Product Overview
The Cisco SFS 7012™ is an industry leading modular system used for creating large, single-system
Grid/Cluster server fabrics, or as a building block for larger fabrics. The SFS 7012 is designed to
maximize performance, streamline operations, and ensure uptime by providing full hardware and
software reliability, availability, and serviceability (RAS) features.
Leveraging InfiniBand (IB) — an industry-standard interconnect — the SFS 7012 provides high
performance, offering a full bisectional bandwidth (FBB) fabric (10Gb-30Gb) and ultra-low switching
latency. Additionally, the SFS 7012 can be configured to run at 2.5 Gbps single data rate (SDR), 5.0
Gbps double data rate (DDR), or both.
All major SFS 7012 components and expansion modules are field replaceable and hot pluggable. To
allow easy scaling, the SFS 7012 provides 12 expansion slots. Each slot can support expansion modules
with twelve 10 Gbit/sec (or 4X) IB ports, meaning the SFS 7012 can scale to 144 (4X) InfiniBand ports.
The SFS 7000 Series switches make possible the highest density of InfiniBand fabrics available today.

SFS 7012 Feature Set

Strategic Benefits

•
•
•
•

Key Design Features

•
•
•
•
•
•
•
OL-8787-04
Creates the industry's simplest way to build medium to large server fabrics
– Modular systems up to 144 ports (4X)
Eliminates requirement for parallel storage networks
High-availability design for mission critical needs
Lowers Total Cost of Ownership (TCO)
All field-replaceable units (FRU's) can be replaced while under power
Redundant management, power and cooling
High performance 10Gb/s
Full Bisectional Bandwidth InfiniBand switching fabric
Twelve (12) expansion slots for InfiniBand (4X)
SDR and DDR support
Embedded system management
