Lexicon RV-8 V2.0 - SERIAL PROTOCOL DEFINITIONS REV 1-8 Manual

Serial protocol definition
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
RV-8
Serial Protocol Definition
Software Version 2.0
Protocol Version:
Major Rev 1
Minor Rev 8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RV-8 V2.0 - SERIAL PROTOCOL DEFINITIONS REV 1-8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lexicon RV-8 V2.0 - SERIAL PROTOCOL DEFINITIONS REV 1-8

Summary of Contents for Lexicon RV-8 V2.0 - SERIAL PROTOCOL DEFINITIONS REV 1-8

  • Page 1 RV-8 Serial Protocol Definition Software Version 2.0 Protocol Version: Major Rev 1 Minor Rev 8...
  • Page 2 Lucasfilm Ltd. Surround EX is a trademark of Dolby Laboratories. Used under authorization. "DTS," "DTS-ES," "Neo:6, " and “DTS 96/24” are trademarks of Digital Theater Systems, Inc. "Lexicon," "LOGIC7," and the L7 logo are registered trademarks of Harman International Industries, Inc. © 2007 Harman International Industries, Inc. All rights reserved.

  • Page 3: Table Of Contents

    Lexicon RV-8 Serial Communications Protocol Documents Definitions Protocol Version Cross-reference Abbreviations General Description Physical Layer DB-9 RS232 Connector Serial Port Driver Errors RV8 Receive Buffer RV8 Hardware Verification Data Link Layer Errors Application Layer RV8 Asynchronous Notification Packets 7.1.1 Wakeup Notification 7.1.2...
  • Page 4 Lexicon RV-8 Serial Communications Protocol 7.3.26 Set Front/Back Balance 7.3.27 Set Active Effect by Id 7.3.28 Set Zone 2 Volume 7.3.29 Set Zone 2 Left/Right Balance 7.3.30 Get Input Name by Id Appendix A: Command Codes Appendix B: Error Codes...

  • Page 5: Documents

    The device initiating or receiving the serial communication packets to/from the RV8. RV8: The Lexicon product receiving or transmitting the serial communication packets to/from the HOST. Nonvolatile FLASH: The area of memory in an RV8 that stores users adjustable parameters.

  • Page 6: Physical Layer

    Lexicon RV-8 Serial Communications Protocol initiates indicating system changes. Each transaction initiated must wait for a corresponding response before initiating the next transmission. The 3 protocol layers are: Physical, Data Link, and Application Layers. Physical Layer (RS232) Data Link Layer...

  • Page 7: Rv8 Receive Buffer

    Lexicon RV-8 Serial Communications Protocol 5.4 RV8 Receive Buffer The RV8 has an internal receive buffer. The buffer is 256 Bytes and will transmit a NAK packet with an error code of DC_ERR_BUFFER_FULL to the HOST if the buffer is full. If the buffer is full, all data transmitted to the RV8 will be ignored.

  • Page 8: Application Layer

    Lexicon RV-8 Serial Communications Protocol process the erroneous application packet. The HOST can use this as an indicator to retransmit the corrupted packet. In addition, each byte of a packet must be received sequentially and within the INTER_PACKET_TIME. If any of the bytes within a packet transmission exceeds the INTER_PACKET_TIME, the RV8 will respond by transmitting a NAK packet with an error code DC_ERR_INVALID_PACKET.

  • Page 9: Front Panel Display

    Lexicon RV-8 Serial Communications Protocol 7.1.3 Front Panel Display RV8 will transmit the front panel display buffer following the update to the RV8 front panel display. The RV8 front panel display is 2 X 20 ASCII character display. The HOST can enable transmission of this notification message by sending Host Wakeup (7.3.29).

  • Page 10: Rv-8 Parameter Change

    Lexicon RV-8 Serial Communications Protocol 7.1.4 RV-8 Parameter Change RV8 will transmit predetermined parameter change notifications. If a parameter value is changed due to any user action or system action the RV8 will transmit the current value of the parameter that is changing.

  • Page 11: Rv8 Parameter Notification By Id

    Lexicon RV-8 Serial Communications Protocol 7.1.4.4 Supported System Parameters The following parameters will be supported by this Parameter Change Notification: Parameter DC Parameter Name DC Param Hex Code Current Effect PROGRAM 0x01 Mute MUTE 0x 03 System Volume VOLUME 0x 05...

  • Page 12: Acknowledgment Packets

    Lexicon RV-8 Serial Communications Protocol 7.1.5.4 Defaults The following Parameters Notifications are enabled in the RV-8 default state: Note: These default notifications may not return the correct values. To ensure the return of correct values for a particular Parameter, it is best to query that Parameter explicitly using the commands described in 7.3.18 (Get Parameter Value by Id)

  • Page 13: No Acknowledge

    Lexicon RV-8 Serial Communications Protocol 7.2.1.2 Data Description Command: DataType: Valid RV8 command as defined in Appendix A Command Codes. 7.2.2 No Acknowledge 7.2.2.1 Packet Description Application Header: Command DC_NACK 0xE1 Data Count 0x02 Application Data: Data[0] Command Data[1] ErrorCode 7.2.2.2 Data Description...

  • Page 14: Get Array Definition(Rv8)

    Lexicon RV-8 Serial Communications Protocol 7.3.2.1 Command Packet Description Application Header: Command DC_CMD_GET_CUST_NAME 0x2B Data Count 0 0x00 Application Data: 7.3.2.2 Data Description 7.3.2.3 Custom Name Response Packet Application Header: Command DC_RESP_CUST_NAME 0x89 Number of Characters in Data Count CustomName + 1...

  • Page 15: Get Arrayitem(Rv8)

    Lexicon RV-8 Serial Communications Protocol 7.3.4 Get ARRAYITEM(RV8) This command will request the current state of the ARRAY ITEM. 7.3.4.1 Command Packet Description Application Header: Command MC_CMD_GET_ARRAYITEM 0x4A Data Count 5 0x05 Application Data: Data[0] Param ID for Array(LSB) 0xnn...
  • Page 16 Lexicon RV-8 Serial Communications Protocol 7.3.4.3 PARAM.TUNER.PRESETS Response Example Application Header: Command MC_RESP_ARRAYITEM 0x98 Data Count 0x13 Application Data: Data[0] ParamID(LSB) 0xA2 Data[1] ParamID(MSB) 0x06 Data[2] Data Type 0x0B Data[3] Index(LSB) 0x01 Data[4] Index(MSB) 0x00 Data[5]…Data ch ch ch {13] Preset Name …...

  • Page 17: Set Arrayitem(Rv8)

    Lexicon RV-8 Serial Communications Protocol 7.3.5 Set ARRAYITEM(RV8) This command will set the array item to the value supplied by the data. 7.3.5.1 Command Packet Description Application Header: Command MC_CMD_SET_ARRAYITEM 0x4B Data Count Num Bytes/ArrayItem + 5 0xnn Application Data:...

  • Page 18: Set Custom Name

    Lexicon RV-8 Serial Communications Protocol 7.3.6 Set Custom Name Sets the Custom Name that can be displayed when the unit powers up. 7.3.6.1 Packet Description Application Header: Command DC_CMD_SET_CUST_NAME 0x2C Number of characters in Data Count CustomName + 2 Application Data:...

  • Page 19: Host Sleep

    Lexicon RV-8 Serial Communications Protocol 7.3.8 Host Sleep By transmitting the Sleep command, the Host indicates it has just “powered down” and will no longer respond to RV-8 Notifications. No Acknowledgment is expected. The Host is assumed to be asleep upon power up of the RV-8. Host status is maintained during standby.

  • Page 20: Set Communication Configuration

    Lexicon RV-8 Serial Communications Protocol 7.3.10 Set Communication Configuration The Set Communication Configuration Command allows the serial port user to set up the various serial port/ protocol configuration parameters. 7.3.10.1 Command Packet Description Application Header: Command DC_CMD_SET_COM_CONFIG 0x30 Data Count...

  • Page 21: Send Display String Command

    Lexicon RV-8 Serial Communications Protocol The RV-8 will set the mute state according to the value transmitted. The RV-8 may still be full muted if other conditions require the audio path to be muted. This is only a direct access to the user mute state.

  • Page 22: Get Parameter Definition By Id

    Lexicon RV-8 Serial Communications Protocol 7.3.13 Get Parameter Definition by Id Request to RV-8 for a Parameter Definition by Parameter Id. RV-8 will respond with “RV8 Parameter Definition Packet”. 7.3.13.1 Command Packet Description Application Header: Command MC_GET_PARAM_BY_ID 0x35 Data Count 2...
  • Page 23 Lexicon RV-8 Serial Communications Protocol ParamType: Param Type Name ParamTy Type Description Data Size pe ID (Bytes) PARAM_TYPE_UINT8 Unsigned 8 bit integer(0 to 255) PARAM_TYPE_UINT16 Unsigned 16 bit integer(0 to 65535) PARAM_TYPE_CSTR8 Zero terminated string of 8 ascii characters PARAM_TYPE_CSTR13...

