Expansion Memory Module - Compaq 6530b - Notebook PC Maintenance And Service Manual

5. Remove the WLAN module (3) by pulling the module away from the slot at an angle.
NOTE:
module slot.
Reverse this procedure to install the WLAN module.

Expansion memory module

Description
2048-MB (PC2-6400, 667-MHz, DDR2)
1024-MB (PC2-6400, 667-MHz, DDR2)
Before removing the expansion memory module, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the memory/WLAN module compartment cover (see
Remove the expansion memory module:
1. Spread the retaining tabs (1) on each side of the memory module slot to release the memory
module. (The edge of the module opposite the slot rises away from the computer.)
WLAN modules are designed with a notch (4) to prevent incorrect insertion into the WLAN
Battery on page 48).
WLAN module on page
Component replacement procedures
Spare part number
483193-001
483194-001
59).
61
