Speaker - Compaq 6530b - Notebook PC Maintenance And Service Manual

Speaker

Description
Speaker
Before removing the speaker, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the following:
a. Hard drive (see
b. Optical drive (see
c. Keyboard (see
d. Switch cover (see
e. Display assembly (see
f. Top cover (see
g. ExpressCard board (see
h. Audio board (see
Remove the speaker:
1. Remove the three Phillips PM2.0×5.0 screws (1) that secure the speaker to the base enclosure.
Battery on page 48).
Hard drive on page 54)
Optical drive on page
Keyboard on page 63)
Switch cover on page
Display assembly on page
Top cover on page 83)
ExpressCard board on page
Audio board on page
57)
67)
76)
88)
89)
Component replacement procedures
Spare part number
486280-001
93