  • Page 24: Set Parameter Value By Id

    Lexicon RV-8 Serial Communications Protocol Max Value: This is a 16 bit value representing the maximum value for a parameter. Parameter values exceeding the maximum will be limited to the maximum. This may be a signed or unsigned value depending on the Parameter Type.

  • Page 25: Set Parameter Value By Id, No Run

    Lexicon RV-8 Serial Communications Protocol PARAM_TYPE_CSTR13 Zero terminated string of 13 ascii characters PARAM_TYPE_UINT32 Unsigned 32 bit integer (0 to 4,294,967,295 ) PARAM_TYPE_BOOLEAN Boolean (0 to 1) PARAM_TYPE_INT8 Signed 8 bit integer (-127 to 128) PARAM_TYPE_BRANCH Parameter Branch PARAM_TYPE_INT16 Signed 16 bit integer...

  • Page 26: Get Unit Configuration

    Lexicon RV-8 Serial Communications Protocol 7.3.15.1 Command Packet Description Application Header: Command MC_CMD_SET_SYS_PARAM_VALUE_BY_ID_NO_RUN 0x37 Data Count 24 0x18 Application Data: Data[0] ParamId(LSB) Data[1] ParamId(MSB) Data[2] ParamType nn nn Data[3-23] Value[0 -20] nn… 7.3.15.2 Data Description Same as Paragraph 7.3.37.2 7.3.16 Get Unit Configuration Request to RV-8 for its current unit configuration.
  • Page 27 Return0 Data[27] Return0 Data[28] Return0 Data[29] Return0 7.3.16.3 Data Description ProductId: This unsigned 8 bit value describes the product. Product ID Lexicon DC-2 Lexicon MC-1 JBL Synthesis SDP-3 Lexicon MC-12 JBL Synthesis SDP-40 Lexicon MC-8 JBL Synthesis SDP-5 Lexicon RV-8...
  • Page 28 Lexicon RV-8 Serial Communications Protocol Software Type: An unsigned 8 bit value indicating the current configuration of the unit’s software. The following table shows the values assigned to the available types: SW Type COMPLETE BOOTROM Software Level: The following table shows the values assigned to the possible software...

  • Page 29: Send Ir Command

    Lexicon RV-8 Serial Communications Protocol TimeStamp: Is a null terminated ASCII text string describing the build date and time of the current software build. The Format of this text string is: “yy/mm/dd(sp)hh:mm” yy- is the last two digits of the year (i.e. year 2001=01, year 2002 = 02)

  • Page 30: Set Parameter Notification By Id

    Lexicon RV-8 Serial Communications Protocol 7.3.18.2 Data Description ParamId: Data Type: Unsigned 16 bit integer. Max: Max Parameter Count as reported by the RV-8 Unit Configuration Response Packet in 7.3.39.2 7.3.18.3 Data Validation If ParamId exceeds the its maximum value, the RV-8 will ignore the command and transmit a DC_NAK command with an error code DC_INVALID_PARAM_ID.

  • Page 31: Parameter Get Value String By Id

    Lexicon RV-8 Serial Communications Protocol If ParamId exceeds the its maximum value, the RV-8 will ignore the command and transmit a DC_NAK command with an error code DC_INVALID_PARAM_ID. 7.3.19.4 RV-8 Response If a parameter has been enabled for notification the RV-8 will transmit its current value whenever it has been changed due to any user or system action.

  • Page 32: Clear All Parameter Notifications

    Lexicon RV-8 Serial Communications Protocol 7.3.20.5 Data Description Value String: Data Type: Null (0x00) terminated ASCII string. Max Length: 21 (20 characters plus terminating Null) 7.3.21 Clear All Parameter Notifications Request to the RV-8 to disable all RV-8 parameter notifications.
  • Page 33 Lexicon RV-8 Serial Communications Protocol 7.3.22.3 Data Description System Volume: Data Type: Signed 8-bit integer (2’s compliment) Max: +12 (0x0C) (12 dB) Min: -80 (0xB0) (-80 dB) Current Input: Data Type: Unsigned 8-bit integer Definition/Conversion: Appendix F RV-8 Input Ids...

  • Page 34: Get Zone 3 Status

    Lexicon RV-8 Serial Communications Protocol Min: -16 (0xF0) (Full Back) Video Sync: Data Type: Boolean. TRUE: RV-8 has detected Video Sync for current video input FALSE: RV-8 can not detect Video Sync for the current video input 7.3.23 Get Zone 3 Status This command is a request to RV-8 for current Zone 3 Status.

  • Page 35: Set System Volume

    Lexicon RV-8 Serial Communications Protocol Zone 3 Balance: Data Type: Signed 8-bit integer (2’s compliment) Max: 16 (0x10) (Full Right) Min: -16 (0xF0) (Full Left) 7.3.24 Set System Volume This command is a request to the RV-8 to set the system volume with the value in this packet.

  • Page 36: Set Front/Back Balance

    Lexicon RV-8 Serial Communications Protocol The RV-8 will assign the value from the packet to the system balance. 7.3.25.4 Data Validation If a value is passed that exceeds the maximum value of that parameter the RV-8 will ignore the command and transmit a DC_NAK command with an error code DC_INVALID_DATA.

  • Page 37: Set Zone 2 Volume

    Lexicon RV-8 Serial Communications Protocol 7.3.27.4 Data Validation If a value is passed that exceeds the maximum value of that parameter the RV-8 will ignore the command and transmit a NAK command with an error code DC_INVALID_DATA. 7.3.28 Set Zone 2 Volume Commands RV-8 to set the Zone 2 volume with the value in this packet.

  • Page 38: Get Input Name By Id

    Lexicon RV-8 Serial Communications Protocol 7.3.29.2 Data Description Value: Data Type: Signed 8-bit integer (2’s compliment) Max: +16 (0x10) (Full Right) Min: -16 (0xF0) (Full Left) 7.3.29.3 RV-8 Response The RV-8 will assign the value from the packet to the Zone 2 balance.
  • Page 39 Lexicon RV-8 Serial Communications Protocol InputName: Data Type: Null (0x00) terminated ASCII character string. Max Length: INPUT_NAME_LENGTH defined in Appendix G Protocol Constants.

  • Page 40: Appendix A: Command Codes

    Lexicon RV-8 Serial Communications Protocol Appendix A: Command Codes Notifications: DC_NO_CMD 0x00 DC_WAKEUP 0x01 DC_SLEEP 0x02 DC_FPD 0x03 DC_PARAM_CHG_MSG 0x04 Host Commands: DC_CMD_RESET 0x10 HOST_WAKEUP 0x11 HOST_SLEEP 0x12 DC_CMD_GET_CUST_NAME 0x2B DC_CMD_SET_CUST_NAME 0x2C DC_CMD_GET_INPUT_NAME 0x2D DC_CMD_SET_INPUT_NAME 0x2E DC_CMD_GET_COM_CONFIG 0x2F DC_CMD_SET_COM_CONFIG 0x30...
  • Page 41 Lexicon RV-8 Serial Communications Protocol Responses DC_RESP_UNIT_CONFIG 0x80 DC_RESP_SYS_STATUS 0x81 DC_RESP_REC_ZONE2_STATUS 0x82 DC_RESP_SYS_PARAM_DEF 0x83 DC_RESP_SYS_PARAM_VALUES 0x84 DC_RESP_EFFECT_DEF 0x85 DC_RESP_EFFECT_PARAM_DEF 0x86 DC_RESP_EFFECT_PARAM_VALUES 0x87 DC_RESP_FPD_CTRL_STATUS 0x88 DC_RESP_CUST_NAME 0x89 DC_RESP_INPUT_NAME 0x8A DC_RESP_PEEK_VALUE 0x8B DC_RESP_COM_CONFIG 0x8C MC_RESP_SYS_PARAM_DEF 0x8F MC_RESP_UNIT_CONFIG 0x91 MC_RESP_PARAM_VALUE 0x92 MC_RESP_VALUE_STRING 0x93...

  • Page 42: Appendix B: Error Codes

    Lexicon RV-8 Serial Communications Protocol Appendix B: Error Codes Error Code(Hex) NO_ACK 0x00 DC_NO_ERROR 0x01 DC_ERR_PARITY 0x02 DC_ERR_FRAMING 0x03 DC_ERR_OVERRUN 0x04 DC_ERR_INVALID_PACKET 0x05 DC_ERR_TIME_OUT 0x06 DC_ERR_BUFFER_FULL 0x07 DC_INVALID_COUNT 0x10 DC_INVALID_CMD 0x11 DC_INVALID_DATA 0x12 DC_INVALID_ADDRESS 0x13 DC_INVALID_EFFECT_ID 0x14 DC_INVALID_PARAM_ID 0x15 DC_INVALID_NAME...

  • Page 43: Appendix D: Rv-8 Ir Codes

    Lexicon RV-8 Serial Communications Protocol Appendix D: RV-8 IR Codes Butto Butto Butto Button Main Zone-2 Zone 3 Shift LABEL DATA FUNCTION DATA FUNCTION DATA FUNCTION DATA (hex) (hex) (hex) (hex) Setup LIGHT None LIGHT None LIGHT None LIGHT None...

