Product Information
System Unit Rear Panel Connectors
This workstation has audio input and output cabability
through external input and output connectors on the
rear panel and through an internal speaker. The rear
panel contains the Line IN (Stereo line-in) and Line
OUT (Stereo line-out) connectors.
The audio connectors are standard stereo audio mini-
jacks. Hewlett-Packard recommends using gold-plated
plugs available through audio retailers. The following
is a summary of the workstation's audio capabilities:
• Audio Features
Programmable sample rates:
8kHz, 16kHz, 32kHz, 48kHz,
11.025kHz, 22.05kHz, and 44.1kHz.
Programmable output attenuation:
0 to -96dB in -1.5dB steps
Programmable input gain:
0 to 22.5dB in 1.5dB steps.
Input monitoring:
16-bit linear, 8-bit u-law, or A-law coding
• Audio Inputs
Line-in
Mono microphone compatible with 1.5V phantom
supply (bias voltage supplied by the system)
CD-ROM audio (if internal CD-ROM is installed)
• Audio Outputs
Line-out
Headset
Built-in mono speaker
