On the switch fan side, insert the notches on the top of the fascia into the two slots on the chassis frame.
Step 1
Snap the bottom of the faceplate in place.

Removing a Module or Blank

The handles are self-locking. To unlock, push up on the handles to disengage from the lock notch. Then
gently pull the handles out and slide the module out of the slot.
If removing, but not replacing a module, remember to replace with a module blank. All slots must be
Note
either populated with a module or have blanks for EMI and thermal integrity.

Installing the Spine and Leaf Modules

The purchased configuration for the SFS 7012 is shipped fully populated. Follow these steps when it
Note
becomes necessary to install or replace spine modules and leaf modules.
Remove the necessary spine modules, spine module blanks, leaf modules, and leaf module blanks. For
Step 1
detailed instructions, please refer to the section
If the user is only adding additional modules, remove only the blank(s) for the slot(s) to be populated.
Note
These will not be replaced.
When placing the spine modules and leaf modules into chassis slots, the following recommendations
Step 1
apply:
a.
Refer to
Cisco SFS 7012 InfiniBand Server Switch Hardware Users Guide
26
Spine Modules — It is recommended that the spine module(s) be installed into:
Slot 1 for managed. For redundant management, populate slots 1 and 2 with management-capable
–
spines.
Slot 3 for unmanaged.
–
Figure 2-9 below:
Removing a Module or Blank, page
Chapter
2-26.
OL-8787-04
