Intel SBXL52 - Server Compute Blade Hardware Maintenance Manual page 89

NOTE
See "System" on page 104 to determine which components should be replaced by a field service
technician.
Error code/symptom
166-201-003 System Management:
Failed (I2C bus error(s) See SERVPROC
and DIAGS entries in event log.)
166-201-004 System Management:
Failed
(I2C bus error(s) See SERVPROC and
DIAGS entries in event log.)
166-201-005 System Management:
Failed
(I2C bus error(s) See SERVPROC and
DIAGS entries in event log.)
166-342-000 System Management:
Failed
(ASM adapter BIST indicate failed tests.)
166-400-000 System Management:
Failed (ISMP self test result failed tests: x
where x = Flash, RAM, or ROM.)
180-XXX-000 (Diagnostics LED failure)
180-XXX-001
(Failed front LED panel test)
180-XXX-002
(Failed diagnostics LED panel test)
180-XXX-003
(Failed system board LED test)
180-XXX-005
(Failed SCSI backplane LED test)
201-XXX-0nn
(Failed memory test.)
201-XXX-999
(Multiple DIMM failure, see error text)
202-XXX-001
(Failed system cache test)
202-XXX-002
(Failed system cache test)
217-198-XXX
(Could not establish drive parameters)
Symptom-to-FRU index
FRU/action
1. I/O adapter
2. System board
1. SCSI storage expansion unit
2. System board
1. DIMMs
2. Microprocessors
3. System board
1. Ensure the latest firmware levels for Remote Supervisor
Adapter and BIOS are installed.
2. Power down blade server and reseat it in chassis.
3. Remote Supervisor Adapter.
1. Reflash or update firmware for ISMP.
2. System board.
• Run diagnostics panel LED test for the failing LED.
1. Front bezel with customer interface card
2. System board
• System board
•
System board
1. SCSI storage expansion unit
2. System board
1. DIMM Location slots 1-4 where nn = DIMM location.
NOTE
nn 1=DIMM 1; 2=DIMM 2; 3=DIMM 3; 4=DIMM 4.
2. System board.
1. See error text for failing DIMMs.
2. System board.
1. Microprocessor 1
2. System board
1. Microprocessor 2
2. System board
• SCSI storage expansion unit