  • Page 45: Appendix F: Rv-8 Input Ids

    Lexicon RV-8 Serial Communications Protocol Appendix F: RV-8 Input Ids RV8 Input Input Name DVD1 DVD2 TUNER PHONO Appendix G: Protocol Constants Constant Value (Dec) Units FPD_LINE_LENGTH 20Chars PARAM_NAME_LENGTH 13Chars CUSTOM_NAME_LENGTH 20Chars INPUT_NAME_LENGTH 8Chars PARAM_PATH_LENGTH 80Chars INTER_PACKET_TIME 200mSec 0xF1 0xF2...

  • Page 46: Appendix J: Rv-8 Mode Ids

    Lexicon RV-8 Serial Communications Protocol Appendix J: RV-8 Mode Ids RV-8 Mode ID (Dec – Hex) RV-8 Mode Name 0 – 0x00 Reserved 1 – 0x01 Reserved 2 – 0x02 Reserved 3 – 0x03 L7 Film 4 – 0x04 L7 TV 5 –...
  • Page 47 Lexicon RV-8 Serial Communications Protocol RV-8 Mode ID (Dec – Hex) RV-8 Mode Name 58 – 0x3A PLIIx Movie 59 – 0x3B PLIIx Music 60 – 0x3C 5.1 PLIIx MOV 61 – 0x3D 5.1 PLIIx MUS 62 – 0x3E Headphone L7 63 –...

