Compaq 6530b - Notebook PC Maintenance And Service Manual page 32

Item
22 Chapter 3 Illustrated parts catalog
Description
●
WXGA BrightView display assembly with 1 microphone
●
WXGA+ display assembly with 2 microphones and webcam
●
WXGA+ display assembly with 1 microphone
● WXGA display assembly with 2 microphones and webcam
●
WXGA display assembly with 1 microphone
For use only with HP Compaq 6535b computer models equipped with a WLAN module and no WWAN module:
●
WXGA BrightView display assembly with 2 microphones and webcam
●
WXGA BrightView display assembly with 1 microphone
● WXGA+ display assembly with 2 microphones and webcam
● WXGA+ display assembly with 1 microphone
●
14.1-inch WXGA display assembly with 2 microphones and webcam
●
14.1-inch WXGA display assembly with 1 microphone
For use only with HP Compaq 6530b computer models equipped with both WLAN and WWAN modules:
●
WXGA BrightView display assembly with 2 microphones and webcam
● WXGA BrightView display assembly with 1 microphone
● WXGA+ display assembly with 2 microphones and webcam
●
WXGA+ display assembly with 1 microphone
●
WXGA display assembly with 2 microphones and webcam
●
WXGA display assembly with 2 microphones and webcam
For use only with HP Compaq 6530b computer models equipped with a WLAN module and no WWAN module:
● WXGA BrightView display assembly with 2 microphones and webcam
●
WXGA BrightView display assembly with 1 microphone
●
WXGA+ display assembly with 2 microphones and webcam
●
WXGA+ display assembly with 1 microphone
●
WXGA display assembly with 2 microphones and webcam
● WXGA display assembly with 1 microphone
Display internal components:
Display bezels
For use only with computer models equipped with a webcam
For use only with computer models not equipped with a webcam
Display hinge covers (includes left and right hinge covers)
Display hinges (includes left and right hinges)
Display inverters
Spare part
number
492170-001
492165-001
492166-001
492161-001
492162-001
492171-001
492172-001
492167-001
492168-001
492163-001
492164-001
486273-001
486274-001
486269-001
486270-001
486265-001
486266-001
486275-001
486276-001
486271-001
486272-001
486267-001
486268-001
486770-001
487339-001
486287-001
486772-001
