Chapter
•
•
Figure 3-9

Leaf and Spine Details Header

The leaf and spine Details Header allows the user to execute the most common tasks for the SFS 7012
switch:
•
•
•
Figure 3-10 Leaf and Spine Details Header

Leaf and Spine Information Area

The Leaf and Spine Information Area allows the user to view high-level information for each specific
leaf or spine module. The information area contains two different fields:
•
•
Additionally, the Component Information Area has Apply and Refresh buttons, which perform the
following functionality:

Displaying the Chassis View

There are two ways to display the chassis view for the SFS 7012:
OL-8787-04
Information area.
Menu
Leaf and Spine Component Details Area
Display the Home page
View field-replaceable unit (FRU) information.
Access online help
The white fields allow the user to add or modify applicable general and system information that is
specific to their environment.
The gray fields are tied to live data from the selected hardware component as well as live system
information.
Apply:
Saves any user edits within the white fields to flash memory.
Refresh:
Refreshes all fields in the information areas.
Cisco SFS 7012 InfiniBand Server Switch Hardware Users Guide
45