  • Page 48: Rv-8 V2.00 Parameter Id List

    Lexicon RV-8 Serial Communications Protocol 1.3 RV-8 V2.00 Parameter ID List The following table is for V2.00 reference only. These Parameter Id Values will change with S/W and Protocol version changes. The RV-8 can always be queried for the correct Parameter Id numbers and Parameter Definition Packets.
  • Page 49 Lexicon RV-8 Serial Communications Protocol 0x0029 PARAM.INPUTS.DVD1.TRIMMODE ParamId ParamId ParamName (dec) (hex) 0x002A PARAM.INPUTS.DVD1.VIDEOIN 0x002B PARAM.INPUTS.DVD1.CH2EFFCT 0x002C PARAM.INPUTS.DVD1.DDEFFCT 0x002D PARAM.INPUTS.DVD1.DTSEFFCT 0x002E PARAM.INPUTS.DVD1.MSRCMODE 0x002F PARAM.INPUTS.DVD1.Z3SRCMODE 0x0030 PARAM.INPUTS.DVD1.Z2SRCMODE 0x0031 PARAM.INPUTS.DVD1.Z2TRIM 0x0032 PARAM.INPUTS.DVD1.Z2TXRATE 0x0033 PARAM.INPUTS.DVD1.ANLGBYPASS 0x0034 PARAM.INPUTS.DVD1.DIGBYPASS 0x0035 PARAM.INPUTS.DVD1.TRIGGER1 0x0036 PARAM.INPUTS.DVD1.Z2DIGBYPASS 0x0037 PARAM.INPUTS.DVD1.TRIGGER2 0x0038 PARAM.INPUTS.DVD1.COMPONENTIN...
  • Page 50 Lexicon RV-8 Serial Communications Protocol 0x0057 PARAM.INPUTS.DVD2.DIGBYPASS ParamId ParamId ParamName (dec) (hex) 0x0058 PARAM.INPUTS.DVD2.TRIGGER1 0x0059 PARAM.INPUTS.DVD2.TRIGGER2 0x005A PARAM.INPUTS.DVD2.COMPONENTIN 0x005B PARAM.INPUTS.DVD2.SVID_16_9 0x005C PARAM.INPUTS.DVD2.Z2BLOCK 0x005D PARAM.INPUTS.DVD2.SVIDOSD_4_3 0x005E PARAM.INPUTS.DVD2.COMPNTOSD 0x005F PARAM.INPUTS.DVD2._51_AD_EFFECT 0x0060 PARAM.INPUTS.DVD2.VIDEO_PLL 0x0061 PARAM.INPUTS.DVD2.LAST2CHEFFECT 0x0062 PARAM.INPUTS.DVD2.LASTDDEFFECT 0x0063 PARAM.INPUTS.DVD2.LASTDTSEFFECT 0x0064 PARAM.INPUTS.DVD2.LAST51ADEFFECT 0x0065 PARAM.INPUTS.DVD2.LASTLIVEEFFECT 0x0066 PARAM.INPUTS.DVD2.LIVEEFFCT...
  • Page 51 Lexicon RV-8 Serial Communications Protocol 0x0085 PARAM.INPUTS.CD.LASTDTSEFFECT ParamId ParamId ParamName (dec) (hex) 0x0086 PARAM.INPUTS.CD.LAST51ADEFFECT 0x0087 PARAM.INPUTS.CD.LASTLIVEEFFECT 0x0088 PARAM.INPUTS.CD.LIVEEFFCT 0x0089 PARAM.INPUTS.CD.TRANSITION_TIME 0x008A PARAM.INPUTS.TUNER 0x008B PARAM.INPUTS.TUNER.INPNAME 0x008C PARAM.INPUTS.TUNER.DIGIN 0x008D PARAM.INPUTS.TUNER.ANLGIN 0x008E PARAM.INPUTS.TUNER.ANLGTRIM 0x008F PARAM.INPUTS.TUNER.TRIMMODE 0x0090 PARAM.INPUTS.TUNER.VIDEOIN 0x0091 PARAM.INPUTS.TUNER.CH2EFFCT 0x0092 PARAM.INPUTS.TUNER.DDEFFCT 0x0093 PARAM.INPUTS.TUNER.DTSEFFCT 0x0094 PARAM.INPUTS.TUNER.MSRCMODE...
  • Page 52 Lexicon RV-8 Serial Communications Protocol 0x00B3 PARAM.INPUTS.TV.CH2EFFCT ParamId ParamId ParamName (dec) (hex) 0x00B4 PARAM.INPUTS.TV.DDEFFCT 0x00B5 PARAM.INPUTS.TV.DTSEFFCT 0x00B6 PARAM.INPUTS.TV.MSRCMODE 0x00B7 PARAM.INPUTS.TV.Z2SRCMODE 0x00B8 PARAM.INPUTS.TV.Z3SRCMODE 0x00B9 PARAM.INPUTS.TV.Z2TRIM 0x00BA PARAM.INPUTS.TV.Z2TXRATE 0x00BB PARAM.INPUTS.TV.ANLGBYPASS 0x00BC PARAM.INPUTS.TV.DIGBYPASS 0x00BD PARAM.INPUTS.TV.Z2DIGBYPASS 0x00BE PARAM.INPUTS.TV.TRIGGER1 0x00BF PARAM.INPUTS.TV.TRIGGER2 0x00C0 PARAM.INPUTS.TV.COMPONENTIN 0x00C1 PARAM.INPUTS.TV.SVID_16_9 0x00C2 PARAM.INPUTS.TV.Z2BLOCK...
  • Page 53 Lexicon RV-8 Serial Communications Protocol 0x00E1 PARAM.INPUTS.VCR.TRIGGER2 ParamId ParamId ParamName (dec) (hex) 0x00E2 PARAM.INPUTS.VCR.COMPONENTIN 0x00E3 PARAM.INPUTS.VCR.SVID_16_9 0x00E4 PARAM.INPUTS.VCR.Z2BLOCK 0x00E5 PARAM.INPUTS.VCR.SVIDOSD_4_3 0x00E6 PARAM.INPUTS.VCR.COMPNTOSD 0x00E7 PARAM.INPUTS.VCR._51_AD_EFFECT 0x00E8 PARAM.INPUTS.VCR.VIDEO_PLL 0x00E9 PARAM.INPUTS.VCR.LAST2CHEFFECT 0x00EA PARAM.INPUTS.VCR.LASTDDEFFECT 0x00EB PARAM.INPUTS.VCR.LASTDTSEFFECT 0x00EC PARAM.INPUTS.VCR.LAST51ADEFFECT 0x00ED PARAM.INPUTS.VCR.LASTLIVEEFFECT 0x00EE PARAM.INPUTS.VCR.LIVEEFFCT 0x00EF PARAM.INPUTS.VCR.TRANSITION_TIME 0x00F0 PARAM.INPUTS.SAT...
  • Page 54 Lexicon RV-8 Serial Communications Protocol 0x010F PARAM.INPUTS.SAT.LASTLIVEEFFECT ParamId ParamId ParamName (dec) (hex) 0x0110 PARAM.INPUTS.SAT.LIVEEFFCT 0x0111 PARAM.INPUTS.SAT.TRANSITION_TIME 0x0112 PARAM.INPUTS.AUX 0x0113 PARAM.INPUTS.AUX.INPNAME 0x0114 PARAM.INPUTS.AUX.DIGIN 0x0115 PARAM.INPUTS.AUX.ANLGIN 0x0116 PARAM.INPUTS.AUX.ANLGTRIM 0x0117 PARAM.INPUTS.AUX.TRIMMODE 0x0118 PARAM.INPUTS.AUX.VIDEOIN 0x0119 PARAM.INPUTS.AUX.CH2EFFCT 0x011A PARAM.INPUTS.AUX.DDEFFCT 0x011B PARAM.INPUTS.AUX.DTSEFFCT 0x011C PARAM.INPUTS.AUX.MSRCMODE 0x011D PARAM.INPUTS.AUX.Z3SRCMODE 0x011E PARAM.INPUTS.AUX.Z2SRCMODE...
  • Page 55 Lexicon RV-8 Serial Communications Protocol 0x013D PARAM.INPUTS.LEVELS.REARRIGHT ParamId ParamId ParamName (dec) (hex) 0x013E PARAM.INPUTS.LEVELS.PEAK 0x013F PARAM.INPUTS.AUTOTRIM 0x0140 PARAM.INPUTS.PHONO 0x0141 PARAM.INPUTS.PHONO.INPNAME 0x0142 PARAM.INPUTS.PHONO.DIGIN 0x0143 PARAM.INPUTS.PHONO.ANLGIN 0x0144 PARAM.INPUTS.PHONO.ANLGTRIM 0x0145 PARAM.INPUTS.PHONO.TRIMMODE 0x0146 PARAM.INPUTS.PHONO.VIDEOIN 0x0147 PARAM.INPUTS.PHONO.CH2EFFCT 0x0148 PARAM.INPUTS.PHONO.DDEFFCT 0x0149 PARAM.INPUTS.PHONO.DTSEFFCT 0x014A PARAM.INPUTS.PHONO.MSRCMODE 0x014B PARAM.INPUTS.PHONO.Z3SRCMODE 0x014C PARAM.INPUTS.PHONO.Z2SRCMODE...
  • Page 56 Lexicon RV-8 Serial Communications Protocol 0x016B PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_CNTR_LEVEL ParamId ParamId ParamName (dec) (hex) 0x016C PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_SIDE_HP_XOVER 0x016D PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_SIDE_L_DIST 0x016E PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_SIDE_L_LEVEL 0x016F PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_SIDE_R_DIST 0x0170 PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_SIDE_R_LEVEL 0x0171 PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_REAR_HP_XOVER 0x0172 PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_REAR_L_DIST 0x0173 PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_REAR_L_LEVEL 0x0174 PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_REAR_R_DIST 0x0175 PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_REAR_R_LEVEL 0x0176 PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_SUB_LP_XOVER 0x0177 PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_SUB_L_DIST 0x0178 PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_SUB_L_LEVEL 0x0179 PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_SUB_R_DIST 0x017A PARAM.MAIN.OUTPUTS.AUTOCAL_DATA.AC_SUB_R_LEVEL...
