Post Error Codes - Intel SBXL52 - Server Compute Blade Hardware Maintenance Manual

NOTE
See "System" on page 104 to determine which components should be replaced by a field service
technician.
Error code/symptom
217-XXX-000
(Failed hard disk drive test)
NOTE
If RAID is configured, the hard disk
drive number refers to the RAID
logical array.
217-XXX-001
(Failed hard disk test)
NOTE
If RAID is configured, the hard disk
number refers to the RAID logical
array.
405-XXX-000
(Failed Ethernet test on controller on the
system board)

POST error codes

In the following error codes, X can be any number or letter.
NOTE
See "System" on page 104 to determine which components should be replaced by a field service
technician.
Error code/symptom
062
(Three consecutive startup failures using
the default configuration.)
101, 102
(System and processor error)
106
(System and processor error)
111
(Channel check error)
114
(Adapter read-only memory error)
76
FRU/action
•
Hard disk drive 1
• Hard disk drive 2
1. Verify that Ethernet is not disabled in BIOS.
2. System board.
FRU/action
1. Run the Configuration/Setup Utility program.
2. Battery.
3. System board.
4. Microprocessor.
• System board
• System board
1. Failing adapter
2. DIMM
3. System board
1. Failing adapter.
2. Run diagnostics.
SBXL52: Hardware Maintenance Manual and Troubleshooting Guide
