Model B SIMMs

A Model B SIMM memory board has 16 sockets, each of which may contain a 16 MB, 32 MB, 64 MB, or
128 MB SIMM. For model B SIMMs, you can mix any two sizes from 16 MB, 32 MB, 64 MB, or 128 MB
SIMMs in Bank 2.
Follow these rules when installing memory on this board:
Use only 60 ns HP SIMMs listed on the Product Reference Label, which is located on the side
of the HP NetServer chassis.
Two different SIMM sizes may be combined in the configurations shown below.
Only one size of SIMM may be installed in each bank.
Only these memory configurations are supported:
18
Key in Socket
Notch on SIMM
Retaining latch
Bank 2
Bank 1