  • Page 57 Lexicon RV-8 Serial Communications Protocol 0x0199 PARAM.MAIN.OUTPUTS.SUB ParamId ParamId ParamName (dec) (hex) 0x019A PARAM.MAIN.OUTPUTS.SUB.LP_XOVER 0x019B PARAM.MAIN.OUTPUTS.SUB.LEFT 0x019C PARAM.MAIN.OUTPUTS.SUB.LEFT.DISTANCE 0x019D PARAM.MAIN.OUTPUTS.SUB.LEFT.OUTLEVEL 0x019E PARAM.MAIN.OUTPUTS.SUB.RIGHT 0x019F PARAM.MAIN.OUTPUTS.SUB.RIGHT.DISTANCE 0x01A0 PARAM.MAIN.OUTPUTS.SUB.RIGHT.OUTLEVEL 0x01A1 PARAM.MAIN.OUTPUTS.SUB.CONFIG 0x01A2 PARAM.MAIN.OUTPUTS.SUB.LIMITEN 0x01A3 PARAM.MAIN.OUTPUTS.SUB.LIMITADJ 0x01A4 PARAM.MAIN.OUTPUTS.LFE 0x01A5 PARAM.MAIN.OUTPUTS.LFE.DISTANCE 0x01A6 PARAM.MAIN.OUTPUTS.LFE.OUTLEVEL 0x01A7 PARAM.MAIN.OUTPUTS.LFE.LIMITEN 0x01A8 PARAM.MAIN.OUTPUTS.LFE.LIMITADJ...
  • Page 58 Lexicon RV-8 Serial Communications Protocol 0x01C7 PARAM.MAIN.DOLBYDATA.ROOMTYPE ParamId ParamId ParamName (dec) (hex) 0x01C8 PARAM.MAIN.DOLBYDATA.CLEV 0x01C9 PARAM.MAIN.DOLBYDATA.SLEV 0x01CA PARAM.MAIN.DTSDATA 0x01CB PARAM.MAIN.DTSDATA.DTS_CHAN 0x01CC PARAM.MAIN.DTSDATA.ES_FLAG 0x01CD PARAM.MAIN.DTSDATA.DTSBITRATE 0x01CE PARAM.MAIN.DTSDATA.WORDLEN 0x01CF PARAM.MAIN.DTSDATA.SFREQ 0x01D0 PARAM.MAIN.DTSDATA._9624FLAG 0x01D1 PARAM.MAIN.MAXVOLUME 0x01D2 PARAM.MAIN.LASTVOLUME 0x01D3 PARAM.MAIN.BROWNOUT_PROTECT 0x01D4 PARAM.MAIN.NEEDSFONTLOAD 0x01D5 PARAM.ZONE3 0x01D6 PARAM.ZONE3.DATA_STREAM...
  • Page 59 Lexicon RV-8 Serial Communications Protocol 0x01F5 PARAM.EFFECTS.LOGIC7.AUTOAZIMUTH ParamId ParamId ParamName (dec) (hex) 0x01F6 PARAM.EFFECTS.LOGIC7.VOCALENH 0x01F7 PARAM.EFFECTS.LOGIC7.FRONTSTEER 0x01F8 PARAM.EFFECTS.LOGIC7.REEQ 0x01F9 PARAM.EFFECTS.LOGIC7.SOUNDSTAGE 0x01FA PARAM.EFFECTS.LOGIC7.FIVESPKRENH 0x01FB PARAM.EFFECTS.LOGIC7.BASSENH 0x01FC PARAM.EFFECTS.LOGIC7.SURRROLLOFF 0x01FD PARAM.EFFECTS.LOGIC7.REARDLYOFF 0x01FE PARAM.EFFECTS.LOGIC7.CENTERONOFF 0x01FF PARAM.EFFECTS.LOGIC7.SEVENCHANNEL 0x0200 PARAM.EFFECTS.LOGIC7.MONODETECT_ON 0x0201 PARAM.EFFECTS.LOGIC7.SURRONOFF 0x0202 PARAM.EFFECTS.LOGIC7.TRIGGER1 0x0203 PARAM.EFFECTS.LOGIC7.TRIGGER2 0x0204 PARAM.EFFECTS.LOGIC7.HIFRONT_REARROLLOFF...
  • Page 60 Lexicon RV-8 Serial Communications Protocol 0x0223 PARAM.EFFECTS.MUSIC_LOGIC.OUTPUTLEVELS.SIDEOUTLEVEL ParamId ParamId ParamName (dec) (hex) 0x0224 PARAM.EFFECTS.MUSIC_LOGIC.OUTPUTLEVELS.REAROUTLEVEL 0x0225 PARAM.EFFECTS.MUSIC_LOGIC.OUTPUTLEVELS.SUBOUTLEVEL 0x0226 PARAM.EFFECTS.MUSIC_LOGIC.OUTPUTLEVELS.LFEOUTLEVEL 0x0227 PARAM.EFFECTS.MUSIC_LOGIC.AUTOAZIMUTH 0x0228 PARAM.EFFECTS.MUSIC_LOGIC.VOCALENH 0x0229 PARAM.EFFECTS.MUSIC_LOGIC.FRONTSTEER 0x022A PARAM.EFFECTS.MUSIC_LOGIC.REEQ 0x022B PARAM.EFFECTS.MUSIC_LOGIC.SOUNDSTAGE 0x022C PARAM.EFFECTS.MUSIC_LOGIC.FIVESPKRENH 0x022D PARAM.EFFECTS.MUSIC_LOGIC.BASSENH 0x022E PARAM.EFFECTS.MUSIC_LOGIC.SURRROLLOFF 0x022F PARAM.EFFECTS.MUSIC_LOGIC.REARDLYOFF 0x0230 PARAM.EFFECTS.MUSIC_LOGIC.CENTERONOFF 0x0231 PARAM.EFFECTS.MUSIC_LOGIC.SEVENCHANNEL 0x0232 PARAM.EFFECTS.MUSIC_LOGIC.MONODETECT_ON...
  • Page 61 Lexicon RV-8 Serial Communications Protocol 0x0251 PARAM.EFFECTS.PROLOGIC.OUTPUTLEVELS.SIDEOUTLEVEL ParamId ParamId ParamName (dec) (hex) 0x0252 PARAM.EFFECTS.PROLOGIC.OUTPUTLEVELS.REAROUTLEVEL 0x0253 PARAM.EFFECTS.PROLOGIC.OUTPUTLEVELS.SUBOUTLEVEL 0x0254 PARAM.EFFECTS.PROLOGIC.OUTPUTLEVELS.LFEOUTLEVEL 0x0255 PARAM.EFFECTS.PROLOGIC.TWO_CH_MUX 0x0256 PARAM.EFFECTS.PROLOGIC.TWOCHCNTRMIX 0x0257 PARAM.EFFECTS.PROLOGIC.CENTERDELAY 0x0258 PARAM.EFFECTS.PROLOGIC.MONOREARON 0x0259 PARAM.EFFECTS.PROLOGIC.DECORRELATE 0x025A PARAM.EFFECTS.PROLOGIC.VOCALENH 0x025B PARAM.EFFECTS.PROLOGIC.REEQ 0x025C PARAM.EFFECTS.PROLOGIC.SURDLY10_25 0x025D PARAM.EFFECTS.PROLOGIC.TRIGGER1 0x025E PARAM.EFFECTS.PROLOGIC.TRIGGER2 0x025F PARAM.EFFECTS.PROLOGIC2 0x0260 PARAM.EFFECTS.PROLOGIC2.NAME...
  • Page 62 Lexicon RV-8 Serial Communications Protocol 0x027F PARAM.EFFECTS.PL2MUSIC.VOCALENH ParamId ParamId ParamName (dec) (hex) 0x0280 PARAM.EFFECTS.PL2MUSIC.REEQ 0x0281 PARAM.EFFECTS.PL2MUSIC.PL2PAN 0x0282 PARAM.EFFECTS.PL2MUSIC.CNTRWIDTH 0x0283 PARAM.EFFECTS.PL2MUSIC.DIMENSION 0x0284 PARAM.EFFECTS.PL2MUSIC.TRIGGER1 0x0285 PARAM.EFFECTS.PL2MUSIC.TRIGGER2 0x0286 PARAM.EFFECTS.PARTY 0x0287 PARAM.EFFECTS.PARTY.NAME 0x0288 PARAM.EFFECTS.PARTY.OUTPUTLEVELS 0x0289 PARAM.EFFECTS.PARTY.OUTPUTLEVELS.CNTROUTLEVEL 0x028A PARAM.EFFECTS.PARTY.OUTPUTLEVELS.SIDEOUTLEVEL 0x028B PARAM.EFFECTS.PARTY.OUTPUTLEVELS.REAROUTLEVEL 0x028C PARAM.EFFECTS.PARTY.OUTPUTLEVELS.SUBOUTLEVEL 0x028D PARAM.EFFECTS.PARTY.OUTPUTLEVELS.LFEOUTLEVEL 0x028E PARAM.EFFECTS.PARTY.AUTOAZIMUTH...
  • Page 63 Lexicon RV-8 Serial Communications Protocol 0x02AD PARAM.EFFECTS.MONO_LOGIC.OUTPUTLEVELS.SUBOUTLEVEL ParamId ParamId ParamName (dec) (hex) 0x02AE PARAM.EFFECTS.MONO_LOGIC.OUTPUTLEVELS.LFEOUTLEVEL 0x02AF PARAM.EFFECTS.MONO_LOGIC.VOCALENH 0x02B0 PARAM.EFFECTS.MONO_LOGIC.REEQ 0x02B1 PARAM.EFFECTS.MONO_LOGIC.USEREVERB 0x02B2 PARAM.EFFECTS.MONO_LOGIC.TRIGGER1 0x02B3 PARAM.EFFECTS.MONO_LOGIC.TRIGGER2 0x02B4 PARAM.EFFECTS.MONO 0x02B5 PARAM.EFFECTS.MONO.NAME 0x02B6 PARAM.EFFECTS.MONO.OUTPUTLEVELS 0x02B7 PARAM.EFFECTS.MONO.OUTPUTLEVELS.CNTROUTLEVEL 0x02B8 PARAM.EFFECTS.MONO.OUTPUTLEVELS.SIDEOUTLEVEL 0x02B9 PARAM.EFFECTS.MONO.OUTPUTLEVELS.REAROUTLEVEL 0x02BA PARAM.EFFECTS.MONO.OUTPUTLEVELS.SUBOUTLEVEL 0x02BB PARAM.EFFECTS.MONO.OUTPUTLEVELS.LFEOUTLEVEL 0x02BC PARAM.EFFECTS.MONO.USEREVERB...
