Managing Mesh Access Points with Cisco Prime Infrastructure
Table 47: Definition for SNR and Packet Error Rate Link Color
Link Color
Green
Amber
Red
The Link label and color settings are reflected on the map immediately. You can display both SNR and PER
Note
values simultaneously.
Step 2
To modify which mesh access points display based on the number of hops between them and their parents, do the
following:
In the Mesh Parent-Child Hierarchical View, click the Quick Selections drop-down list.
Select the appropriate option from the list.
Table 48: Quick Selection Options
Parameter
Select only Root APs
Parameter
Select up to 1st hops
Select up to 2nd hops
Select up to 3rd hops
Select up to 4th hops
Select All
Click Update Map View to refresh the screen and redisplay the map view with the selected options.
Map view information is retrieved from the Cisco Prime Infrastructure database and is updated every 15 minutes.
Note
OL-27593-01
Link SNR
Represents an SNR above 25 dB (high value)
Represents an SNR between 20 and 25 dB
(acceptable value)
Represents an SNR below 20 dB (low value)
Using Mesh Filters to Modify Map Display of Maps and Mesh Links
Packet Error Rate (PER)
Represents a PER of one percent (1%) or lower
Represents a PER that is less than ten percent
(10%) and greater than one percent (1%)
Represents a PER that is greater than ten percent
(10%)
Description
Choose this setting if you want the map view to display
root access points only.
Description
Choose this setting if you want the map view to display
1st hops only.
Choose this setting if you want the map view to display
2nd hops only.
Choose this setting if you want the map view to display
3rd hops only.
Choose this setting if you want the map view to display
4th hops only.
Select this setting if you want the map view to display all
access points.
