ExpressCard board

Description
ExpressCard board (includes RTC battery)
Before removing the ExpressCard board, follow these steps:
1. Shut down the computer. If you are unsure whether the computer is off or in Hibernation, turn the
computer on, and then shut it down through the operating system.
2. Disconnect all external devices connected to the computer.
3. Disconnect the power from the computer by first unplugging the power cord from the AC outlet and
then unplugging the AC adapter from the computer.
4. Remove the battery (see
5. Remove the following:
a.
b.
c.
d.
e.
f.
Remove the ExpressCard board:
1. Remove the two Phillips PM2.5×3.0 broad-head screws (1) that secure the ExpressCard board to
the computer.
2. Remove the ExpressCard board (2).
Reverse this procedure to install the ExpressCard board.
88 Chapter 4 Removal and replacement procedures
Battery on page
Hard drive (see Hard drive on page
Optical drive (see Optical drive on page
Keyboard (see Keyboard on page
Switch cover (see Switch cover on page
Display assembly (see
Top cover (see Top cover on page
48).
54)
57)
63)
67)
Display assembly on page
83)
Spare part number
486251-001
76)