  • Page 64 Lexicon RV-8 Serial Communications Protocol 0x02DB PARAM.EFFECTS._51_LOGIC7.FRONTSTEER51 ParamId ParamId ParamName (dec) (hex) 0x02DC PARAM.EFFECTS._51_LOGIC7.SURREX 0x02DD PARAM.EFFECTS._51_LOGIC7.SEVENCHANNEL 0x02DE PARAM.EFFECTS._51_LOGIC7.TRIGGER1 0x02DF PARAM.EFFECTS._51_LOGIC7.TRIGGER2 0x02E0 PARAM.EFFECTS._51_LOGIC7.MONOREARON51 0x02E1 PARAM.EFFECTS._51_LOGIC7.SURRROLLOFF 0x02E2 PARAM.EFFECTS._51_LOGIC7.CENTERONOFF 0x02E3 PARAM.EFFECTS._51_LOGIC7.SURRONOFF 0x02E4 PARAM.EFFECTS._51_MUSIC 0x02E5 PARAM.EFFECTS._51_MUSIC.NAME 0x02E6 PARAM.EFFECTS._51_MUSIC.OUTPUTLEVELS 0x02E7 PARAM.EFFECTS._51_MUSIC.OUTPUTLEVELS.CNTROUTLEVEL 0x02E8 PARAM.EFFECTS._51_MUSIC.OUTPUTLEVELS.SIDEOUTLEVEL 0x02E9 PARAM.EFFECTS._51_MUSIC.OUTPUTLEVELS.REAROUTLEVEL 0x02EA PARAM.EFFECTS._51_MUSIC.OUTPUTLEVELS.SUBOUTLEVEL...
  • Page 65 Lexicon RV-8 Serial Communications Protocol 0x0309 PARAM.EFFECTS._51_TV_LOGIC.REARDLYOFF ParamId ParamId ParamName (dec) (hex) 0x030A PARAM.EFFECTS._51_TV_LOGIC.COMPRESSION 0x030B PARAM.EFFECTS._51_TV_LOGIC.LFEMIX 0x030C PARAM.EFFECTS._51_TV_LOGIC.SOUNDSTAGE51 0x030D PARAM.EFFECTS._51_TV_LOGIC.FRONTSTEER51 0x030E PARAM.EFFECTS._51_TV_LOGIC.SURREX 0x030F PARAM.EFFECTS._51_TV_LOGIC.SEVENCHANNEL 0x0310 PARAM.EFFECTS._51_TV_LOGIC.TRIGGER1 0x0311 PARAM.EFFECTS._51_TV_LOGIC.TRIGGER2 0x0312 PARAM.EFFECTS._51_TV_LOGIC.MONOREARON51 0x0313 PARAM.EFFECTS._51_TV_LOGIC.SURRROLLOFF 0x0314 PARAM.EFFECTS._51_TV_LOGIC.CENTERONOFF 0x0315 PARAM.EFFECTS._51_TV_LOGIC.SURRONOFF 0x0316 PARAM.EFFECTS._51_THX 0x0317 PARAM.EFFECTS._51_THX.NAME 0x0318 PARAM.EFFECTS._51_THX.OUTPUTLEVELS...
  • Page 66 Lexicon RV-8 Serial Communications Protocol 0x0337 PARAM.EFFECTS.DOLBY_DIGITAL.TWO_CH_MUX ParamId ParamId ParamName (dec) (hex) 0x0338 PARAM.EFFECTS.DOLBY_DIGITAL.TWOCHCNTRMIX 0x0339 PARAM.EFFECTS.DOLBY_DIGITAL.CENTERDELAY 0x033A PARAM.EFFECTS.DOLBY_DIGITAL.DECORRELATE 0x033B PARAM.EFFECTS.DOLBY_DIGITAL.VOCALENH 0x033C PARAM.EFFECTS.DOLBY_DIGITAL.REEQ 0x033D PARAM.EFFECTS.DOLBY_DIGITAL.TRIGGER1 0x033E PARAM.EFFECTS.DOLBY_DIGITAL.TRIGGER2 0x033F PARAM.EFFECTS.DOLBY_DIGITAL.MONOREARON 0x0340 PARAM.EFFECTS.DOLBY_DIGITAL.EX 0x0341 PARAM.EFFECTS._51_2CHANNEL 0x0342 PARAM.EFFECTS._51_2CHANNEL.NAME 0x0343 PARAM.EFFECTS._51_2CHANNEL.OUTPUTLEVELS 0x0344 PARAM.EFFECTS._51_2CHANNEL.OUTPUTLEVELS.CNTROUTLEVEL 0x0345 PARAM.EFFECTS._51_2CHANNEL.OUTPUTLEVELS.SIDEOUTLEVEL 0x0346 PARAM.EFFECTS._51_2CHANNEL.OUTPUTLEVELS.REAROUTLEVEL...
  • Page 67 Lexicon RV-8 Serial Communications Protocol 0x0364 PARAM.EFFECTS._51_MONO_LOGIC.OUTPUTLEVELS.CNTROUTLEVEL 0x0365 PARAM.EFFECTS._51_MONO_LOGIC.OUTPUTLEVELS.SIDEOUTLEVEL ParamId ParamId ParamName (dec) (hex) 0x0366 PARAM.EFFECTS._51_MONO_LOGIC.OUTPUTLEVELS.REAROUTLEVEL 0x0367 PARAM.EFFECTS._51_MONO_LOGIC.OUTPUTLEVELS.SUBOUTLEVEL 0x0368 PARAM.EFFECTS._51_MONO_LOGIC.OUTPUTLEVELS.LFEOUTLEVEL 0x0369 PARAM.EFFECTS._51_MONO_LOGIC.EFFECTLEVEL 0x036A PARAM.EFFECTS._51_MONO_LOGIC.ACADEMY 0x036B PARAM.EFFECTS._51_MONO_LOGIC.SURRROLLOFF 0x036C PARAM.EFFECTS._51_MONO_LOGIC.USEREVERB 0x036D PARAM.EFFECTS._51_MONO_LOGIC.TRIGGER1 0x036E PARAM.EFFECTS._51_MONO_LOGIC.TRIGGER2 0x036F PARAM.EFFECTS._51_AD_FILM 0x0370 PARAM.EFFECTS._51_AD_FILM.NAME 0x0371 PARAM.EFFECTS._51_AD_FILM.OUTPUTLEVELS 0x0372 PARAM.EFFECTS._51_AD_FILM.OUTPUTLEVELS.CNTROUTLEVEL 0x0373 PARAM.EFFECTS._51_AD_FILM.OUTPUTLEVELS.SIDEOUTLEVEL...
  • Page 68 Lexicon RV-8 Serial Communications Protocol 0x0392 PARAM.EFFECTS._20_ANALOG_BYPASS.TRIGGER2 0x0393 PARAM.EFFECTS._51_ANALOG_BYPASS ParamId ParamId ParamName (dec) (hex) 0x0394 PARAM.EFFECTS._51_ANALOG_BYPASS.NAME 0x0395 PARAM.EFFECTS._51_ANALOG_BYPASS.OUTPUTLEVELS 0x0396 PARAM.EFFECTS._51_ANALOG_BYPASS.OUTPUTLEVELS.CNTROUTLEVEL 0x0397 PARAM.EFFECTS._51_ANALOG_BYPASS.OUTPUTLEVELS.SIDEOUTLEVEL 0x0398 PARAM.EFFECTS._51_ANALOG_BYPASS.OUTPUTLEVELS.REAROUTLEVEL 0x0399 PARAM.EFFECTS._51_ANALOG_BYPASS.OUTPUTLEVELS.SUBOUTLEVEL 0x039A PARAM.EFFECTS._51_ANALOG_BYPASS.OUTPUTLEVELS.LFEOUTLEVEL 0x039B PARAM.EFFECTS._51_ANALOG_BYPASS.TRIGGER1 0x039C PARAM.EFFECTS._51_ANALOG_BYPASS.TRIGGER2 0x039D PARAM.EFFECTS._51_MONO 0x039E PARAM.EFFECTS._51_MONO.NAME 0x039F PARAM.EFFECTS._51_MONO.OUTPUTLEVELS 0x03A0 PARAM.EFFECTS._51_MONO.OUTPUTLEVELS.CNTROUTLEVEL 0x03A1 PARAM.EFFECTS._51_MONO.OUTPUTLEVELS.SIDEOUTLEVEL...
  • Page 69 Lexicon RV-8 Serial Communications Protocol 0x03C0 PARAM.EFFECTS.DTS_LOGIC7.OUTPUTLEVELS.SIDEOUTLEVEL 0x03C1 PARAM.EFFECTS.DTS_LOGIC7.OUTPUTLEVELS.REAROUTLEVEL ParamId ParamId ParamName (dec) (hex) 0x03C2 PARAM.EFFECTS.DTS_LOGIC7.OUTPUTLEVELS.SUBOUTLEVEL 0x03C3 PARAM.EFFECTS.DTS_LOGIC7.OUTPUTLEVELS.LFEOUTLEVEL 0x03C4 PARAM.EFFECTS.DTS_LOGIC7.VOCALENH 0x03C5 PARAM.EFFECTS.DTS_LOGIC7.FIVESPKRENH 0x03C6 PARAM.EFFECTS.DTS_LOGIC7.BASSENH 0x03C7 PARAM.EFFECTS.DTS_LOGIC7.REEQ 0x03C8 PARAM.EFFECTS.DTS_LOGIC7.REARDLYOFF 0x03C9 PARAM.EFFECTS.DTS_LOGIC7.LFEMIX 0x03CA PARAM.EFFECTS.DTS_LOGIC7.SOUNDSTAGE51 0x03CB PARAM.EFFECTS.DTS_LOGIC7.FRONTSTEER51 0x03CC PARAM.EFFECTS.DTS_LOGIC7.SURREX 0x03CD PARAM.EFFECTS.DTS_LOGIC7.SEVENCHANNEL 0x03CE PARAM.EFFECTS.DTS_LOGIC7.TRIGGER1 0x03CF PARAM.EFFECTS.DTS_LOGIC7.TRIGGER2...
  • Page 70 Lexicon RV-8 Serial Communications Protocol 0x03EE PARAM.EFFECTS.DTS_MUSIC.OUTPUTLEVELS 1006 0x03EF PARAM.EFFECTS.DTS_MUSIC.OUTPUTLEVELS.CNTROUTLEVEL 1007 ParamId ParamId ParamName (dec) (hex) 0x03F0 PARAM.EFFECTS.DTS_MUSIC.OUTPUTLEVELS.SIDEOUTLEVEL 1008 0x03F1 PARAM.EFFECTS.DTS_MUSIC.OUTPUTLEVELS.REAROUTLEVEL 1009 0x03F2 PARAM.EFFECTS.DTS_MUSIC.OUTPUTLEVELS.SUBOUTLEVEL 1010 0x03F3 PARAM.EFFECTS.DTS_MUSIC.OUTPUTLEVELS.LFEOUTLEVEL 1011 0x03F4 PARAM.EFFECTS.DTS_MUSIC.VOCALENH 1012 0x03F5 PARAM.EFFECTS.DTS_MUSIC.FIVESPKRENH 1013 0x03F6 PARAM.EFFECTS.DTS_MUSIC.BASSENH 1014 0x03F7 PARAM.EFFECTS.DTS_MUSIC.REEQ 1015 0x03F8 PARAM.EFFECTS.DTS_MUSIC.REARDLYOFF...
