Tools/Hardware needed:
• Wire stripper/cutter
• Drill or duct-cutting tool
• 1-3/4-in. hole saw
• 1/8-in. drill bit
• Phillips and slotted (or Torx) screwdriver
• 18-gauge thermostat wire (5 or 2 conductor)
* Warranty requires in-line water filter installation with regular service.
WhaT you WIll need To InsTall TRuesTeam
Material Provided:
• 1/4-in. copper or plastic water line
• 1/2-in. drain hose and clamps
• Mounting bracket and hardware
• In-line water filter* (50028044-001)
• Saddle valve
• Back-flow valve (50030142-001)
Options:
• Remote Installation Kits
• Humidity Controls
• Water line T-fitting
• Manual shut-off valve
• Remote hose P-trap
• Remote mount duct board adapter kit
• Differential pressure switch (50027910-001)
3
TrueSTEAM Humidification System
– 10-foot hose and nozzle kit (50024917-001)
– 20-foot hose and nozzle kit (50024917-002)
– Manual Humidistat (H8908ASPST)
– TrueIAQ (DG115EZIAQ)
– VisionPRO IAQ (YTH9421C1010)
(32005530-001)
69-2036EFS—07
