Figure 3-17 LEDs and Sensors Tab
Note For a detailed explanation of physical LEDs on the hardware components, please refer to the section
7012 Component LEDs, page
System Tab
The System tab displays the overall system information of the SFS 7012. This information includes the
following items:
Out of Band LAN IP
Netmask
System Description
IB Node Description
Note
System Uptime
System Contact
Cisco SFS 7012 InfiniBand Server Switch Hardware Users Guide
50
2-34.
The IP address of the switch. Note that changes to this field only take effect after a switch power
cycle (i.e., shutting the switch and powering it back up). The IP address of the switch can be changed
by the administrator.
The current net mask settings for the chassis. Note that changes to this field only take effect after a
chassis power cycle (i.e., shutting down the chassis and powering it back up). The net mask of the
chassis can be changed by the administrator.
A textual description of the system, which can be assigned by the administrator.
Assigned by the administrator, the IB node description is an IB fabric-applicable name that will be
displayed within a subnet manager GUI. Note that changes to this field will only take effect after a
the chassis is rebooted. To reset this field to the default setting, click the Field Default button.
If the IB Node Description field has been changed since the last reboot of either spine, the next
reboot will be treated as disruptive.
The elapsed time since the last time switch was re-initialized.