  • Page 71 Lexicon RV-8 Serial Communications Protocol 0x041C PARAM.EFFECTS.DTS_NEO_MUSIC.OUTPUTLEVELS 1052 0x041D PARAM.EFFECTS.DTS_NEO_MUSIC.OUTPUTLEVELS.CNTROUTLEVEL 1053 ParamId ParamId ParamName (dec) (hex) 0x041E PARAM.EFFECTS.DTS_NEO_MUSIC.OUTPUTLEVELS.SIDEOUTLEVEL 1054 0x041F PARAM.EFFECTS.DTS_NEO_MUSIC.OUTPUTLEVELS.REAROUTLEVEL 1055 0x0420 PARAM.EFFECTS.DTS_NEO_MUSIC.OUTPUTLEVELS.SUBOUTLEVEL 1056 0x0421 PARAM.EFFECTS.DTS_NEO_MUSIC.OUTPUTLEVELS.LFEOUTLEVEL 1057 0x0422 PARAM.EFFECTS.DTS_NEO_MUSIC.TRIGGER1 1058 0x0423 PARAM.EFFECTS.DTS_NEO_MUSIC.TRIGGER2 1059 0x0424 PARAM.EFFECTS.DTS_NEO_MUSIC.DECORRELATE 1060 0x0425 PARAM.EFFECTS.DTS_NEO_MUSIC.MONOREARON 1061 0x0426 PARAM.EFFECTS.DTS_NEO_FILM...
  • Page 72 Lexicon RV-8 Serial Communications Protocol 0x044A PARAM.EFFECTS._51_AD_MUSIC.FIVESPKRENH 1098 0x044B PARAM.EFFECTS._51_AD_MUSIC.BASSENH 1099 ParamId ParamId ParamName (dec) (hex) 0x044C PARAM.EFFECTS._51_AD_MUSIC.REEQ 1100 0x044D PARAM.EFFECTS._51_AD_MUSIC.REARDLYOFF 1101 0x044E PARAM.EFFECTS._51_AD_MUSIC.LFEMIX 1102 0x044F PARAM.EFFECTS._51_AD_MUSIC.SOUNDSTAGE51 1103 0x0450 PARAM.EFFECTS._51_AD_MUSIC.FRONTSTEER51 1104 0x0451 PARAM.EFFECTS._51_AD_MUSIC.SURREX 1105 0x0452 PARAM.EFFECTS._51_AD_MUSIC.SEVENCHANNEL 1106 0x0453 PARAM.EFFECTS._51_AD_MUSIC.TRIGGER1 1107 0x0454 PARAM.EFFECTS._51_AD_MUSIC.TRIGGER2...
  • Page 73 Lexicon RV-8 Serial Communications Protocol 0x0478 PARAM.EFFECTS._51_AD.REEQ 1144 0x0479 PARAM.EFFECTS._51_AD.TRIGGER1 1145 ParamId ParamId ParamName (dec) (hex) 0x047A PARAM.EFFECTS._51_AD.TRIGGER2 1146 0x047B PARAM.EFFECTS._51_AD.ANLGCENTERONOFF 1147 0x047C PARAM.EFFECTS._51_AD.ANLGSURRONOFF 1148 0x047D PARAM.EFFECTS._51_AD_THX 1149 0x047E PARAM.EFFECTS._51_AD_THX.NAME 1150 0x047F PARAM.EFFECTS._51_AD_THX.OUTPUTLEVELS 1151 0x0480 PARAM.EFFECTS._51_AD_THX.OUTPUTLEVELS.CNTROUTLEVEL 1152 0x0481 PARAM.EFFECTS._51_AD_THX.OUTPUTLEVELS.SIDEOUTLEVEL 1153 0x0482 PARAM.EFFECTS._51_AD_THX.OUTPUTLEVELS.REAROUTLEVEL...
  • Page 74 Lexicon RV-8 Serial Communications Protocol 0x04A6 PARAM.EFFECTS._51_AD_THX_MUSIC.SURREX 1190 0x04A7 PARAM.EFFECTS._51_AD_THX_MUSIC.THXMODEON 1191 ParamId ParamId ParamName (dec) (hex) 0x04A8 PARAM.EFFECTS._51_AD_THX_MUSIC.TRIGGER1 1192 0x04A9 PARAM.EFFECTS._51_AD_THX_MUSIC.TRIGGER2 1193 0x04AA PARAM.EFFECTS._51_AD_THX_MUSIC.REARTIMBRE 1194 0x04AB PARAM.EFFECTS._51_AD_THX_MUSIC.ANLGCENTERONOFF 1195 0x04AC PARAM.EFFECTS._51_AD_THX_MUSIC.ANLGSURRONOFF 1196 0x04AD PARAM.EFFECTS._51_THX_MUSIC 1197 0x04AE PARAM.EFFECTS._51_THX_MUSIC.NAME 1198 0x04AF PARAM.EFFECTS._51_THX_MUSIC.OUTPUTLEVELS 1199 0x04B0 PARAM.EFFECTS._51_THX_MUSIC.OUTPUTLEVELS.CNTROUTLEVEL...
  • Page 75 Lexicon RV-8 Serial Communications Protocol 0x04D4 PARAM.EFFECTS.DTS_THX_MUSIC.TIMBRE 1236 0x04D5 PARAM.EFFECTS.DTS_THX_MUSIC.SURREX 1237 ParamId ParamId ParamName (dec) (hex) 0x04D6 PARAM.EFFECTS.DTS_THX_MUSIC.THXMODEON 1238 0x04D7 PARAM.EFFECTS.DTS_THX_MUSIC.TRIGGER1 1239 0x04D8 PARAM.EFFECTS.DTS_THX_MUSIC.TRIGGER2 1240 0x04D9 PARAM.EFFECTS.DTS_THX_MUSIC.REARTIMBRE 1241 0x04DA PARAM.EFFECTS.DTS_THX_MUSIC.DTS_ES_DETECT 1242 0x04DB PARAM.EFFECTS.AUTO_CAL 1243 0x04DC PARAM.EFFECTS.AUTO_CAL.NAME 1244 0x04DD PARAM.EFFECTS.AUTO_CAL.OUTPUTLEVELS 1245 0x04DE PARAM.EFFECTS.AUTO_CAL.OUTPUTLEVELS.CNTROUTLEVEL...
  • Page 76 Lexicon RV-8 Serial Communications Protocol 0x0502 PARAM.EFFECTS.CONCERT_HALL.SIZE 1282 0x0503 PARAM.EFFECTS.CONCERT_HALL.PREDELAY 1283 ParamId ParamId ParamName (dec) (hex) 0x0504 PARAM.EFFECTS.CONCERT_HALL.MIDRT 1284 0x0505 PARAM.EFFECTS.CONCERT_HALL.SPEECHDETECT 1285 0x0506 PARAM.EFFECTS.CONCERT_HALL.CENTERDRYLEVEL 1286 0x0507 PARAM.EFFECTS.CHURCH 1287 0x0508 PARAM.EFFECTS.CHURCH.NAME 1288 0x0509 PARAM.EFFECTS.CHURCH.OUTPUTLEVELS 1289 0x050A PARAM.EFFECTS.CHURCH.OUTPUTLEVELS.CNTROUTLEVEL 1290 0x050B PARAM.EFFECTS.CHURCH.OUTPUTLEVELS.SIDEOUTLEVEL 1291 0x050C PARAM.EFFECTS.CHURCH.OUTPUTLEVELS.REAROUTLEVEL...
  • Page 77 Lexicon RV-8 Serial Communications Protocol 0x0530 PARAM.EFFECTS.MUSIC_SURR.NAME 1328 0x0531 PARAM.EFFECTS.MUSIC_SURR.OUTPUTLEVELS 1329 ParamId ParamId ParamName (dec) (hex) 0x0532 PARAM.EFFECTS.MUSIC_SURR.OUTPUTLEVELS.CNTROUTLEVEL 1330 0x0533 PARAM.EFFECTS.MUSIC_SURR.OUTPUTLEVELS.SIDEOUTLEVEL 1331 0x0534 PARAM.EFFECTS.MUSIC_SURR.OUTPUTLEVELS.REAROUTLEVEL 1332 0x0535 PARAM.EFFECTS.MUSIC_SURR.OUTPUTLEVELS.SUBOUTLEVEL 1333 0x0536 PARAM.EFFECTS.MUSIC_SURR.OUTPUTLEVELS.LFEOUTLEVEL 1334 0x0537 PARAM.EFFECTS.MUSIC_SURR.AUTOAZIMUTH 1335 0x0538 PARAM.EFFECTS.MUSIC_SURR.VOCALENH 1336 0x0539 PARAM.EFFECTS.MUSIC_SURR.FRONTSTEER 1337 0x053A PARAM.EFFECTS.MUSIC_SURR.REEQ...
  • Page 78 Lexicon RV-8 Serial Communications Protocol 0x055E PARAM.EFFECTS.PROLOGIC_THX.OUTPUTLEVELS 1374 0x055F PARAM.EFFECTS.PROLOGIC_THX.OUTPUTLEVELS.CNTROUTLEVEL 1375 ParamId ParamId ParamName (dec) (hex) 0x0560 PARAM.EFFECTS.PROLOGIC_THX.OUTPUTLEVELS.SIDEOUTLEVEL 1376 0x0561 PARAM.EFFECTS.PROLOGIC_THX.OUTPUTLEVELS.REAROUTLEVEL 1377 0x0562 PARAM.EFFECTS.PROLOGIC_THX.OUTPUTLEVELS.SUBOUTLEVEL 1378 0x0563 PARAM.EFFECTS.PROLOGIC_THX.OUTPUTLEVELS.LFEOUTLEVEL 1379 0x0564 PARAM.EFFECTS.PROLOGIC_THX.TWO_CH_MUX 1380 0x0565 PARAM.EFFECTS.PROLOGIC_THX.TWOCHCNTRMIX 1381 0x0566 PARAM.EFFECTS.PROLOGIC_THX.CENTERDELAY 1382 0x0567 PARAM.EFFECTS.PROLOGIC_THX.MONOREARON 1383 0x0568 PARAM.EFFECTS.PROLOGIC_THX.DECORRELATE...
