STEP 3. Assembly of center frame cover and rear running leg cover.
1.1 Align the hole in the center shroud with the hole in the center of the running leg set and attach
with M5 bolt.
1.2 Turn the units middle adjustment foot pads until they are lifted above the ground.
1.3 Turn the units rear adjustment foot pads so that they contact the floor and the unit does not
lean (to the left or right).
1.4 Turn the middle foot pads down to the floor. Try to slide a piece of paper under all four foot
pads to verify that they all touch the floor.
1.5 The unit should not lean to the left or the right and should be stable.
1.6 Place the plastic cover on the rear stabilizer tube as shown and attach with bolts.
BH Fitness • 20155 Ellipse • Foothill Ranch • CA • 92610
www.bhnorthamerica.com • Phone 949-206-8152 • Fax 949-206-0013
ASSEMBLY INSTRUCTIONS CONTINUED
Rear foot pads
12
BH X8 ELLIPTICAL
Middle foot pads
