Compaq 6530b - Notebook PC Maintenance And Service Manual page 46

Spare part
number
486285-001
486286-001
486287-001
486288-001
486289-001
486290-001
486291-001
486292-001
486293-001
486294-001
486295-001
486296-001
486770-001
486772-001
486773-001
486774-001
486775-001
486776-001
486777-001
486778-001
486782-001
487330-001
36 Chapter 3 Illustrated parts catalog
Description
Base enclosure for use only with computer models not equipped with a WWAN module (does not include SIM
slot opening)
Display enclosure
Display hinge covers (includes left and right hinge covers)
Fan
Heat sink for use only with HP Compaq 6530b computer models (includes replacement thermal material)
Display Logo Kit
Rear cover
Plastics Kit (see Plastics Kit on page 29
Rubber Kit (not illustrated, contains 7 computer feet)
Screw Kit
6-cell, 47-Wh Li-ion battery
6-cell, 55-Wh Li-ion battery
Display bezel for use only with computer models equipped with a webcam
Display hinges (includes left and right hinges)
Display inverter for use only with HP Compaq 6530b computer models
Display Screw Kit
Display Rubber Kit (includes display bezel screw covers)
Display panel cable
WLAN wireless antenna set (includes 2 transceivers and cables)
WWAN wireless antenna set (includes 2 transceivers and cables)
120-GB, 7200-rpm hard drive (includes hard drive bracket)
Broadcom 4322 802.11a/b/g/n WLAN module for use in Antigua and Barbuda, Barbados, Belize, Canada,
the Cayman Islands, Guam, Puerto Rico, Trinidad and Tobago, the U.S. Virgin Islands,
and the United States
for more Plastics Kit spare part information)
