Compaq 6530b - Notebook PC Maintenance And Service Manual page 34

Item
(4a)
(4b)
(5a)
(5b)
(5c)
(6a)
(6b)
(6c)
(6d)
(7a)
(7b)
(7c)
(8a)
(8b)
24 Chapter 3 Illustrated parts catalog
Description
For use in Spain
For use in Sweden
For use in Switzerland
For use in Taiwan
For use in Thailand
For use in Turkey
For use in the United Kingdom
For use in the United States
Memory modules (PC2-6400, 667-MHz, DDR2)
Primary memory module (located under keyboard)
Expansion memory module (located under memory/WLAN module compartment cover)
2048-MB
1024-MB
TouchPad assemblies (include the components listed below):
Fingerprint reader board and cable (included only in spare part kit 486277-001)
TouchPad board and cable
TouchPad board bracket
For use only with computer models equipped with a fingerprint reader (includes a fingerprint
reader board and cable)
For use only with computer models not equipped with a fingerprint reader
Plastics Kit (see Plastics Kit on page 29
PC Card slot bezel
Memory/WLAN module compartment cover
Hard drive bay cover
Bluetooth module compartment cover
Cable Kit (see Cable Kit on page 30
Bluetooth module cable
Modem module cable (includes RJ-11 connector)
Microphone extension cable
System boards (include system board bracket, system board, and replacement thermal material):
System board bracket
System board
For use only with HP Compaq 6535b computer models equipped with both WLAN and WWAN
modules
for more Plastics Kit spare part information):
for more Cable Kit spare part information):
Spare part
number
486279-071
486279-B71
486279-BG1
486279-AB1
486279-281
486279-141
486279-031
486279-001
483194-001
483193-001
486277-001
486278-001
486292-001
486281-001
488193-001
