NOTE
See "System" on page 104 to determine which components should be replaced by a field service
technician.
Error code/symptom
1301
(I2C cable to operator information panel
not found)
1302
(I2C cable from system board to power-
on and reset switches not found)
1303
(I2C cable from system board to power
backplane not found)
1304
(I2C cable to diagnostic LED board not
found)
1762
(Hard disk configuration error)
178X
(Fixed disk error)
1800
(No more hardware interrupt available for
PCI adapter)
1962
(Drive does not contain a valid boot
sector)
2400
(Video controller test failure)
Symptom-to-FRU index
FRU/action
1. Cable
2. Operator information card
3. Power switch assembly
4. System board
1. Cable
2. Power switch assembly
3. System board
1. Cable
2. Power supply
3. System board
1. Power switch assembly
2. System board
1. Hard disk drive.
2. Hard disk drive cables.
3. Run the Configuration/Setup Utility program.
4. SCSI storage expansion unit.
5. System board.
1. Hard disk drive cables.
2. Run diagnostics.
3. Hard disk drive.
4. System board.
1. Run Configuration/Setup to verify that the interrupt resource
settings are correct.
2. Failing adapter (if installed).
3. System board.
1. Verify that a startable operating system is installed.
2. Run diagnostics.
3. Hard disk drive.
4. SCSI storage expansion unit.
5. System board.
1. Verify that the keyboard/mouse/video select button LED on the
front of the blade server is on, indicating that the blade server is
connected to the shared SBCE monitor.
2. Verify that the monitor is connected correctly to the SBCE unit.
3. Video adapter (if installed).
4. System board.
