Removing Memory Modules

Before removing memory modules, remove the Main
Tray Assembly from the system unit.
Refer to Chapter 3 for information about memory con-
figurations.
Perform the following steps to remove memory mod-
ules:
1 Locate the memory modules on the CPU board, as shown
Figure 33 Memory Module Location
2 To remove a memory module, push the ejector tabs on
in Figure 33.
Memory Connectors
each side of the module. Lift the memory module up and
out of the connector and place it on a static-free surface.
Figure 34 shows how to remove a memory module.
Field Replaceable Units
FRU Removal and Replacement
103
