action circuit breaker
recommended
Power availability
System dimensions
104
CON0
Clear CMOS
Clear CMOS
Enable
Clear CMOS
Protect
JP 8
Reserved
JP 9
Main BIOS
Flashing
JP10
Boot Block
BIOS Flashing
The HP NetServer LXr Pro8 includes a total of four power supplies. The system
requires three functional supplies at all times; individual supplies can be hot-
swapped.
200-240 VAC; 47-63Hz.
1560W
80A for 10 ms
208/240 60hz: NEMA AB1 20A
220/230/240 50hz -- IEC type C (single server per rack) or type D
(multiple servers per rack) for 16A circuits.
200W continuous to PCI cards and internal drives
17.5 in. high x 19.0 in wide x 32.1 in deep
Con 0
Con 6 5 4 3 2 1 (Reserved)
Con 0
Enable Flashing
Protect
Enable Flashing
Protect
