Microprocessor:
Supports up to 2 microprocessors
® ™
• Intel Xeon Processor
• 512 KB ECC L2 cache
• 533 MHz front-side bus (FSB)
Memory:
• Four double data rate (DDR)
PC1600 sockets
• Minimum: 512 MB
• Maximum: 4 GB
•
Type: 2-way interleaved, DDR,
PC2100, ECC SDRAM
registered x4 (Chipkill) DIMMs
only
NOTE
PC2100 DIMMs are
backward-compatible
and can function in the
PC1600 sockets
• Supports 256 MB, 512 MB,
and 1 GB dual inline memory
modules (DIMMs)
Drives:
•
Support for up to two internal
IDE 2.5-inch hard disk drives
• Support for up to two Ultra320
SCSI hot-swap hard disk
drives available in an optional
SCSI storage expansion unit
NOTE
The operating system in the blade server must provide USB support for the blade server to
recognize and use the keyboard, mouse, CD-ROM drive, and diskette drive. The SBCE unit
uses USB for internal communications with these devices.
Introduction
Size:
•
Height: 24.5 cm (9.7 inches)
• Depth: 44.6 cm (17.6 inches)
•
Width: 2.9 cm (1.14 inches)
• Maximum weight: 5.4 kg (12
lb)
Integrated functions:
• Two Gigabit Ethernet
controllers
• ATI* Rage* XL video
controller
• Light path diagnostics
• Local service processor
• IDE hard disk drive controller
•
RS-485 interface for
communication with SBCE
management module
• USB buses for
communication with
keyboard, mouse, diskette
drive, and CD-ROM drive
Predictive Failure Analysis
(PFA) alerts:
• Microprocessor
•
Memory
• Hard disk drives
Environment:
•
Air temperature:
— Blade server on: 10 to
35 C (50 to 95 F).
Altitude: 0 to 914 m
(2998.69 ft)
— Blade server on: 10 to
32 C (50 to 95 F).
Altitude: 914 m to 2134 m
(2998.69 ft to 7000 ft)
— Blade server off: -40 to
60 C (-40 to 140 F)
•
Humidity:
— Blade server on: 8% to
80%
— Blade server off: 5% to
80%
Electrical input:
• Input voltage: 12 V dc
