Button
Power
On/Off/
Sleep LED
Reset
Button
Secure
Mode
Button
Secure
Mode LED
Control Panel LCD Screen and Navigation Buttons
Escape
NOTE
50
If sleep states are not available, then this button only turns power On or Off.
The sleep states are NOS dependent and not available if your NOS does not
support power management based on the ACPI standard. A NOS supporting
ACPI allows this button to be configured through a user interface. Refer to
"Applying Power to the HP NetServer" and "Using Sleep States".
This LED glows a steady green when power is On, and dark, when the HP
NetServer is powered Off.
If the HP NetServer is under ACPI control, this LED will flash between green and
dark (off), when in an ACPI sleep state.
This button performs a system reset (hard reset or cold boot).
Puts the HP NetServer in the Secure Mode, if it is configured in the Setup Utility
(BIOS) for the Secure Mode feature.
Secure mode can include such restrictions as keyboard lock, power button lock,
and window blanking. The reset button and scroll keys will also be disabled.
Refer to Security to configure the NetServer's Setup Utility for Secure Mode.
This LED glows a steady green when the HP NetServer is in Secure Mode, and
is dark (off) at all other times.
Not
Used
Enter
Control Panel Display Window and Navigation Buttons
The LCD display can present a custom defined text string used to identify the HP
NetServer, instead of the default HP NetServer LXr 8500. Use the Setup Utility
(BIOS) to create the custom text string.
Scroll Up
One Line
Scroll Down
One Line
Two-Line
Display