  • Page 79 Lexicon RV-8 Serial Communications Protocol 0x058C PARAM.EFFECTS.LIVE1.INPUTDB 1420 0x058D PARAM.EFFECTS.LIVE1.OUTPUTDB 1421 ParamId ParamId ParamName (dec) (hex) 0x058E PARAM.EFFECTS.LIVE1.LVGNRDNOUTBIAS 1422 0x058F PARAM.EFFECTS.LIVE1.LVGNRDN 1423 0x0590 PARAM.EFFECTS.LIVE1.MICAUTOBAL 1424 0x0591 PARAM.EFFECTS.LIVE1.LVGNRDNTHRESH 1425 0x0592 PARAM.EFFECTS.LIVE1.INLIMTHRESH 1426 0x0593 PARAM.EFFECTS.LIVE1.LOWFILTERGAIN 1427 0x0594 PARAM.EFFECTS.LIVE2 1428 0x0595 PARAM.EFFECTS.LIVE2.NAME 1429 0x0596 PARAM.EFFECTS.LIVE2.OUTPUTLEVELS...
  • Page 80 Lexicon RV-8 Serial Communications Protocol 0x05BA PARAM.EFFECTS.LIVE3.OUTPUTLEVELS 1466 0x05BB PARAM.EFFECTS.LIVE3.OUTPUTLEVELS.CNTROUTLEVEL 1467 ParamId ParamId ParamName (dec) (hex) 0x05BC PARAM.EFFECTS.LIVE3.OUTPUTLEVELS.SIDEOUTLEVEL 1468 0x05BD PARAM.EFFECTS.LIVE3.OUTPUTLEVELS.REAROUTLEVEL 1469 0x05BE PARAM.EFFECTS.LIVE3.OUTPUTLEVELS.SUBOUTLEVEL 1470 0x05BF PARAM.EFFECTS.LIVE3.OUTPUTLEVELS.LFEOUTLEVEL 1471 0x05C0 PARAM.EFFECTS.LIVE3.TRIGGER1 1472 0x05C1 PARAM.EFFECTS.LIVE3.TRIGGER2 1473 0x05C2 PARAM.EFFECTS.LIVE3.EFFECTLEVEL 1474 0x05C3 PARAM.EFFECTS.LIVE3.SURRROLLOFF 1475 0x05C4 PARAM.EFFECTS.LIVE3.SIZE3...
  • Page 81 Lexicon RV-8 Serial Communications Protocol 0x05E8 PARAM.EFFECTS.PL2XMOVIE.OUTPUTLEVELS 1512 0x05E9 PARAM.EFFECTS.PL2XMOVIE.OUTPUTLEVELS.CNTROUTLEVEL 1513 ParamId ParamId ParamName (dec) (hex) 0x05EA PARAM.EFFECTS.PL2XMOVIE.OUTPUTLEVELS.SIDEOUTLEVEL 1514 0x05EB PARAM.EFFECTS.PL2XMOVIE.OUTPUTLEVELS.REAROUTLEVEL 1515 0x05EC PARAM.EFFECTS.PL2XMOVIE.OUTPUTLEVELS.SUBOUTLEVEL 1516 0x05ED PARAM.EFFECTS.PL2XMOVIE.OUTPUTLEVELS.LFEOUTLEVEL 1517 0x05EE PARAM.EFFECTS.PL2XMOVIE.SIDEREAR10DELAY 1518 0x05EF PARAM.EFFECTS.PL2XMOVIE.TWO_CH_MUX 1519 0x05F0 PARAM.EFFECTS.PL2XMOVIE.TWOCHCNTRMIX 1520 0x05F1 PARAM.EFFECTS.PL2XMOVIE.CENTERDELAY 1521 0x05F2 PARAM.EFFECTS.PL2XMOVIE.MONOREARON...
  • Page 82 Lexicon RV-8 Serial Communications Protocol 0x0616 PARAM.EFFECTS.PL2XTHX.OUTPUTLEVELS.SIDEOUTLEVEL 1558 0x0617 PARAM.EFFECTS.PL2XTHX.OUTPUTLEVELS.REAROUTLEVEL 1559 ParamId ParamId ParamName (dec) (hex) 0x0618 PARAM.EFFECTS.PL2XTHX.OUTPUTLEVELS.SUBOUTLEVEL 1560 0x0619 PARAM.EFFECTS.PL2XTHX.OUTPUTLEVELS.LFEOUTLEVEL 1561 0x061A PARAM.EFFECTS.PL2XTHX.TWO_CH_MUX 1562 0x061B PARAM.EFFECTS.PL2XTHX.TWOCHCNTRMIX 1563 0x061C PARAM.EFFECTS.PL2XTHX.CENTERDELAY 1564 0x061D PARAM.EFFECTS.PL2XTHX.MONOREARON 1565 0x061E PARAM.EFFECTS.PL2XTHX.DECORRELATE 1566 0x061F PARAM.EFFECTS.PL2XTHX.VOCALENH 1567 0x0620 PARAM.EFFECTS.PL2XTHX.REEQ...
  • Page 83 Lexicon RV-8 Serial Communications Protocol 0x0644 PARAM.EFFECTS._51_PL2X_MUSIC.COMPRESSION 1604 0x0645 PARAM.EFFECTS._51_PL2X_MUSIC.LFEMIX 1605 ParamId ParamId ParamName (dec) (hex) 0x0646 PARAM.EFFECTS._51_PL2X_MUSIC.TWO_CH_MUX 1606 0x0647 PARAM.EFFECTS._51_PL2X_MUSIC.TWOCHCNTRMIX 1607 0x0648 PARAM.EFFECTS._51_PL2X_MUSIC.CENTERDELAY 1608 0x0649 PARAM.EFFECTS._51_PL2X_MUSIC.DECORRELATE 1609 0x064A PARAM.EFFECTS._51_PL2X_MUSIC.VOCALENH 1610 0x064B PARAM.EFFECTS._51_PL2X_MUSIC.REEQ 1611 0x064C PARAM.EFFECTS._51_PL2X_MUSIC.TRIGGER1 1612 0x064D PARAM.EFFECTS._51_PL2X_MUSIC.TRIGGER2 1613 0x064E PARAM.EFFECTS._51_PL2X_MUSIC.MONOREARON...
  • Page 84 Lexicon RV-8 Serial Communications Protocol 0x0672 PARAM.EFFECTS.HEADPHONE51_DTS.OUTPUTLEVELS 1650 0x0673 PARAM.EFFECTS.HEADPHONE51_DTS.OUTPUTLEVELS.CNTROUTLEVEL 1651 ParamId ParamId ParamName (dec) (hex) 0x0674 PARAM.EFFECTS.HEADPHONE51_DTS.OUTPUTLEVELS.SIDEOUTLEVEL 1652 0x0675 PARAM.EFFECTS.HEADPHONE51_DTS.OUTPUTLEVELS.REAROUTLEVEL 1653 0x0676 PARAM.EFFECTS.HEADPHONE51_DTS.OUTPUTLEVELS.SUBOUTLEVEL 1654 0x0677 PARAM.EFFECTS.HEADPHONE51_DTS.OUTPUTLEVELS.LFEOUTLEVEL 1655 0x0678 PARAM.EFFECTS.HEADPHONE51_DTS.MONOREARON 1656 0x0679 PARAM.EFFECTS.HEADPHONE51_DTS.DTS_ES_DETECT 1657 0x067A PARAM.EFFECTS.HEADPHONE51_DTS.TRIGGER1 1658 0x067B PARAM.EFFECTS.HEADPHONE51_DTS.TRIGGER2 1659 0x067C PARAM.ZONE2...
  • Page 85 Lexicon RV-8 Serial Communications Protocol 0x06A0 PARAM.TMPKEY 1696 0x06A1 PARAM.TUNER 1697 ParamId ParamId ParamName (dec) (hex) 1698 0x06A2 PARAM.TUNER.PRESETS note: this parameter is an array 1699 0x06A3 PARAM.TUNER.STATIONNAME_ACTIVE 1700 0x06A4 PARAM.TUNER.BAND_ACTIVE 1701 0x06A5 PARAM.TUNER.FREQUENCY_ACTIVE 1702 0x06A6 PARAM.TUNER.FILTER_ACTIVE 1703 0x06A7 PARAM.TUNER.REGION 1704 0x06A8 PARAM.TUNER.LASTAM...
  • Page 86 Lexicon RV-8 Serial Communications Protocol 1742 0x06CE PARAM.LIVEEQ.LEFTFILTERS.FILTER0.FREQ 1743 0x06CF PARAM.LIVEEQ.LEFTFILTERS.FILTER0.GAIN ParamId ParamId ParamName (dec) (hex) 1744 0x06D0 PARAM.LIVEEQ.LEFTFILTERS.FILTER0.FLTRTYPE 1745 0x06D1 PARAM.LIVEEQ.LEFTFILTERS.FILTER1 1746 0x06D2 PARAM.LIVEEQ.LEFTFILTERS.FILTER1.Q 1747 0x06D3 PARAM.LIVEEQ.LEFTFILTERS.FILTER1.FREQ 1748 0x06D4 PARAM.LIVEEQ.LEFTFILTERS.FILTER1.GAIN 1749 0x06D5 PARAM.LIVEEQ.LEFTFILTERS.FILTER1.FLTRTYPE 1750 0x06D6 PARAM.LIVEEQ.LEFTFILTERS.FILTER2 1751 0x06D7 PARAM.LIVEEQ.LEFTFILTERS.FILTER2.Q 1752 0x06D8 PARAM.LIVEEQ.LEFTFILTERS.FILTER2.FREQ...
  • Page 87 Lexicon RV-8 Serial Communications Protocol 1788 0x06FC PARAM.LIVEEQ.RIGHTFILTERS.FILTER2.Q 1789 0x06FD PARAM.LIVEEQ.RIGHTFILTERS.FILTER2.FREQ ParamId ParamId ParamName (dec) (hex) 1790 0x06FE PARAM.LIVEEQ.RIGHTFILTERS.FILTER2.GAIN 1791 0x06FF PARAM.LIVEEQ.RIGHTFILTERS.FILTER2.FLTRTYPE 1792 0x0700 PARAM.LIVEEQ.RIGHTFILTERS.FILTER3 1793 0x0701 PARAM.LIVEEQ.RIGHTFILTERS.FILTER3.Q 1794 0x0702 PARAM.LIVEEQ.RIGHTFILTERS.FILTER3.FREQ 1795 0x0703 PARAM.LIVEEQ.RIGHTFILTERS.FILTER3.GAIN 1796 0x0704 PARAM.LIVEEQ.RIGHTFILTERS.FILTER3.FLTRTYPE 1797 0x0705 PARAM.LIVEEQ.RIGHTFILTERS.FILTER4 1798 0x0706 PARAM.LIVEEQ.RIGHTFILTERS.FILTER4.Q...
