Transition from Neoware M100 to HP Compaq 6720t
Mobile Thin Client
Introduction......................................................................................................................................... 1
Symptoms ........................................................................................................................................... 2
Detailed Explanation ............................................................................................................................ 2
Short-term Recovery/Workaround.......................................................................................................... 2
Appendix A: Installing Altiris Bootworks ................................................................................................ 2
For more information.......................................................................................................................... 16
Introduction
Purpose
The HP Compaq 6720t Mobile Thin Client is considered to be the replacement for the pre-merger
M100 Mobile Thin Client offered by Neoware. However, the XPe image for the HP Compaq 6720t
does not contain the EZUpdate agent that resides in the M100 XPe image. The HP recommended
management solution to replace the EZUpdate functionality found in the M100 is Altiris. Included with
your purchase of the 6720t is a license for Altiris Deployment Solution. The local Altiris agent is
already preinstalled in the XPe image for the 6720t, so customers will not be required to install the
agent. Detailed instructions on setting up and using the Altiris Deployment Solution can be found at
the following location.
Audience
This white paper is for use by legacy Neoware customers that are familiar with the EZUpdate
functionality offered in Neoware branded Thin Clients.

Advertisement

loading
Need help?

Need help?

Do you have a question about the 6720t - Mobile Thin Client and is the answer not in the manual?

Questions and answers

Related Manuals for Compaq 6720t - Mobile Thin Client

Summary of Contents for Compaq 6720t - Mobile Thin Client

  • Page 1 Introduction Purpose The HP Compaq 6720t Mobile Thin Client is considered to be the replacement for the pre-merger M100 Mobile Thin Client offered by Neoware. However, the XPe image for the HP Compaq 6720t does not contain the EZUpdate agent that resides in the M100 XPe image. The HP recommended management solution to replace the EZUpdate functionality found in the M100 is Altiris.
  • Page 2 Symptoms HP Compaq 6720t users will not have the ability to perform an FTP Image Update, which is a feature currently supported by EZUpdate. HP´s recommendation is that customers use PXE via the Altiris Deployment Solution as a replacement option for image update functionality. Detailed instructions on setting up and using the Altiris Deployment Solution can be found at the following location: http://www.altiris.com/Products/DeploymentSolution/hpthinclients.aspx...
  • Page 3 3. Enter a unique name for the configuration and a description if desired, then click Next. 4. Choose Microsoft Windows and click Next.
  • Page 4 5. Select the correct Broadcom Integrated Ethernet Adapter from the list and click Next.
  • Page 5 6. Choose Obtain an IP Address from a DHCP server and click Next.
  • Page 6 7. Select Use TCP/IP to connect to Altiris Express Server and click Next.
  • Page 7 8. Enter the domain or workgroup and account privileges to connect to the server and click Next.
  • Page 8 9. Select Manually Create Drive Maps. 10. Verify the UNC path in the box is correct to the Express share on the Altiris server and click Next.
  • Page 9 11. Verify all the information is correct on the last screen and click Finish.
  • Page 10 12. On the Boot Disk Type dialog, select Create an automation partition install package and click Next.
  • Page 11 13. Select Windows setup package and click Next.
  • Page 12 14. Select Create an embedded MS-DOS automation partition and click Next.
  • Page 13 15. Enter the installer package file path and select Run silent install and click Next.
  • Page 14 16. Verify that the setup package was created at the noted location and click Close.
  • Page 15 17. Verify all the information is correct on the last screen.

  • Page 16: For More Information

    This package can now be added to a job under the Distribute Software function and Altiris Deployment Solution Product deployed to a client or group of clients. Refer to the Guide for more information on creating jobs. For more information To learn more about HP Mobile Thin Clients, contact your local HP sales representative or visit our Web site at: http://h20000.www2.hp.com/bizsupport/TechSupport/Home.jsp?lang=en&cc=us&prodTypeId=321957&prodSe...
