7.3.6 Set Custom Name

Sets the Custom Name that can be displayed when the unit powers up.
7.3.6.1 Packet Description
Application Header:
Command
Data Count
Application Data:
Data[0]
Data[1]-Data[DataCount-1] CustomName
7.3.6.2 Data Description
CustomNameEnable:
DataType:
TRUE:
FALSE:
CustomName:
Data Type:
Max Length:
7.3.6.3 RV-8 Response
If the custom name enable is TRUE then the custom name banner is display on "power on". If
the Custom Name Enable is FALSE the custom name is not displayed. The CustomName string
is copied to Nonvolatile RAM. The RV8 will ACK when completed with this command.
7.3.6.4 Data Validation
No data validation is done on the transmitted data.

7.3.7 Host Wakeup

By transmitting the Wakeup Notification, the Host indicates it has just "powered on" or reset and
is ready to receive RV-8 Notifications or Responses. The Host is assumed to be asleep upon
power up of the RV-8. Host status is maintained during standby.
7.3.7.1 Command Packet Description
7.3.7.2 Data Description
7.3.7.3 RV-8 Response
The RV-8 will respond to this command with an ACK. The unit also returns the input name, audio
status, and mode.
DC_CMD_SET_CUST_NAME 0x2C
Number of characters in
CustomName + 2
CustomNameEnable
Enables/Disables the Custom Name Display.
Boolean
CustomName Enabled
CustomName Disabled
Null (0x00) terminated ASCII character string.
CUSTOM_NAME_LENGTH defined in Appendix G Protocol Constants.
Application Header:
Command HOST_WAKEUP
Data Count 0
Application Data:
N/A
N/A
RV-8 Serial Communications Protocol
nn
nn
ch ch ch ... 0x00
0x11
0x00
18
