Figure 3-4
Displaying the Leaf and Spine Module Views
Leaf Module View
To display the leaf module view for the SFS 7012:
Mouse over the leaf module to display. The edges of the leaf module are highlighted green as shown in
Step 1
Figure 3-5 below:
Figure 3-5
Left click the mouse. The leaf module view will be displayed.
OL-8787-04
Support Contact Screen
Leaf Module Mouseover
Cisco SFS 7012 InfiniBand Server Switch Hardware Users Guide
43
